AWEA LP-3025YZF
Image: awea.com, AWEA
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
x axis travel
How much does the AWEA LP-3025YZF cost?
Price estimate
We do not have a price for the AWEA LP-3025YZF that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Tall work on a short table is the case for the AWEA LP-3025YZF. It gives 1,000 mm (39.4 in) of Z travel and 200 ~ 1,200 mm (7.9 ~ 47.2 in) from spindle nose to table top, on a 5-face bridge machine with only 3,000 mm (118.1 in) of X. The LP-3025YF, its lower sibling, stops at 760 mm (29.9 in) of Z and 200 ~ 960 mm (7.9 ~ 37.8 in).
The extra height matters twice on a 5-face machine. A tall part needs it, plainly. And a milling head hanging under the ram uses up part of the daylight before any cutting starts, so a longer Z keeps more of the envelope usable once the horizontal head is on.
AWEA changes the spindle with the Z stroke. Standard here is the 4,000 rpm high torque spindle, which the maker rates at 977 N-m at 254 rpm from the 26 kW motor through a 2-speed gear box. That is a roughing spindle for large face mills and boring bars in BT50. If the work is lighter and faster, built-in spindles of 6,000 / 8,000 rpm and direct drive spindles of 8,000 / 10,000 rpm are listed as options.
Z rapid traverse is 10,000 mm/min (394 ipm), while X moves at 20,000 mm/min (787 ipm) and Y at 15,000 mm/min (591 ipm). Y travel is 3,200 mm (126.0 in) over a 3,020 x 2,400 mm (118.9 x 94.5 in) table for 12,000 kg (26,455 lb). The machine weighs 39,000 kg (85,979 lb).
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 3,000 mm (118.1 in) |
| Y Axis Travel | 3,200 mm (126.0 in) |
| Z Axis Travel | 1,000 mm (39.4 in) |
| Table Size | 3,020 x 2,400 mm (118.9 x 94.5 in) |
| Max Table Load | 12,000 kg (26,455 lb) |
| Distance Spindle Nose to Table | 200 ~ 1,200 mm (7.9 ~ 47.2 in) |
| Distance Between Columns | 2,700 mm (106.3 in) |
| Spindle Motor Power | 22 / 26 kW (30 / 35 HP) |
| Max Spindle Speed | 4,000 rpm (Std.) Built-in 6,000 / 8,000 rpm (Opt.) Direct Drive 8,000 / 10,000 rpm (Opt.) |
| Spindle Taper | BT50 (ISO50) / DIN69871-A (Opt.) |
| Rapid Traverse X | 20,000 mm/min (787 ipm) |
| Rapid Traverse Y | 15,000 mm/min (591 ipm) |
| Rapid Traverse Z | 10,000 mm/min (394 ipm) |
| Cutting Feed Rate | 1 ~ 10,000 mm/min (0.04 ~ 394 ipm) |
| Tool Capacity | 32 (60 / 90 / 120 Opt.) |
| Max Tool Diameter (full magazine) | Ø127 / Ø215 mm (Ø5.0 / Ø8.5 in) |
| Max Tool Length | 350 mm (13.8 in) |
| Max Tool Weight | 20 kg (44 lb) |
| Positioning Accuracy Jis B 6338 | ± 0.015 mm / Full Travel |
| Positioning Accuracy VDI 3441 | P ≤ 0.025 mm / Full Travel |
| Repeatability Jis B 6338 | ± 0.003 mm |
| Repeatability VDI 3441 | Ps ≤ 0.020 mm |
| Air Pressure Requirement | 5 ~ 8 (5) kg/cm² |
| Hydraulic Tank Capacity | 120 liter (10 HP) |
| Lubrication Tank Capacity | 6 liter |
| Coolant Tank Capacity | 750 liter (1.5 HP) |
| Machine Weight | 39,000 kg (85,979 lb) |
Specifications sourced from awea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 1,000 mm (39.4 in) of Z travel with up to 1,200 mm (47.2 in) between spindle nose and table
- 4,000 rpm high torque gear spindle as standard, rated by AWEA at 977 N-m at 254 rpm
- X rapid of 20,000 mm/min (787 ipm), the fastest X figure among the YZF machines of this width
- Built-in 6,000 / 8,000 rpm and direct drive 8,000 / 10,000 rpm spindles can be ordered instead
- VDI positioning accuracy of P ≤ 0.025 mm over full travel
Limitations
- Standard spindle speed is 4,000 rpm; the LP-3025YF comes with 6,000 rpm
- Z rapid traverse drops to 10,000 mm/min (394 ipm) from 15,000 mm/min (591 ipm) on the LP-3025YF
- 39,000 kg (85,979 lb) of machine weight for a 12,000 kg (26,455 lb) table load
- X travel of 3,000 mm (118.1 in) is shorter than the 3,200 mm Y stroke, so long parts need the LP-4025YZF
Best For
Frequently Asked Questions
01
Z travel, spindle and weight. The LP-3025YZF has 1,000 mm (39.4 in) of Z, a 4,000 rpm standard spindle and weighs 39,000 kg (85,979 lb). The LP-3025YF has 760 mm (29.9 in) of Z, a 6,000 rpm spindle and weighs 36,000 kg (79,365 lb). X travel, Y travel, the table and the 12,000 kg (26,455 lb) load do not change.
02
AWEA states that the 4,000 rpm high torque spindle with its 26 kW motor delivers a maximum of 977 N-m at 254 rpm. For comparison, the maker's built-in 6,000 and 8,000 rpm spindles are given as 600 N-m at 350 rpm, and the direct drive 8,000 and 10,000 rpm spindles as 165 N-m at 1,500 rpm. Those two families are options on this model.
03
The standard Z axis is a box way, hardened and precisely ground, which AWEA describes as suited to heavy-duty cutting. Roller type linear guide ways on Z are offered as an option only together with the high speed direct drive spindle. X and Y use roller type linear guide ways in every case.
04
The distance from spindle nose to table top runs from 200 mm to 1,200 mm (7.9 ~ 47.2 in). That is the vertical-spindle figure. A milling head, a fixture and the tool itself all come out of that distance, so check the stack for the tallest setup before settling on this Z stroke.
