Johnford ST-60BX
Key Specifications
Max Spindle
Rapid Traverse
Spindle Power
swing over bed
swing over cross slide
chuck size
How much does the Johnford ST-60BX cost?
Price estimate
We do not have a price for the Johnford ST-60BX that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Johnford ST-60BX has 420 mm (16.5 in) of X travel on a 1,200 mm (47.2 in) bed, with an A2-11 spindle and 1,020 mm (40.2 in) of swing over the bed.
Long cross travel is useful beyond large diameters. It gives the turret room to bring a long boring bar onto the center line and still retract clear of a wide part, and it lets external tools reach a large rim and then drop to a small journal without repositioning the work. On a lathe that swings 800 mm (31.5 in) over the cross slide, both situations come up often.
For boring in particular, Johnford's options include a boring bar holder on the turret carriage and a completely independent boring bar system.
The spindle is the middle one of the series: 132.5 mm (5.2 in) bore, 116 mm (4.6 in) bar capacity, 2,000 rpm through four automatic speeds, and 22 / 26 kW (29.5 / 34.9 hp) or 30 / 37 kW (40.2 / 49.6 hp). Tailstock travel is 900 mm (35.4 in). Rapids are 12 m/min on X and 16 m/min on Z. The machine weighs 12,300 kg (27,060 lb) and measures 6,195 x 2,270 x 2,765 mm (243.9 x 89.4 x 108.9 in).
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 1,020 mm (40.2 in) |
| Swing Over Cross Slide | 800 mm (31.5 in) |
| Chuck Size | 381 mm (15 in) |
| Chuck Size Optional | 450 mm (17.7 in) |
| Bar Capacity | 116 mm (4.6 in) |
| Spindle Nose | A2-11 |
| Spindle Bore | 132.5 mm (5.2 in) |
| Spindle Transmission | Auto 4 speeds |
| Max Spindle Speed | 2,000 rpm |
| Spindle Motor Power | 22 / 26 kW (29.5 / 34.9 hp) (Std.); 30 / 37 kW (40.2 / 49.6 hp) (Opt.) |
| Spindle Bearing Diameter | 180 mm (7.1 in) |
| Turret Stations | 12 |
| X Axis Travel | 420 mm (16.5 in) |
| Y Axis Travel Optional | ±75 mm (±3 in) |
| Z Axis Travel | 1,200 mm (47.2 in) |
| Rapid Traverse Rate | X: 12 m/min (472 ipm); Y: 10 m/min (394 ipm); Z: 16 m/min (630 ipm) |
| Tailstock Travel | 900 mm (35.4 in) |
| Tailstock Quill Travel | 125 mm (4.9 in) |
| Tailstock Quill Diameter | Ø125 mm (Ø4.9 in) |
| Tailstock Taper | MT#5 |
| Servo Motor X | 7 kW |
| Servo Motor Y Optional | 3 kW |
| Servo Motor Z | 7 kW |
| Bed Inclination | 60° |
| Machine Weight | 12,300 kg (27,060 lb) |
| Machine Dimensions | 6,195 x 2,270 x 2,765 mm (243.9 x 89.4 x 108.9 in) |
Specifications sourced from johnford.com.tw — verified 2026-10-04
Strengths & Limitations
Strengths
- 420 mm (16.5 in) of X travel for boring bars and large rims
- 800 mm (31.5 in) swing over the cross slide
- 1,200 mm (47.2 in) of Z travel
- Boring bar holder and independent boring bar system are available
- 2,000 rpm with four automatic speeds
Limitations
- Boring bar equipment is optional
- Rapid traverse of 12 m/min on X
- Bar capacity of 116 mm (4.6 in)
- Tailstock quill of Ø125 mm (4.9 in) with MT#5
Best For
Frequently Asked Questions
01
02
A boring bar holder mounted on the turret carriage, a completely independent boring bar system and a dented space on the headstock sheet metal for boring bar clearance, all optional.
03
12,300 kg (27,060 lb). The table lists the ST-60BH at 12,200 kg (26,840 lb) and the ST-60B at 12,100 kg (26,620 lb).
04
2,000 rpm through four automatic speeds, with a 22 / 26 kW (29.5 / 34.9 hp) motor as standard and a 30 / 37 kW (40.2 / 49.6 hp) motor as an option.
