AWEA SP-2016
Image: awea.com, AWEA
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
x axis travel
How much does the AWEA SP-2016 cost?
Price estimate
We do not have a price for the AWEA SP-2016 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The AWEA SP-2016 is the shortest of the three SP bridge type vertical machining centers, with 2,100 mm (82.7 in) of X travel, 1,600 mm (63.0 in) of Y and 760 mm (29.9 in) of Z. Its 2,310 x 1,500 mm (90.9 x 59.1 in) table runs between columns set 1,700 mm (66.9 in) apart and is rated for 8,000 kg (17,637 lb).
That load rating is the reason to pick it. AWEA's VP-2016 covers nearly the same envelope, 2,000 mm (78.7 in) by the same Y and Z, and traverses X faster at 24 m/min (945 ipm), but its table stops at 5,000 kg (11,023 lb). The LP-2516 matches the SP-2016 on table size and on the 8,000 kg rating and weighs 26,000 kg (57,319 lb). At 19,000 kg (41,887 lb), the SP-2016 is the lightest AWEA bridge machine that will take a block of that weight.
Heavy blocks usually mean heavy cuts. The standard spindle is a 6,000 rpm gear unit with a 2-speed gear box, a 22 / 26 kW (30 / 35 HP) motor and a BT50 (ISO50) taper, DIN69871-A being the optional one. The maker quotes a maximum torque of 642 N-m at 387 rpm. Where the work is mostly finishing, direct drive spindles of 8,000 rpm and 10,000 rpm are available with a maximum of 165 N-m at 1,500 rpm, so the choice between them is a choice between roughing torque and surface speed.
Short travel helps the accuracy figures. Under the VDI standard this model is listed at P ≤ 0.020 mm over full travel and Ps ≤ 0.015 mm, the tightest pair in the series; the SP-4016 is listed at P ≤ 0.030 mm. Both X and Y rapid at 20,000 mm/min (787 ipm), and Z at 15,000 mm/min (591 ipm).
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 2,100 mm (82.7 in) |
| Y Axis Travel | 1,600 mm (63.0 in) |
| Z Axis Travel | 760 mm (29.9 in) |
| Table Size | 2,310 x 1,500 mm (90.9 x 59.1 in) |
| Max Table Load | 8,000 kg (17,637 lb) |
| Distance Spindle Nose to Table | 200 ~ 960 mm (7.9 ~ 37.8 in) |
| Distance Between Columns | 1,700 mm (66.9 in) |
| Spindle Motor Power | 22 / 26 kW (30 / 35 HP) |
| Max Spindle Speed | 6,000 rpm |
| Spindle Taper | BT50 (ISO50) / DIN69871-A (Opt.) |
| Rapid Traverse X | 20,000 mm/min (787 ipm) |
| Rapid Traverse Y | 20,000 mm/min (787 ipm) |
| Rapid Traverse Z | 15,000 mm/min (591 ipm) |
| Cutting Feed Rate | 1 ~ 10,000 mm/min (0.04 ~ 394 ipm) |
| Tool Capacity | 32 (24 / 40 / 60 Opt.) |
| Max Tool Diameter (full magazine) | Ø127 / 215 mm (Ø5.0 / 8.5 in) |
| Max Tool Length | 400 mm (15.7 in) |
| Max Tool Weight | 20 kg (44 lb) |
| Positioning Accuracy Jis B 6338 | ± 0.015 mm / Full Travel |
| Positioning Accuracy VDI 3441 | P ≤ 0.020 mm / Full Travel |
| Repeatability Jis B 6338 | ± 0.003 mm |
| Repeatability VDI 3441 | Ps ≤ 0.015 mm |
| Air Pressure Requirement | 5 ~ 8 kg/cm² |
| Hydraulic Tank Capacity | 120 liter (7.5 HP) |
| Lubrication Tank Capacity | 6 liter |
| Coolant Tank Capacity | 420 liter (1 HP) |
| Machine Weight | 19,000 kg (41,887 lb) |
Specifications sourced from awea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 8,000 kg (17,637 lb) table load, against 5,000 kg (11,023 lb) on the VP-2016 with a similar envelope
- 19,000 kg (41,887 lb) machine weight, where the LP-2516 with the same table and load rating weighs 26,000 kg (57,319 lb)
- Tightest VDI accuracy figures of the SP series: P ≤ 0.020 mm over full travel and Ps ≤ 0.015 mm
- Gear spindle with a maximum torque of 642 N-m at 387 rpm from the 26 kW motor
- X and Y both rapid at 20,000 mm/min (787 ipm)
Limitations
- X travel of 2,100 mm (82.7 in) is the shortest in the series; the SP-3016 gives 3,060 mm (120.5 in)
- The standard spindle tops out at 6,000 rpm; 8,000 rpm and 10,000 rpm direct drive spindles are options with a maximum of 165 N-m
- X rapid of 20,000 mm/min (787 ipm) is slower than the 24 m/min (945 ipm) of the VP-2016
- Z travel is 760 mm (29.9 in) with 200 ~ 960 mm (7.9 ~ 37.8 in) from spindle nose to table, which limits tall workpieces
Best For
Frequently Asked Questions
01
The two share 1,600 mm (63.0 in) of Y, 760 mm (29.9 in) of Z, a 6,000 rpm gear spindle and a 22 / 26 kW motor. The SP-2016 has 2,100 mm (82.7 in) of X and carries 8,000 kg (17,637 lb) on a 2,310 x 1,500 mm (90.9 x 59.1 in) table. The VP-2016 has 2,000 mm (78.7 in) of X, carries 5,000 kg (11,023 lb) on a 2,000 x 1,500 mm (78.7 x 59.1 in) table and has the faster X rapid, 24 m/min (945 ipm).
02
The standard unit is a 6,000 rpm gear spindle with a 2-speed gear box, rated 22 / 26 kW (30 / 35 HP), with a maximum torque of 642 N-m at 387 rpm. AWEA also offers direct drive spindles of 8,000 rpm and 10,000 rpm, which give a maximum of 165 N-m at 1,500 rpm. With a direct drive spindle the Z axis can optionally run on roller type linear guide ways instead of the standard box way.
03
AWEA gives two sets of figures. Under the JIS standard, positioning is ± 0.015 mm over full travel and repeatability ± 0.003 mm. Under the VDI standard, positioning is P ≤ 0.020 mm over full travel and repeatability Ps ≤ 0.015 mm. The VDI values widen on the longer models, to P ≤ 0.025 mm on the SP-3016 and P ≤ 0.030 mm on the SP-4016.
04
The machine weighs 19,000 kg (41,887 lb). The table is 2,310 x 1,500 mm (90.9 x 59.1 in) and takes 8,000 kg (17,637 lb). Width is limited by the 1,700 mm (66.9 in) between the columns, and height by the 200 ~ 960 mm (7.9 ~ 37.8 in) between spindle nose and table.
