Feeler RG-3020
Image: feeler.com, Feeler
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
x axis travel
y axis travel
How much does the Feeler RG-3020 cost?
Price estimate
We do not have a price for the Feeler RG-3020 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Feeler RG-3020 is a gantry machining center with a five-axis head, built for high-speed machining of large aluminium parts. It is the shortest of four RG models: 3,000 mm (118.1 in) of X travel, 2,000 mm (78.7 in) of Y and 1,200 mm (47.2 in) of Z, over a 2,000 x 3,000 mm table.
Feeler calls the series the premier choice for new energy vehicle aluminum parts. The parts in question are battery trays, subframes and large structural castings: wide, shallow, thin-walled, and covered in pockets, holes and angled faces. Machining them is a matter of spindle speed and axis speed, not torque, and the specification follows. The spindle runs to 20,000 rpm with an HSK-A63 interface, and rapids are 40 m/min (1,575 ipm) on X and Y and 36 m/min (1,417 ipm) on Z.
The head is described as a high-precision five-axis head performing 3+2 positional machining on complex surfaces. That means the two rotary axes set the tool at an angle and lock, and cutting is then done with the linear axes, the right method for angled bosses and side features on a tray. The page does not claim simultaneous five-axis contouring and gives no head angles.
Table load is 5,000 kg (11,023 lb) and the magazine holds 40 tools. Feeler mentions a lightweight structural design, a spindle head balanced by a dual accumulator and nitrogen energy storage system, independent cooling for the spindle and secondary head, and a direct-drive reducer on the X axis.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 3,000 mm (118.1 in) |
| Y Axis Travel | 2,000 mm (78.7 in) |
| Z Axis Travel | 1,200 mm (47.2 in) |
| Table Size | 2,000 x 3,000 mm (78.7 x 118.1 in) |
| Max Table Load | 5,000 kg (11,023 lb) |
| Max Spindle Speed | 20,000 rpm |
| Spindle Taper | HSK-A63 |
| Rapid Traverse X | 40 m/min (1,575 ipm) |
| Rapid Traverse Y | 40 m/min (1,575 ipm) |
| Rapid Traverse Z | 36 m/min (1,417 ipm) |
| Tool Capacity | 40 |
Specifications sourced from feeler.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 20,000 rpm spindle with HSK-A63 interface for aluminium
- Five-axis head for 3+2 positional machining
- Rapids of 40 m/min (1,575 ipm) on X and Y and 36 m/min on Z
- 2,000 x 3,000 mm table with 1,200 mm (47.2 in) of Z travel
- Independent cooling systems for the spindle and secondary head
Limitations
- X travel of 3,000 mm is the shortest in the RG series
- Head rotation angles and speeds are not published
- 40 tools with no larger magazine listed
- Table load of 5,000 kg and a high-speed spindle make it unsuited to heavy steel work
Best For
Frequently Asked Questions
01
3,000 mm (118.1 in) in X, 2,000 mm (78.7 in) in Y and 1,200 mm (47.2 in) in Z. The table is listed as 2,000 x 3,000 mm with a maximum loading weight of 5,000 kg (11,023 lb).
02
Feeler says it is equipped with a high-precision five-axis head and performs 3+2 positional machining on complex surfaces. Simultaneous five-axis cutting is not mentioned on the series page.
03
A 20,000 rpm spindle with an HSK-A63 taper. The spindle and the secondary head have independent cooling systems, and the spindle head is balanced by a dual accumulator and nitrogen energy storage system.
