AWEA HTP-5025
Image: awea.com, AWEA
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
x axis travel
How much does the AWEA HTP-5025 cost?
Price estimate
We do not have a price for the AWEA HTP-5025 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Five metres of X on the narrow HTP frame: the AWEA HTP-5025 pairs 5,000 mm (196.9 in) of X travel with 2,500 mm (98.4 in) of Y, 1,000 mm (39.4 in) of Z and a column spacing of 2,700 mm (106.3 in). It is a fixed-bridge, moving-table machining center with a 4,000 rpm gear spindle.
The middle length of the 25 group keeps something its longer neighbour gives up. Cutting feed is still 1 ~ 10 m/min (39 ~ 394 ipm), the same as the HTP-4025, whereas the HTP-6025 is limited to 1 ~ 5 m/min (39 ~ 197 ipm). Rapid traverse on X is 10 m/min (394 ipm), and Y and Z move at 12 m/min (472 ipm).
What the extra metre buys is capacity. The 5,020 x 2,400 mm (197.6 x 94.5 in) table is rated for 18,000 kg (39,683 lb), up from 15,000 kg (33,069 lb) on the HTP-4025. Machine weight is 45,000 kg (99,206 lb). The table rides on what AWEA calls a compound 4 guideways design on the base, with the X ball screw placed in the centre of the table, an arrangement the maker says reduces table overhang.
Accuracy loosens a step with the length. VDI positioning is P ≤ 0.040 mm over full travel and repeatability Ps ≤ 0.030 mm; the JIS values are ± 0.015 mm and ± 0.003 mm, as on every HTP.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 5,000 mm (196.9 in) |
| Y Axis Travel | 2,500 mm (98.4 in) (Opt. 3,200) |
| Z Axis Travel | 1,000 mm (39.4 in) (Opt. 1,200 / 1,400) |
| Table Size | 5,020 x 2,400 mm (197.6 x 94.5 in) |
| Max Table Load | 18,000 kg (39,683 lb) |
| Distance Between Columns | 2,700 mm (106.3 in) |
| Distance Spindle Nose to Table | 200 ~ 1,200 mm (7.9 ~ 47.2 in) (Opt. 200 ~ 1,400 / 200 ~ 1,600) |
| Spindle Taper | BBT50 (ISO 50) |
| Spindle Motor Power | 22 / 26 kW (29.5 / 34.9 hp) (Opt. 30 / 37) |
| Max Spindle Speed | Gear Spindle 4,000 rpm |
| Rapid Traverse X | 10 m/min (394 ipm) |
| Rapid Traverse Yz | 12 m/min (472 ipm) |
| Cutting Feed Rate | 1 ~ 10 m/min (39 ~ 394 ipm) |
| Tool Capacity | 32 T (Opt. 40 / 60 / 90 / 120) |
| Max Tool Length | 350 mm (13.8 in) (Opt. 400) |
| Max Tool Weight | 20 kg (44 lb) |
| Max Tool Diameter (full magazine) | Ø127 / Ø215 mm (Ø5.0 / Ø8.5 in) |
| Positioning Accuracy Jis B 6338 | ± 0.015 mm / Full Travel |
| Positioning Accuracy VDI 3441 | P ≤ 0.040 mm / Full Travel |
| Repeatability Jis B 6338 | ± 0.003 mm |
| Repeatability VDI 3441 | Ps ≤ 0.030 mm |
| Coolant Tank Capacity | 900 liter |
| Lubrication Tank Capacity | 6 liter |
| Hydraulic Tank Capacity | 100 liter |
| Air Pressure Requirement | 5 ~ 8 kg/cm² |
| Machine Weight | 45,000 kg (99,206 lb) |
Specifications sourced from awea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Cutting feed of 1 ~ 10 m/min (39 ~ 394 ipm) on a 5,000 mm (196.9 in) X stroke; the HTP-5033 of the same length is listed at 1 ~ 5 m/min (39 ~ 197 ipm)
- 18,000 kg (39,683 lb) table load on a 5,020 x 2,400 mm (197.6 x 94.5 in) table
- 4 guideways under the table and a centre-mounted X ball screw
- 22 / 26 kW (29.5 / 34.9 hp) gear spindle with BBT50 (ISO 50) taper
Limitations
- X rapid traverse falls to 10 m/min (394 ipm) from the 15 m/min (591 ipm) of the HTP-4025
- VDI positioning widens to P ≤ 0.040 mm over full travel
- Spindle speed stops at 4,000 rpm in the listed configuration
- Needs a foundation for 45,000 kg (99,206 lb) of machine plus up to 18,000 kg (39,683 lb) of work
Best For
Frequently Asked Questions
01
18,000 kg (39,683 lb) on a table of 5,020 x 2,400 mm (197.6 x 94.5 in). The HTP-4025 is rated for 15,000 kg (33,069 lb) and the HTP-6025 for 20,000 kg (44,092 lb), so the rating rises with each metre of table in this group.
02
Rapid traverse is 10 m/min (394 ipm) on X and 12 m/min (472 ipm) on Y and Z. Cutting feed is 1 ~ 10 m/min (39 ~ 394 ipm). AWEA fits roller type linear guide ways on all three axes and a closed loop hydraulic counterbalance on the head.
03
Width. The HTP-5033 has 3,500 mm (137.8 in) between the columns, 3,300 mm (129.9 in) of Y and a 5,020 x 3,000 mm (197.6 x 118.1 in) table, and weighs 47,000 kg (103,616 lb). The HTP-5025 has 2,700 mm (106.3 in) between the columns and weighs 45,000 kg (99,206 lb). Table load is 18,000 kg (39,683 lb) on both.
04
32 T as standard, with 40 / 60 / 90 / 120 printed as options. A tool can be 350 mm (13.8 in) long and weigh 20 kg (44 lb); diameter is listed as Ø127 / Ø215 mm (Ø5.0 / Ø8.5 in).
