Litz VB-1300B/BG

Q: How much does the Litz VB-1300B/BG cost?

The price estimate for the Litz VB-1300B/BG is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/litz-vb-1300b-bg#price; the request is passed to Litz or an authorised dealer.

Specs verified 2026-10-04 · litzhitech.com Updated 2026-10-04

Litz VB series vertical machining center (VB-1300B/BG)

Image: litzhitech.com, Litz

Key Specifications

Max Spindle

10,000 rpm (B) / 8,000 rpm (BG)

Tool Capacity

Table Size

1,500 x 600 mm (59.1 x 23.6 in)

x axis travel

1,300 mm (51.2 in)

y axis travel

610 mm (24.0 in)

z axis travel

600 mm (23.6 in)

How much does the Litz VB-1300B/BG cost?

Price estimate

Uncertain

We do not have a price for the Litz VB-1300B/BG that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Litz VB-1300B/BG is the longer of the two VB vertical machining centers. It offers 1,300 mm (51.2 in) of X travel with 610 mm (24.0 in) of Y and 600 mm (23.6 in) of Z, a BT-50 spindle, and a 1,500 x 600 mm (59.1 x 23.6 in) table.

The comparison with the VB-1100B/BG is short. X travel and table length each grow by the same step. Against the VB-1100B/BG at 9,600 kg and 416 L of coolant, this model weighs 10,000 kg (22,046 lb) and carries 450 L. Table load is 1,000 kg (2,205 lb) on both, and so are Y, Z, rapids and the tool changer.

So the question is whether the parts are long. Bars, beams, long die plates and rail-shaped castings are the natural work. Because the Y travel and the 600 mm table depth match, long narrow workpieces sit fully inside the cutting zone, and the working area is listed as 1,300 x 600 mm (51.2 x 23.6 in).

Spindle speed depends on the version: 10,000 rpm for the B, 8,000 rpm for the BG. Thirty BT-50 tools are carried, each up to 15 kg (33 lb). The spindle centre is 660 mm (26.0 in) from the Z rail surface, a deep throat that goes with the 610 mm Y stroke. Standard equipment includes the chip conveyor and coolant cooling system. FANUC 0i MF is the control and supply is 25 kVA.

Full Specifications

Parameter	Value
X Axis Travel	1,300 mm (51.2 in)
Y Axis Travel	610 mm (24.0 in)
Z Axis Travel	600 mm (23.6 in)
Distance Spindle Nose to Table	125 to 725 mm (4.9 to 28.5 in)
Spindle Center to Z Rail Surface	660 mm (26.0 in)
Table Height From Floor	988 mm (38.9 in)
Max Spindle Speed	10,000 rpm (B) / 8,000 rpm (BG)
Tool Capacity	30
Max Tool Length	305 mm (12.0 in)
Max Tool Weight	15 kg (33 lb)
Tool Change Method	ARM
Tool Shank	BT-50
Table Size	1,500 x 600 mm (59.1 x 23.6 in)
Max Table Load	1,000 kg (2,205 lb)
Working Area	1,300 x 600 mm (51.2 x 23.6 in)
T-Slots	5 x 18 mm x 100 mm (number x width x distance from the center)
CNC Control	FANUC 0i MF
Machine Weight	10,000 kg (22,046 lb)
Coolant Tank Capacity	450 L
Power Requirement	25 kVA
Compressed Air	6 kg/cm²
Rapid Traverse Xyz	30 / 30 / 24 m/min (1,181 / 1,181 / 945 ipm)

Specifications sourced from litzhitech.com — verified 2026-10-04

Strengths & Limitations

Strengths

1,300 mm (51.2 in) of X travel with BT-50 tooling
30 tools up to 15 kg (33 lb) each
Working area of 1,300 x 600 mm (51.2 x 23.6 in)
Chip conveyor, chip cart and coolant cooling system are standard
450 L coolant tank, against 416 L on the VB-1100B/BG

Limitations

Table load stays at 1,000 kg (2,205 lb), the same as the VB-1100B/BG
Spindle motor rating is not stated in the table
Y travel of 610 mm (24.0 in) is unchanged from the shorter model
Linear scales are optional

Best For

Long die plates, beams and rail-shaped castings BT-50 roughing over a 1,300 mm stroke Heavy cutting of parts up to 1,000 kg (2,205 lb)

Frequently Asked Questions

01 How long is the X travel of the Litz VB-1300B/BG?

1,300 mm (51.2 in). Y travel is 610 mm (24.0 in), Z travel is 600 mm (23.6 in), and spindle nose to table distance is 125 to 725 mm (4.9 to 28.5 in).

02 How does the VB-1300B/BG compare with the VB-1100B/BG?

The VB-1300B/BG has a 1,500 x 600 mm table and weighs 10,000 kg (22,046 lb). The VB-1100B/BG has a 1,300 x 600 mm table and weighs 9,600 kg (21,164 lb). Spindle, magazine, rapids and the 1,000 kg (2,205 lb) table load are the same.

03 What spindle speeds does the VB-1300B/BG offer?

10,000 rpm on the B version and 8,000 rpm on the BG version. Both take BT-50 tooling. A spindle oil cooling system and dust-proof air-sealing system are standard, and coolant through the spindle is optional.

04 What control does the VB-1300B/BG use?

FANUC 0i MF is named in the specification table and FANUC is the standard control in the accessory list. Mitsubishi M80 and Siemens 828D are available as options.
