Goodway GVH-2000

Q: How much does the Goodway GVH-2000 cost?

The price estimate for the Goodway GVH-2000 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/goodway-gvh-2000#price; the request is passed to Goodway or an authorised dealer.

Specs verified 2026-10-04 · goodwaycnc.com Updated 2026-10-04

Goodway SUPER GV series super size vertical turning centers (GVH-2000)

Image: goodwaycnc.com, Goodway

Key Specifications

Spindle Taper

BT50

Tool Capacity

Spindle Power

60 kW (80.5 hp) (cont.)

table diameter

Ø2,000 mm (78.7 in)

max swing diameter

Ø2,500 mm (98.4 in)

max turning diameter

Ø2,300 mm (90.6 in)

How much does the Goodway GVH-2000 cost?

Price estimate

Uncertain

We do not have a price for the Goodway GVH-2000 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Goodway GVH-2000 opens the SUPER GV series of very large vertical turning centers. Its Ø2,000 mm (78.7 in) table carries 10,000 kg (22,046 lb), it turns Ø2,300 mm (90.6 in), and its table drive produces 59,700 Nm (44,035 lb-ft). That torque is two and a half times the 23,900 Nm of the GVF-2023, a machine with the same table diameter.

Power rises to match. The workpiece spindle motor is rated 60 kW (80.5 hp) continuous and 75 kW (100.6 hp) for 30 min., and drives a 2-speed gear box. The table runs on a crossed roller bearing.

Height is offered in two versions. Maximum turning height is 1,700 mm (66.9 in) or 2,100 mm (82.7 in), with W-axis cross rail travel of 1,200 mm (47.2 in) or 1,600 mm (63.0 in) and ram travel of 1,200 mm (47.2 in) or 1,500 mm (59.1 in) in Z. X travel is 2,830 mm (111.4 in), which exceeds the Ø2,500 mm (98.4 in) swing and lets the ram work well past center.

Goodway describes the GVH models as having a one-piece column and structure, as distinct from the bridge-type GVB-3000. A 16-tool magazine with BT50 taper is listed, and the control is the FANUC Oi-TF Plus. Options include a tooling spindle of 11 kW (14.8 hp) continuous, a Cf-type C-axis with disk brake for the GVH, and a twin ram configuration, which Goodway says gives more freedom in process planning. The page states two different top speeds for the tooling spindle, so that figure needs confirming.

Full Specifications

Parameter	Value
Table Diameter	Ø2,000 mm (78.7 in)
Max Swing Diameter	Ø2,500 mm (98.4 in)
Max Turning Diameter	Ø2,300 mm (90.6 in)
Max Turning Height	1,700 mm (66.9 in) / 2,100 mm (82.7 in)
Max Table Load	10,000 kg (22,046 lb)
Spindle Motor Power	60 kW (80.5 hp) (cont.)
Spindle Power 30 Min	75 kW (100.6 hp) (30 min.)
Spindle Torque	59,700 Nm (44,035 lb-ft)
Tooling Spindle Power	11 kW (14.8 hp) (cont.) (opt.)
Tooling Spindle Power 30 Min	15 kW (20.1 hp) (30 min.) (opt.)
Tooling Spindle Speed Range	1 ~ 2,400 rpm (opt.)
X Axis Travel	2,830 mm (111.4 in)
Z Axis Travel	1,200 mm (47.2 in) / 1,500 mm (59.1 in)
W Axis Travel	1,200 mm (47.2 in) / 1,600 mm (63.0 in)
Tool Capacity	16
Spindle Taper	BT50
CNC Control	FANUC Oi-TF Plus

Specifications sourced from goodwaycnc.com — verified 2026-10-04

Strengths & Limitations

Strengths

59,700 Nm (44,035 lb-ft) of maximum table torque
60 kW (80.5 hp) continuous, 75 kW (100.6 hp) 30 min. workpiece spindle motor
10,000 kg (22,046 lb) table load
Turning height of 1,700 mm (66.9 in) or 2,100 mm (82.7 in) with a W-axis cross rail
Optional twin ram configuration

Limitations

Table load is the lowest of the SUPER GV series; the GVH-2500 carries 15,000 kg (33,069 lb)
The tooling spindle is optional and rated 11 kW (14.8 hp) continuous
Goodway's table and feature list disagree on the tooling spindle's top speed
The magazine holds 16 tools

Best For

Heavy castings and forgings up to 10,000 kg (22,046 lb) Tall, large-diameter parts up to 2,100 mm (82.7 in) high Energy, shipbuilding and aerospace components up to Ø2,300 mm (90.6 in)

Frequently Asked Questions

01 What is the capacity of the GVH-2000?

Table diameter Ø2,000 mm (78.7 in), swing Ø2,500 mm (98.4 in), maximum turning diameter Ø2,300 mm (90.6 in), maximum turning height 1,700 mm (66.9 in) or 2,100 mm (82.7 in), and maximum table load 10,000 kg (22,046 lb).

02 How powerful is the GVH-2000 table drive?

The motor is rated 60 kW (80.5 hp) continuous and 75 kW (100.6 hp) on the 30 min. rating. Maximum spindle torque is 59,700 Nm (44,035 lb-ft), delivered through a 2-speed gear box.

03 What travels does the GVH-2000 have?

X-axis travel is 2,830 mm (111.4 in). Z-axis travel is 1,200 mm (47.2 in) or 1,500 mm (59.1 in), and W-axis travel 1,200 mm (47.2 in) or 1,600 mm (63.0 in), according to the height version.

04 How does the GVH-2000 differ from the GVB-3000?

The GVH-2000 has a one-piece column structure and a FANUC control. The GVB-3000 is a bridge-type machine with a Ø3,000 mm (118.1 in) table, 169,700 Nm (125,171 lb-ft) of torque and a SIEMENS SINUMERIK 840D sl control.
