Feeler RG-6020
Image: feeler.com, Feeler
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
x axis travel
y axis travel
How much does the Feeler RG-6020 cost?
Price estimate
We do not have a price for the Feeler RG-6020 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Six metres of X travel puts the Feeler RG-6020 in the size class where one machine can hold two large parts end to end. X is 6,000 mm (236.2 in), Y is 2,000 mm (78.7 in), Z is 1,200 mm (47.2 in), and the table is listed as 2,000 x 6,000 mm.
That length is commonly used as two work zones. One battery tray or subframe is machined at one end while the finished part at the other end is unloaded and the next is clamped, so the 20,000 rpm spindle rarely waits for the operator. The alternative use is a single long part: rail vehicle profiles, long extrusions, aerospace stringers and similar aluminium sections.
A gantry that travels this far has to keep both sides of the bridge in step. Feeler states that the X-axis features a direct-drive reducer providing strong torque output, while the Y and Z axes use direct transmission for rigidity, and gives rapid traverse speeds of 40 / 40 / 36 m/min for X / Y / Z. The rate is the same on this model as on the shorter RG-3020, so the added length does not slow the machine.
The five-axis head does 3+2 positional machining, and the spindle takes HSK-A63 tooling. Table load is 5,000 kg (11,023 lb) for the whole table, a figure that does not rise with length across the RG series and that suits aluminium far better than steel. There are 40 tool positions. The maker also describes independent cooling for the spindle and the secondary head to limit thermal deformation.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 6,000 mm (236.2 in) |
| Y Axis Travel | 2,000 mm (78.7 in) |
| Z Axis Travel | 1,200 mm (47.2 in) |
| Table Size | 2,000 x 6,000 mm (78.7 x 236.2 in) |
| Max Table Load | 5,000 kg (11,023 lb) |
| Max Spindle Speed | 20,000 rpm |
| Spindle Taper | HSK-A63 |
| Rapid Traverse X | 40 m/min (1,575 ipm) |
| Rapid Traverse Y | 40 m/min (1,575 ipm) |
| Rapid Traverse Z | 36 m/min (1,417 ipm) |
| Tool Capacity | 40 |
Specifications sourced from feeler.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 6,000 mm (236.2 in) of X travel, enough for two work zones
- 20,000 rpm HSK-A63 spindle on a five-axis head
- Rapid traverse of 40 / 40 / 36 m/min on X / Y / Z
- Direct-drive reducer on the X axis for strong torque output
- 2,000 mm (78.7 in) of Y travel and 1,200 mm of Z
Limitations
- Table load is 5,000 kg (11,023 lb) over a 2,000 x 6,000 mm table
- 40 tools shared by both ends of the table
- No head angles, spindle power or accuracy figures are published
- Not intended for heavy cutting in steel
Best For
Frequently Asked Questions
01
Travels are 6,000 mm (236.2 in) in X, 2,000 mm (78.7 in) in Y and 1,200 mm (47.2 in) in Z. The table is printed as 2,000 x 6,000 mm and the maximum loading weight is 5,000 kg (11,023 lb).
02
The table length allows it, and that is a common way to run a long gantry. Feeler's page does not describe a partition, twin work zones or safety arrangement for pendulum loading, so specify that with the maker.
03
Feeler quotes rapid traverse speeds of 40 / 40 / 36 m/min (X / Y / Z). The X-axis is driven through a direct-drive reducer and the Y and Z axes by direct transmission.
04
20,000 rpm with an HSK-A63 taper, mounted in a five-axis head for 3+2 positional machining. Power and torque are not listed on the series page.
