Litz VC-600
Image: litzhitech.com, Litz
Key Specifications
Max Spindle
Tool Capacity
Table Size
Spindle Power
x axis travel
y axis travel
How much does the Litz VC-600 cost?
Price estimate
We do not have a price for the Litz VC-600 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Litz VC-600 is the entry model of the VC vertical machining center series, with travels of 610 mm (24.0 in) in X, 410 mm (16.1 in) in Y and 540 mm (21.3 in) in Z and a belt-driven 10,000 rpm BT-40 spindle.
Belt drive is the theme of the VC range. It keeps the spindle simple to service and gives a useful torque band for everyday milling and drilling, at the expense of top speed. Buyers who want more can choose from the option list: a 12,000 rpm belt spindle, or direct-drive spindles at 12,000 rpm and 15,000 rpm. The built-in spindles offered on larger VC models are not listed for the VC-600.
Everything is scaled to light work. The motor is 5.5 / 7.5 kW (7.4 / 10.1 hp), the axis motors are 1.6 / 1.6 / 3.0 kW, the table is 700 x 400 mm (27.6 x 15.7 in) and it carries 350 kg (772 lb). T-slots are 14 mm wide, narrower than the 18 mm used from the VC-800A upward. Tool length is limited to 200 mm (7.9 in).
Rapids are 36 / 36 / 24 m/min (1,417 / 1,417 / 945 ipm). The standard control is the FANUC 0iMF-Plus, with Mitsubishi M80 and Siemens 828D as options. Note what is not included: the chip conveyor and even the chip cart are options on this series. Weight is 4,200 kg (9,259 lb) and supply 15 kVA.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 610 mm (24.0 in) |
| Y Axis Travel | 410 mm (16.1 in) |
| Z Axis Travel | 540 mm (21.3 in) |
| Distance Spindle Nose to Table | 100 to 640 mm (3.9 to 25.2 in) |
| Max Spindle Speed | 10,000 rpm |
| Tool Capacity | 24 |
| Max Tool Diameter (full magazine) | 80 / 125 mm (3.1 / 4.9 in) |
| Max Tool Length | 200 mm (7.9 in) |
| Max Tool Weight | 7 kg (15 lb) |
| Tool Change Method | ARM |
| Tool Shank | BT-40 |
| Spindle Motor Power | 5.5 / 7.5 kW (7.4 / 10.1 hp) |
| Axis Motors Xyz | 1.6 / 1.6 / 3.0 kW |
| Table Size | 700 x 400 mm (27.6 x 15.7 in) |
| Max Table Load | 350 kg (772 lb) |
| T-Slots | 5 x 14 x 63 mm |
| Cutting Feed Rate | 1-20,000 mm/min (up to 787 ipm) |
| Machine Weight | 4,200 kg (9,259 lb) |
| Power Requirement | 15 kVA |
| Coolant Tank Capacity | 200 L |
| Compressed Air | 6 kg/cm² |
| Rapid Traverse Xyz | 36 / 36 / 24 m/min (1,417 / 1,417 / 945 ipm) |
Specifications sourced from litzhitech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Compact 610 x 410 x 540 mm envelope at 4,200 kg (9,259 lb) and 15 kVA
- Belt-driven 10,000 rpm BT-40 spindle, with 12,000 rpm and 15,000 rpm direct-drive options
- FANUC 0iMF-Plus as standard; Mitsubishi M80 and Siemens 828D optional
- 36 / 36 / 24 m/min (1,417 / 1,417 / 945 ipm) rapids
Limitations
- 5.5 / 7.5 kW (7.4 / 10.1 hp) motor limits metal removal
- Chip conveyor and chip cart are both options
- Tool length capped at 200 mm (7.9 in)
- 350 kg (772 lb) table load and 14 mm T-slots
Best For
Frequently Asked Questions
01
610 mm (24.0 in) in X, 410 mm (16.1 in) in Y and 540 mm (21.3 in) in Z. The table is 700 x 400 mm (27.6 x 15.7 in) with a 350 kg (772 lb) load limit, and the spindle nose is 100 to 640 mm (3.9 to 25.2 in) above it.
02
A belt-driven BT-40 spindle at 10,000 rpm with a 5.5 / 7.5 kW (7.4 / 10.1 hp) motor. A 12,000 rpm belt spindle and direct-drive spindles at 12,000 rpm and 15,000 rpm are listed as options.
03
The accessory list marks the FANUC 0iMF-Plus as standard and lists Mitsubishi M80 and Siemens 828D as options. A 4th axis rotating table and an oil mist collector are also optional.
04
No. The standard chip removal items are a chip auger inside the machine, a coolant gun, an air gun and fully-covered sheet metal. The chip conveyor, chip cart and wash down device are options.
