AWEA LG-8040
Image: awea.com, AWEA
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
x axis travel
How much does the AWEA LG-8040 cost?
Price estimate
We do not have a price for the AWEA LG-8040 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The AWEA LG-8040 is a gantry type 5-face machining center with 8,000 mm (315.0 in) of X, 4,000 mm (157.5 in) of Y and 1,000 mm (39.4 in) of Z. Its fixed table is 8,000 x 3,800 mm (315.0 x 149.6 in) and carries 2,500 kg/m².
A table that size holds a great deal of work, and long cycles on it run into the magazine before anything else. Standard capacity is 32 tools, with 60 as the option. Each tool can be up to 350 mm (13.8 in) long from the gauge line and 20 kg (44 lb). Diameter is limited to Ø127 mm (Ø5.0 in), or 215 mm (8.5 in) when the adjacent pockets are empty. The magazine is a floor type unit on the back of the machine. With tools capped at 350 mm, deep side features are a job for an extension head, not for long tooling.
Plan the services early. The machine needs 80 kVA and compressed air at 5 ~ 8 kg/cm². The hydraulic unit holds 120 liter, the lubrication tank 6 liter, and the coolant tank, which stands apart from the machine, 1,600 liter. The LG-8030 uses a 1,300 liter tank and the LG-8050 a 1,900 liter one, so coolant volume grows with width while all three need the same 80 kVA.
Motion figures are 20 m/min (787 ipm) in X on a rack and pinion drive, 15 m/min (591 ipm) in Y and 10 m/min (394 ipm) in Z. Under VDI, X positioning is P = 0.040 mm with Ps = 0.030 mm repeatability; Y and Z are P = 0.030 mm over full travel and Ps = 0.025 mm.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 8,000 mm (315.0 in) |
| Y Axis Travel | 4,000 mm (157.5 in) |
| Z Axis Travel | 1,000 mm (39.4 in) |
| Table Size | 8,000 x 3,800 mm (315.0 x 149.6 in) |
| Max Table Load | 2,500 kg/m² |
| Distance Spindle Nose to Table | 200 ~ 1,200 mm (7.9 ~ 47.2 in) |
| Distance Between Columns with Water Eliminator | 4,800 mm (4,500 mm) |
| Spindle Motor Power | 22 / 26 kW (30 / 35 HP) |
| Max Spindle Speed | Gear 4,000 rpm (Std.) ; Gear 5,000 / 6,000 rpm (Opt.) ; Built-in 6,000 / 8,000 rpm (Opt.) |
| Spindle Taper | CAT50 (7 / 24) |
| Rapid Traverse X | 20 m/min (787 ipm) |
| Rapid Traverse Y | 15 m/min (591 ipm) |
| Rapid Traverse Z | 10 m/min (394 ipm) |
| Cutting Feed Rate | 1 ~ 10 m/min (39 ~ 394 ipm) |
| Tool Capacity | 32 (60 Opt.) |
| Max Tool Diameter (full magazine) | Ø127 / 215 mm (Ø5.0 / 8.5 in) |
| Max Tool Length | 350 mm (13.8 in) |
| Max Tool Weight | 20 kg (44 lb) |
| Positioning Accuracy Jis B 6338 | ± 0.025 / Full Travel |
| Positioning Accuracy VDI 3441 | P = 0.040 mm |
| Positioning Accuracy Yz VDI 3441 | P = 0.030 mm / Full Travel |
| Repeatability Jis B 6338 | ± 0.003 mm |
| Repeatability VDI 3441 | Ps = 0.030 mm |
| Repeatability Yz VDI 3441 | Ps = 0.025 mm |
| Power Requirement | 80 kVA 220 ±10 % Vac 3 phase 50 / 60 Hz |
| Air Pressure Requirement | 5 ~ 8 (5) kg/cm² |
| Hydraulic Tank Capacity | 120 liter |
| Lubrication Tank Capacity | 6 liter |
| Coolant Tank Capacity | 1,600 liter |
Specifications sourced from awea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 8,000 x 3,800 mm (315.0 x 149.6 in) fixed table rated at 2,500 kg/m²
- Magazine can be specified with 60 tools in place of the standard 32
- Accepts tools up to 215 mm (8.5 in) in diameter with adjacent pockets empty, and up to 20 kg (44 lb)
- Same 80 kVA power requirement as the narrower LG-8030
- Floor type magazine at the back of the machine, placed for access and maintenance
Limitations
- Tool length is capped at 350 mm (13.8 in) from the gauge line
- A 1,600 liter coolant tank, hydraulic unit and floor magazine all need space beside the machine
- X positioning of P = 0.040 mm; the shorter LG-6040 is listed at P = 0.035 mm
- The JIS positioning row is printed as ± 0.025 / Full Travel, without a unit
Best For
Frequently Asked Questions
01
The table lists an 80 kVA power requirement and a pneumatic pressure of 5 ~ 8 kg/cm². Tank capacities are 120 liter for the hydraulic unit, 6 liter for lubrication oil and 1,600 liter for coolant. The coolant tank is a separate type, so its floor area has to be planned alongside the machine.
02
Maximum tool diameter is Ø127 mm (Ø5.0 in) with neighbouring pockets occupied and 215 mm (8.5 in) with them empty. Maximum length is 350 mm (13.8 in) from the gauge line and maximum weight 20 kg (44 lb). The taper is CAT50 (7 / 24).
03
It depends on how many different parts share the table. One large workpiece often needs fewer than 32 tools. Several different parts fixtured together can exceed that, which is the case for the 60-tool option listed for this model. The LG-8030 table shows 32 only.
04
The LG-8050 has 5,000 mm (196.9 in) of Y and an 8,000 x 4,800 mm (315.0 x 189.0 in) table, with a 1,900 liter coolant tank. Y rapid on the LG-8050 is 12 m/min (472 ipm) and its Y and Z positioning P = 0.040 mm. The LG-8040 is narrower but faster and tighter across the gantry: 15 m/min (591 ipm) and P = 0.030 mm.
05
Under VDI the table gives Ps = 0.030 mm, and Ps = 0.025 mm for the Y and Z axes. The JIS repeatability row reads ± 0.003 mm. Positioning under VDI is P = 0.040 mm, with P = 0.030 mm over full travel for Y and Z.
