Vision Wide VBT-110-1416
Image: visionwide-tech.com, Vision Wide
Key Specifications
Max Spindle
Table Size
x axis travel
y axis travel
z axis travel
w axis travel
How much does the Vision Wide VBT-110-1416 cost?
Price estimate
We do not have a price for the Vision Wide VBT-110-1416 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The spindle of the Vision Wide VBT-110-1416 comes down to the table. The row for spindle center to table surface begins at 0: it reads 0~1,600 mm, or 0~2,000 mm with the optional Y travel.
A horizontal spindle that reaches table level can machine features at the very bottom of a part, such as the feet and lower bores of a gearbox housing, without packing the part up on risers. Risers raise the load, reduce stiffness and use up Y travel, so a machine that does not need them is easier to set up for low features.
Vision Wide describes the VBT series as a Y-axis box way structure design. The vertical axis carries the headstock and takes the full cutting reaction in boring, and box ways there mean sliding contact with good damping.
The table is 1,400 x 1,600 mm (55.1 x 63.0 in), rated at 6,000 kg with 10,000 kg (22,046 lb) as an option, in the central area. X is 2,000 mm, or 2,500 mm, Z is 1,500 mm (59.1 in) and W is 550 mm (21.7 in). The spindle gives 972 / 1,155 Nm (717 / 852 lb-ft) and runs to 3,500 rpm. The VBH-110-1416 prints the same figures for a box in box machine.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 2,000 / 2,500 mm (78.7 / 98.4 in) (Opt.) |
| Y Axis Travel | 1,600 / 2,000 mm (63.0 / 78.7 in) (Opt.) |
| Z Axis Travel | 1,500 mm (59.1 in) |
| W Axis Travel | 550 mm (21.7 in) |
| Table Size | 1,400 x 1,600 mm (55.1 x 63.0 in) |
| Max Table Load Central Area | 6,000 / 10,000 kg (13,228 / 22,046 lb) (Opt.) |
| Distance Spindle Nose to Table Center | -25~525~2,025 mm (-1.0~20.7~79.7 in) |
| Distance Spindle Center to Table Surface | 0~1,600 / 0~2,000 mm (0~63.0 / 0~78.7 in) (Opt.) |
| Max Spindle Speed | 3,500 rpm |
| Spindle Power Cont 30 Min | 18.5 / 22 kW (24.8 / 29.5 hp) |
| Spindle Torque Cont 30 Min | 972 / 1,155 Nm (717 / 852 lb-ft) |
Specifications sourced from visionwide-tech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Spindle center travels from table surface level up to 1,600 mm, or 2,000 mm optional
- Box ways on the Y axis for damping under boring loads
- 1,400 x 1,600 mm (55.1 x 63.0 in) table
- Optional table load of 10,000 kg (22,046 lb)
Limitations
- Standard table load is 6,000 kg
- Z travel of 1,500 mm (59.1 in) has no optional extension in the 110 class
- The maker's page gives no accuracy figures
Best For
Frequently Asked Questions
01
To table level. The distance from spindle center to table surface is listed as 0~1,600 / 0~2,000 mm (0~63.0 / 0~78.7 in) (Opt.), the longer range going with the optional Y travel.
02
6,000 / 10,000 kg (13,228 / 22,046 lb) (Opt.) in the central area. The table is 1,400 x 1,600 mm (55.1 x 63.0 in).
03
X is 2,000 / 2,500 mm (78.7 / 98.4 in) (Opt.), Y is 1,600 / 2,000 mm (63.0 / 78.7 in) (Opt.), Z is 1,500 mm (59.1 in) and W is 550 mm (21.7 in).
04
The specification tables are the same. The difference stated by Vision Wide is the structure: Y-axis box way for the VBT, box in box for the VBH.
