Litz VC-1400A(B)
Image: litzhitech.com, Litz
Key Specifications
Max Spindle
Tool Capacity
Table Size
Spindle Power
x axis travel
y axis travel
How much does the Litz VC-1400A(B) cost?
Price estimate
We do not have a price for the Litz VC-1400A(B) that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Litz VC-1400A(B) begins the large half of the VC vertical machining center series. Travels are 1,400 mm (55.1 in) in X, 800 mm (31.5 in) in Y and 740 mm (29.1 in) in Z, over a 1,500 x 800 mm (59.1 x 31.5 in) table that carries 1,600 kg (3,527 lb).
Y travel is the headline. Going from the VC-1200A(B) to this model adds some X but takes Y from the 600 mm of the VC-1200A(B) to 800 mm, so the machine suits parts that are wide and square, not only long. The table is as deep as the Y stroke, which means the whole surface can be machined.
As with the other bracketed VC models, the column gives two sets of spindle figures. Unbracketed: 10,000 rpm, BT-40, 30 tools, 7 kg (15 lb) per tool, 14,500 kg (31,966 lb). Bracketed: 6,000 rpm, BT-50, 24 tools, 15 kg (33 lb) per tool, 15,000 kg (33,069 lb). The motor is 15 / 18.5 kW (20.1 / 24.8 hp) in both cases. The accessory list is filled in for the BT-40 arrangement, with a 30T arm type magazine as standard and a 40T as an option.
Rapids are 20 / 20 / 20 m/min (787 / 787 / 787 ipm), and feed is programmable to 20,000 mm/min. Tools can be 300 mm (11.8 in) long. Supply is 42 kVA with a 500 L coolant tank.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 1,400 mm (55.1 in) |
| Y Axis Travel | 800 mm (31.5 in) |
| Z Axis Travel | 740 mm (29.1 in) |
| Distance Spindle Nose to Table | 100 to 840 mm (3.9 to 33.1 in) |
| Max Spindle Speed | 10,000 rpm; in brackets: 6,000 rpm |
| Tool Capacity | 30; in brackets: 24 |
| Max Tool Diameter (full magazine) | 85 / 150 mm (3.3 / 5.9 in) |
| Max Tool Length | 300 mm (11.8 in) |
| Max Tool Weight | 7 kg (15 lb); in brackets: 15 kg (33 lb) |
| Tool Change Method | ARM |
| Tool Shank | BT-40(BT-50) |
| Spindle Motor Power | 15 / 18.5 kW (20.1 / 24.8 hp) |
| Axis Motors Xyz | 4 / 4 / 4 kW |
| Table Size | 1,500 x 800 mm (59.1 x 31.5 in) |
| Max Table Load | 1,600 kg (3,527 lb) |
| T-Slots | 7 x 18 x 100 mm |
| Cutting Feed Rate | 1-20,000 mm/min (up to 787 ipm) |
| Machine Weight | 14,500 kg (31,966 lb); in brackets: 15,000 kg (33,069 lb) |
| Power Requirement | 42 kVA |
| Coolant Tank Capacity | 500 L |
| Compressed Air | 6 kg/cm² |
| Rapid Traverse Xyz | 20 / 20 / 20 m/min (787 / 787 / 787 ipm) |
Specifications sourced from litzhitech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 800 mm (31.5 in) of Y travel with a 1,500 x 800 mm (59.1 x 31.5 in) table
- 1,600 kg (3,527 lb) table load
- 15 / 18.5 kW (20.1 / 24.8 hp) spindle motor
- 30T magazine standard in the BT-40 arrangement, 40T optional
- Up to 840 mm (33.1 in) from spindle nose to table
Limitations
- Rapids of 20 / 20 / 20 m/min (787 / 787 / 787 ipm)
- Two spindle versions share one column of the table; figures must be confirmed per machine
- 42 kVA supply and at least 14,500 kg (31,966 lb) of machine weight
- Chip conveyor and chip cart are options
Best For
Frequently Asked Questions
01
1,400 mm (55.1 in) in X, 800 mm (31.5 in) in Y and 740 mm (29.1 in) in Z. Spindle nose to table distance is 100 to 840 mm (3.9 to 33.1 in), and the table is 1,500 x 800 mm (59.1 x 31.5 in).
02
The table gives 10,000 rpm with BT-40 as the first figures and 6,000 rpm with BT-50 in brackets. Both are listed with a 15 / 18.5 kW (20.1 / 24.8 hp) motor. Tool weight is 7 kg (15 lb), or 15 kg (33 lb) in brackets.
03
The table gives 30 tools, and 24 as the bracketed figure. The accessory list marks a 30T arm type magazine as standard and a 40T arm type magazine as an option.
04
14,500 kg (31,966 lb), with 15,000 kg (33,069 lb) given in brackets. The power requirement is 42 kVA and the coolant tank holds 500 L.
