Fidia Linea M6
Image: fidia.it, Fidia
Key Specifications
Max Spindle
Spindle Taper
Spindle Power
x axis travel
y axis travel
z axis travel
How much does the Fidia Linea M6 cost?
Price estimate
We do not have a price for the Fidia Linea M6 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Fidia Linea M6 is the long version of Fidia's mould and tooling gantry: 6,200 mm (244 in) of X, 3,000 mm (118 in) of Y and 1,250 mm (49 in) of Z, in 5 axes.
This is the size Fidia points at sheet metal stamping. Large stamping tools are long, heavy and finished over wide, gently curved surfaces, which is where a gantry earns its place: the tool sits still on a cast iron worktable anchored to the foundation and only the gantry moves. Clearance under the head can be adapted to production needs.
Surface finishing over that area is a matter of time. X and Y run at 60 m/min, and Fidia describes the linear motor drives as high in dynamics and free of maintenance. Z is slower at 30 m/min. The spindles are the same as on the smaller sizes: 55 kW and 88 Nm on HSK-A63 at 24,000 1/min or 20,000 1/min, or 65 kW and 124 Nm on HSK-A100 at 15,000 1/min or 12,000 1/min.
Heads are the M5A, with A travel of +95° ÷ -110°, or the symmetrical M5S, with ±110°. For anything longer, look at the GTF/R, whose X travel is listed up to 19,600 mm (772 in).
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 6,200 mm (244 in) |
| Y Axis Travel | 3,000 mm (118 in) |
| Z Axis Travel | 1,250 mm (49 in) |
| Axis Speed | 60/60/30 m/min (X/Y/Z) |
| Milling Heads | M5A or M5S bi-rotary head |
| M5a Axis Travel | A: +95° ÷ -110°; C: ±360° |
| M5s Axis Travel | A: ±110°; C: ±360° |
| Max Spindle Speed | 24,000 1/min or 20,000 1/min (55 kW spindles); 15,000 1/min or 12,000 1/min (65 kW spindles) |
| Spindle Motor Power | 55 kW or 65 kW |
| Spindle Torque | 88 Nm (55 kW spindles); 124 Nm (65 kW spindles) |
| Spindle Taper | HSK-A63 (55 kW spindles); HSK-A100 (65 kW spindles) |
| CNC Control | Fidia or Siemens control |
Specifications sourced from fidia.it — verified 2026-10-05
Strengths & Limitations
Strengths
- 6,200 mm (244 in) of X for large tooling on a stationary worktable
- Linear motor technology that Fidia describes as high dynamics and no maintenance
- Clearance under the head can be adapted through the separate cast iron worktable
- Available with a Fidia or a Siemens control
- M5S head option with tandem dual motors and hydraulic brakes
Limitations
- Y travel stays at 3,000 mm (118 in) however long the X axis
- Finishing-oriented spindle list: at most 65 kW and 124 Nm
- Anchoring the worktable to the foundation means civil work along more than 6,200 mm (244 in)
- Vertical travel is 1,250 mm (49 in), at 30 m/min
Best For
Frequently Asked Questions
01
02
Fidia says the larger Linea M versions are well-suited for the sheet metal stamping field, and this is the largest. Note that the line is presented for semi-finishing and finishing, with a highest listed spindle torque of 124 Nm.
03
The gantry. The worktable is cast iron, independent from the side walls and anchored to the foundation, so the workpiece stays still while the axes move above it at 60 m/min in X and Y and 30 m/min in Z. Versions with a monolithic base are also available.
04
The M5A head (A travel +95° ÷ -110°) or the M5S head (A travel ±110°), both with ±360° on C. Spindles are 55 kW with 88 Nm on HSK-A63 at 24,000 1/min or 20,000 1/min, or 65 kW with 124 Nm on HSK-A100 at 15,000 1/min or 12,000 1/min.
