Goodway GVB-3000

Q: How much does the Goodway GVB-3000 cost?

The price estimate for the Goodway GVB-3000 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/goodway-gvb-3000#price; the request is passed to Goodway or an authorised dealer.

Specs verified 2026-10-04 · goodwaycnc.com Updated 2026-10-04

Goodway SUPER GV series super size vertical turning centers (GVB-3000)

Image: goodwaycnc.com, Goodway

Key Specifications

Spindle Taper

BT50 / BT60

Tool Capacity

Spindle Power

39 kW (52.3 hp) × 2 / 58 kW (77.8 hp) × 2 (cont.)

table diameter

Ø3,000 mm (118.1 in)

max swing diameter

Ø3,700 mm (145.7 in)

max turning diameter

Ø3,500 mm (137.8 in)

How much does the Goodway GVB-3000 cost?

Price estimate

Uncertain

We do not have a price for the Goodway GVB-3000 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Goodway GVB-3000 is the largest machine Goodway lists: a bridge-type vertical turning center with a Ø3,000 mm (118.1 in) table, Ø3,500 mm (137.8 in) of turning diameter and 20,000 kg (44,092 lb) of table load, with 45,000 kg (99,206 lb) available as an option. Maximum spindle torque is 169,700 Nm (125,171 lb-ft).

The B in the name marks a different structure from the GVH models. Goodway describes it as a W-axis four-guideway bridge type, and the long W travel shows why: the cross rail moves between 1,200 mm (47.2 in) and 2,800 mm (110.2 in) depending on the version, for turning heights from 1,600 mm (63.0 in) up to 3,200 mm (126.0 in). Ram travel is 1,500 mm (59.1 in) or 1,800 mm (70.9 in) and X travel 3,950 mm (155.5 in).

Two motors drive the table. The table lists them as 39 kW (52.3 hp) × 2 or 58 kW (77.8 hp) × 2 continuous, and 45 kW (60.3 hp) × 2 or 70 kW (93.9 hp) × 2 for 30 min. Goodway explains that the double spindle motors of the GVB series also form the Cs-axis: driving against each other they remove gear backlash and double the torque.

This is also the only model in the range with a SIEMENS SINUMERIK 840D sl control. The ram takes BT50 or BT60 tooling from a 16-tool magazine, and the optional tooling spindle is rated 15 kW (20.1 hp) continuous and 18 kW (24.1 hp) for 30 min. Swing is Ø3,700 mm (145.7 in).

Full Specifications

Parameter	Value
Table Diameter	Ø3,000 mm (118.1 in)
Max Swing Diameter	Ø3,700 mm (145.7 in)
Max Turning Diameter	Ø3,500 mm (137.8 in)
Max Turning Height	1,600 mm (63.0 in) ~ 3,200 mm (126.0 in)
Max Table Load	20,000 kg (44,092 lb) (opt. 45,000 kg (99,206 lb))
Spindle Motor Power	39 kW (52.3 hp) × 2 / 58 kW (77.8 hp) × 2 (cont.)
Spindle Power 30 Min	45 kW (60.3 hp) × 2 / 70 kW (93.9 hp) × 2 (30 min.)
Spindle Torque	169,700 Nm (125,171 lb-ft)
Tooling Spindle Power	15 kW (20.1 hp) (cont.) (opt.)
Tooling Spindle Power 30 Min	18 kW (24.1 hp) (30 min.) (opt.)
Tooling Spindle Speed Range	1 ~ 2,400 rpm (opt.)
X Axis Travel	3,950 mm (155.5 in)
Z Axis Travel	1,500 mm (59.1 in) / 1,800 mm (70.9 in)
W Axis Travel	1,200 mm (47.2 in) ~ 2,800 mm (110.2 in)
Tool Capacity	16
Spindle Taper	BT50 / BT60
CNC Control	SIEMENS SINUMERIK 840D sl

Specifications sourced from goodwaycnc.com — verified 2026-10-04

Strengths & Limitations

Strengths

Ø3,500 mm (137.8 in) turning diameter on a Ø3,000 mm (118.1 in) table
169,700 Nm (125,171 lb-ft) of maximum spindle torque from twin motors
20,000 kg (44,092 lb) table load, with 45,000 kg (99,206 lb) optional
Turning height up to 3,200 mm (126.0 in) with a bridge-type W-axis
BT50 or BT60 ram tooling and a SIEMENS SINUMERIK 840D sl control

Limitations

The 45,000 kg (99,206 lb) load rating is an option, not the base figure
The tool magazine holds 16 tools
Tooling spindle is optional, 15 kW (20.1 hp) continuous at up to 2,400 rpm
A different control from the rest of the SUPER GV series, which matters for shops standardised on one control family

Best For

Oversized, heavy workpieces for energy, shipbuilding and aerospace Parts up to Ø3,500 mm (137.8 in) and 3,200 mm (126.0 in) tall Large asymmetric parts that need very high table torque

Frequently Asked Questions

01 What is the largest part the GVB-3000 can machine?

Maximum turning diameter is Ø3,500 mm (137.8 in) and swing Ø3,700 mm (145.7 in). Maximum turning height ranges from 1,600 mm (63.0 in) to 3,200 mm (126.0 in) by version. Table load is 20,000 kg (44,092 lb), or 45,000 kg (99,206 lb) as an option.

02 How is the GVB-3000 table driven?

By two motors, listed as 39 kW (52.3 hp) × 2 or 58 kW (77.8 hp) × 2 continuous. Maximum spindle torque is 169,700 Nm (125,171 lb-ft). Goodway states that the double spindle motors eliminate gear backlash and provide double torque output in Cs-axis operation.

03 Which control does the GVB-3000 use?

The SIEMENS SINUMERIK 840D sl. It is the only model in the SUPER GV series listed with this control; the GVH-2000 and GVH-2500 use a different one.

04 What are the axis travels of the GVB-3000?

X-axis travel is 3,950 mm (155.5 in). Z-axis ram travel is 1,500 mm (59.1 in) or 1,800 mm (70.9 in). W-axis cross rail travel runs from 1,200 mm (47.2 in) to 2,800 mm (110.2 in), depending on the version ordered.
