AWEA VP-5012HS
Image: awea.com, AWEA
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
x axis travel
How much does the AWEA VP-5012HS cost?
Price estimate
We do not have a price for the AWEA VP-5012HS that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Five metres is the end of the line for the VP-HS series. The AWEA VP-5012HS has 5,000 mm (196.9 in) of X travel, a 5,000 x 1,100 mm (196.9 x 43.3 in) table and the highest load rating of the five models at 8,000 kg (17,637 lb). It also weighs the most: 28,000 kg (61,728 lb).
Think of it as a long-bed machine that happens to carry a fast spindle. The head is the series unit, direct-driven to 10,000 rpm with a BBT50 taper and 22 / 26 kW (29.5 / 34.9 hp), yet the X axis that feeds work under it is limited to 8 m/min (315 ipm) for both rapid and cutting feed. Y at 24 m/min (945 ipm) moves three times as fast. Toolpaths should be planned around that: long passes down the bed, stepovers in Y, and as few end-to-end returns as the part allows.
Tolerances are the widest in the range. By VDI the machine lists P ≤ 0.04 mm positioning over full travel and Ps ≤ 0.03 mm repeatability, against P ≤ 0.03 mm and Ps ≤ 0.02 mm for the VP-4012HS. Shops finishing mold surfaces to tight limits will usually be better served by a shorter model. This one earns its place on parts that cannot be cut anywhere smaller.
The cross section is no bigger than on the VP-1612HS at the short end of the series. Y travel is 1,200 mm (47.2 in), Z is 760 mm (29.9 in), and the columns are 1,300 mm (51.2 in) apart. Work that is wide as well as long does not fit this series at any length. The plain VP range does continue past this length with the VP-6012, at 6,000 mm (236.2 in).
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 5,000 mm (196.9 in) |
| Y Axis Travel | 1,200 mm (47.2 in) |
| Z Axis Travel | 760 mm (29.9 in) |
| Table Size | 5,000 x 1,100 mm (196.9 x 43.3 in) |
| Max Table Load | 8,000 kg (17,637 lb) |
| Distance Spindle Nose to Table | 200 ~ 960 mm (7.9 ~ 37.8 in) |
| Distance Between Columns | 1,300 mm (51.2 in) |
| Spindle Taper | BBT50 (Opt. BBT40) |
| Spindle Motor Power | 22 / 26 kW (29.5 / 34.9 hp) |
| Max Spindle Speed | Direct-driven spindle 10,000 rpm |
| Rapid Traverse X | 8 m/min (315 ipm) |
| Rapid Traverse Y | 24 m/min (945 ipm) |
| Rapid Traverse Z | 20 m/min (787 ipm) |
| Cutting Feed Rate | 8 m/min (315 ipm) |
| Tool Capacity | 32 T (Opt. 24 / 40 T) |
| Max Tool Diameter (full magazine) | Ø125 / Ø229 mm (Ø4.9 / Ø9.0 in) |
| Max Tool Length | 350 mm (13.8 in) |
| Max Tool Weight | 15 kg (33 lb) |
| Positioning Accuracy Jis B 6338 | ± 0.010 mm / Full Travel |
| Positioning Accuracy VDI 3441 | P ≤ 0.04 mm / Full Travel |
| Repeatability Jis B 6338 | ± 0.003 mm |
| Repeatability VDI 3441 | Ps ≤ 0.03 mm |
| Power Requirement | AC 220 ± 10 % 3 , 60 / 50 Hz / 40 kVA |
| Air Pressure Requirement | 5 ~ 7 kg/cm² |
| Lubrication Tank Capacity | 4.5 liter |
| Hydraulic Tank Capacity | 400 liter (1 HP) |
| Machine Weight | 28,000 kg (61,728 lb) |
Specifications sourced from awea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 5,000 mm (196.9 in) of X travel, the longest in the VP-HS series
- Table rated for 8,000 kg (17,637 lb)
- 10,000 rpm direct-driven spindle with 22 / 26 kW (29.5 / 34.9 hp) on a bed of this length
- Y and Z rapids remain 24 m/min (945 ipm) and 20 m/min (787 ipm)
- Power requirement of 40 kVA, no higher than the smaller VP-HS machines
Limitations
- X rapid and cutting feed both stop at 8 m/min (315 ipm)
- VDI positioning of P ≤ 0.04 mm over full travel, the loosest of the series
- Only 1,100 mm (43.3 in) of table width for 5,000 mm (196.9 in) of length
- 28,000 kg (61,728 lb) of machine to transport, lift and found
- No HS model beyond this length; the VP-6012 is the next step in X
Best For
Frequently Asked Questions
01
02
Measured the VDI way, the table gives positioning of P ≤ 0.04 mm over full travel and repeatability of Ps ≤ 0.03 mm. Measured the JIS way, it gives ± 0.010 mm over full travel and ± 0.003 mm. The VDI rows widen with every size step above the VP-3012HS; the JIS rows are printed the same for all five models.
03
Not within the VP-HS series, which ends at this model. The VP-6012 extends X to 6,000 mm (236.2 in) and is listed with a direct drive spindle of 10,000 rpm and 22 / 26 kW (29.5 / 34.9 hp), and its table load is 5,000 kg (11,023 lb), lower than the 8,000 kg (17,637 lb) here.
04
A foundation for 28,000 kg (61,728 lb) plus up to 8,000 kg (17,637 lb) on the table, an electrical supply of AC 220 ± 10 % at 60 / 50 Hz with 40 kVA, and air at 5 ~ 7 kg/cm². The hydraulic tank is listed at 400 liter (1 HP) and the lubrication tank at 4.5 liter.
