Yamazaki Mazak Vertical Machining Centers

Mazak VC-Ez 26

$90,000 - $135,000 Updated 2026-03-19

Key Specifications

X Travel

1,000 mm (39.4 in)

Y Travel

510 mm (20.1 in)

Z Travel

510 mm (20.1 in)

Max Spindle

12,000 RPM

Spindle Taper

CAT No. 40

Tool Capacity

20 (arm-type ATC)

Overview

The Mazak VC-Ez 26 is a larger-envelope model in the VC-Ez entry-level vertical machining center series, offering more work envelope than the popular VC-Ez 20 while maintaining the same accessible price philosophy. Built at Mazak's Florence, Kentucky facility, the 26 targets shops that regularly run parts too large for a 30-inch-class VMC but do not need the full size or cost of a VCN-series machine.

Axis travels measure 1,000 x 510 x 510 mm (39.4 x 20.1 x 20.1 in), providing roughly 70% more volume than the VC-Ez 20. The table measures 1,400 x 610 mm (55.1 x 24.0 in) with a maximum load of 600 kg (1,323 lb), accommodating larger fixtures and multi-part setups. The 12,000 RPM CAT No. 40 spindle produces 15 kW (20 hp), a step up from the 11 kW on the smaller VC-Ez models to match the demands of a larger work envelope.

The 20-station arm-type ATC delivers fast tool changes, and rapid traverse hits 36 m/min on all axes via the MX Hybrid Roller Guideway system. Thermal Shield technology compensates for thermal drift during extended runs. The increased Y-travel of 510 mm gives meaningfully more room for tombstone-style fixtures and wider parts than the 410 mm on the VC-Ez 20.

The MAZATROL SmoothEz CNC with 15-inch touchscreen provides conversational programming and EIA/ISO G-code support. The control includes 3D simulation for program verification before first cuts. Optional through-spindle coolant, probing packages, and chip conveyors round out the configuration options.

New VC-Ez 26 machines price between $90,000 and $135,000. The machine competes with the Haas VF-3, Doosan DNM 5700, and Brother Speedio H630Xd1 in the mid-size VMC segment.

Full Specifications

Parameter	Value
X-Axis Travel	1,000 mm (39.4 in)
Y-Axis Travel	510 mm (20.1 in)
Z-Axis Travel	510 mm (20.1 in)
Max Spindle Speed	12,000 RPM
Spindle Taper	CAT No. 40
Spindle Motor Power	15 kW (20 hp)
Tool Capacity	20 (arm-type ATC)
Table Size	1,400 x 610 mm (55.1 x 24.0 in)
Max Table Load	600 kg (1,323 lb)
Rapid Traverse Rate	36 m/min (1,417 ipm)
CNC Control	MAZATROL SmoothEz CNC
Guide Type	MX Hybrid Roller Guideway (all axes)
Thermal Compensation	Thermal Shield
Machine Weight	5,200 kg (11,464 lb) approx.
Manufactured In	Florence, Kentucky, USA

Specifications sourced from mazakusa.com — verified 2026-03-28

Strengths & Limitations

Strengths

39.4-inch X-travel and 20.1-inch Y-travel provide a much larger work envelope than the VC-Ez 20 while staying in the entry-level price range
15 kW (20 hp) spindle offers more cutting power than the smaller VC-Ez 16 and 20 models for machining larger steel parts
1,400 x 610 mm table accommodates wider fixtures, multi-part setups, and tombstone configurations
600 kg table load supports heavier workpieces and fixtures than the smaller VC-Ez models
MAZATROL SmoothEz with 3D simulation and conversational programming keeps setup times short for varying part mixes
Thermal Shield compensation maintains dimensional accuracy through long production runs

Limitations

15 kW spindle is still modest compared to VCN-530C (18.5 kW) and VCN-600 (22 kW) for heavy roughing applications
20-tool magazine may limit complex parts; no expanded magazine option unlike the VCN series with 48+ tools
Entry-level construction trades some rigidity compared to the heavier VCN and VCE box-way machines
SmoothEz control lacks the full feature set of SmoothG and SmoothAi found on higher-end Mazak machines

Best For

Job shops regularly running parts in the 20-to-36-inch range that exceed the capacity of 30-inch-class VMCs Contract manufacturers needing a mid-size VMC with Mazak quality and support at an accessible price point Shops machining aluminum and mild steel structural components, housings, and plates in moderate volumes Manufacturers wanting to step up from entry-level VMCs to a larger envelope without jumping to VCN pricing Multi-part fixture shops that benefit from the wider table and higher load capacity

Frequently Asked Questions

01 What does a new Mazak VC-Ez 26 cost?

New VC-Ez 26 machines start around $90,000 for base configurations and reach $135,000 with options like through-spindle coolant, probing, and chip conveyor. This positions it between the VC-Ez 20 and the production-grade VCN-530C in Mazak's lineup.

02 How does the VC-Ez 26 compare to the Haas VF-3?

Both offer roughly 40-inch X-travel in a similar price range. The Haas VF-3 provides more spindle power (22.4 kW vs 15 kW) and a proven aftermarket. The VC-Ez 26 counters with MAZATROL conversational programming, arm-type ATC, roller guide construction, and Thermal Shield compensation.

03 What is the difference between the VC-Ez 26 and VC-Ez 26X?

The VC-Ez 26 is a 3-axis vertical machining center. The VC-Ez 26X adds a trunnion-style rotary table for 5-axis capability (A and C axes), different control (SmoothEz5), and a circular table instead of a rectangular one. The 26X costs significantly more.

04 Can the VC-Ez 26 handle steel and cast iron?

Yes. The 15 kW spindle handles moderate cuts in mild steel, alloy steels, and cast iron. For aggressive roughing and heavy interrupted cuts in harder materials, the VCN or VCE series with more power and rigidity would be better suited.
