HNK HB-130C
Key Specifications
Spindle Taper
Table Size
Spindle Power
x axis travel
y axis travel
z axis travel
How much does the HNK HB-130C cost?
Price estimate
We do not have a price for the HNK HB-130C that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The HNK HB-130C changes the table concept of the HB series. Its table type is given as Rotary + Sub table: a 1,400 x 1,400 mm (55.1 x 55.1 in) rotary table combined with a sub table to make a 1,400 x 3,000 mm (55.1 x 118.1 in) surface. The other small and mid-size HB models have a plain rotary table.
Long parts are the reason. A beam, a machine bed, a roll stand or a welded frame three metres long cannot sit on a square rotary table without hanging off both ends. On the C table it is supported along its length and machined from the front in one pass of the 3,000 mm (118.1 in) X travel. Shorter parts still go on the rotary section for four-face work with 0.001° indexing.
Load on the rotary table is 7,000 kg (15,432 lb), with 9,000 kg (19,841 lb) in braces. That is the HB-130S rating, well under the 12,000 kg (26,455 lb) of the HB-130, so the C model trades rotary capacity for length. The page does not say what the sub table carries.
Travels and spindle are those of the HB-130: Y 2,000 mm (78.7 in) with 2,300 mm (90.6 in) in braces, Z 1,300 mm (51.2 in) with 1,600 mm (63.0 in) in braces, W 700 mm (27.6 in), a Ø130 mm (5.1 in) ISO 50 spindle at 5 to 2,500 rpm and 22/26 kW (29.5/34.9 hp) cont/30min. Rotation is 1.4 rpm. Fanuc 31i-B and Siemens 840D are listed.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 3,000 mm (118.1 in) |
| Y Axis Travel | 2,000 mm (78.7 in) {2,300 mm (90.6 in)} |
| Z Axis Travel | 1,300 mm (51.2 in) {1,600 mm (63.0 in)} |
| W Axis Travel | 700 mm (27.6 in) |
| Table Size | 1,400 x 3,000 mm (55.1 x 118.1 in) |
| Rotary Table Size | 1,400 x 1,400 mm (55.1 x 55.1 in) |
| Table Indexing | 0.001° (every 90° indexing by locate pin) |
| Table Type | Rotary + Sub table |
| Max Rotary Table Load | 7,000 kg (15,432 lb) {9,000 kg (19,841 lb)} |
| Table Rotation Speed | 1.4 rpm |
| Spindle Diameter | Ø130 mm (5.1 in) |
| Spindle Speed Range | 5 ~ 2,500 rpm |
| Spindle Taper | ISO 50 |
| Spindle Motor Power | 22/26 kW (29.5/34.9 hp) {30/35 kW (40.2/46.9 hp)} (cont/30min) |
| CNC Control | Fanuc 31i-B, Siemens 840D |
Specifications sourced from en.hnkkorea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Rotary + Sub table giving a 1,400 x 3,000 mm (55.1 x 118.1 in) table
- Table length matches the 3,000 mm (118.1 in) X travel
- 1,400 x 1,400 mm (55.1 x 55.1 in) rotary section with 0.001° indexing
- Same Ø130 mm (5.1 in) spindle and travels as the HB-130
Limitations
- Rotary table load is 7,000 kg (15,432 lb), below the 12,000 kg (26,455 lb) of the HB-130
- Sub table capacity is not stated on the maker's page
- Rotary section is smaller than the 1,600 x 1,800 mm table of the HB-130
Best For
Frequently Asked Questions
01
It is the table type HNK lists for this model. The table row gives 1,400 x 3,000 mm (55.1 x 118.1 in) overall and the rotary table row 1,400 x 1,400 mm (55.1 x 55.1 in). The page offers no further description, so ask HNK how the two sections are arranged and whether the sub table moves with X.
02
The maximum load on the rotary table is 7,000 kg (15,432 lb), with 9,000 kg (19,841 lb) in braces. No separate figure is given for a long part resting on both the rotary and the sub table.
03
The HB-130CX is the longer version: a 1,600 x 4,000 mm (63.0 x 157.5 in) table, a 1,600 x 1,600 mm (63.0 x 63.0 in) rotary section, 4,000 mm (157.5 in) of X and 10,000 kg (22,046 lb) on the rotary table. The HB-130C has 3,000 mm (118.1 in) of X.
04
The Ø130 mm (5.1 in) spindle common to the HB-130 group: ISO 50 taper, 5 to 2,500 rpm and a 22/26 kW (29.5/34.9 hp) motor, with 700 mm (27.6 in) of W-axis travel.
