Johnford DMC-3100H
Key Specifications
Spindle Taper
Tool Capacity
Table Size
Spindle Power
distance between columns
x axis travel
How much does the Johnford DMC-3100H cost?
Price estimate
We do not have a price for the Johnford DMC-3100H that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Johnford DMC-3100H is the longest No.50 machine on Johnford's 1,300 mm double column frame. Its table is 3,200 x 1,100 mm, X travel is 3,050 mm, Y is 1,300 mm (51.2 in) and Z is 800 mm (31.5 in). The spindle is BT-50 / CAT-50 with a 15 / 18.5 kW (20.1 / 24.8 hp) Hi Lo Gear drive.
Length and a heavy spindle point to a specific kind of part: machine tool beds and columns, long press components, rail and guide blocks, large fabricated frames. These are faced, slotted and bored along their length, usually with big cutters at low speed, and the 6,000 rpm standard spindle with its 90 mm (3.5 in) bearing diameter is specified for exactly that. Tools can be Ø200 mm (Ø7.8 in), 400 mm (15.7 in) long and 15 kg (33 lb).
The load figure deserves attention before an order. The table is rated 6,000 kg (13,200 lb), the same as on the frame's shortest model. Cast iron beds three metres long can weigh more than that. If the parts are heavy for their length, the question to put to Johnford is whether the rating can be raised, or whether the larger DMC-S frame is the right machine.
Rapids are 12 / 15 / 12 m/min (472 / 591 / 472 ipm). At 26,800 kg (59,000 lb) and 8,515 x 3,300 x 3,835 mm (335 x 130 x 151 in) the machine needs a prepared foundation, and Johnford supplies foundation bolts and levelling pads with it. A 24-tool arm type changer is standard; 32, 40 and 60-tool magazines are options.
Full Specifications
| Parameter | Value |
|---|---|
| Distance Between Columns | 1,300 mm (51.2 in) |
| Table Size | 3,200 x 1,100 mm |
| X Axis Travel | 3,050 mm |
| Y Axis Travel | 1,300 mm (51.2 in) |
| Z Axis Travel | 800 mm (31.5 in) |
| Distance Spindle Nose to Table | 150~950 mm (5.9~37.4 in) |
| Spindle Taper | BT-50 / CAT-50; HSK A100(Opt.) |
| Spindle Bearing Diameter | 90 mm (3.5 in) |
| Spindle Speed | 6,000, 8,000 rpm (Opt.); 10,000 rpm |
| Spindle Motor Power | 15 / 18.5 kW (20.1 / 24.8 hp) Hi Lo Gear; 26 / 31 kW (34.9 / 41.6 hp) or 31 / 40 kW (41.6 / 53.6 hp) Built-in |
| Rapid Traverse Xyz | 12 / 15 / 12 m/min (472 / 591 / 472 ipm) |
| Cutting Feed Rate | 1~10,000 mm/min (0.04~394 ipm) |
| Max Tool Diameter Adjacent Pockets | Ø125 mm (Ø5 in) |
| Tool Capacity | Arm type 24 / 32 / 40 (Opt.) |
| Max Tool Diameter (full magazine) | Ø200 mm (Ø7.8 in) |
| Max Tool Length | 400 mm (15.7 in) |
| Max Tool Weight | 15 kg (33 lb) |
| Tool Selection | Bi-direction random type, Shortest path |
| Max Table Load | 6,000 kg (13,200 lb) |
| Machine Dimensions | 8,515 x 3,300 x 3,835 mm (335 x 130 x 151 in) |
| Machine Weight | 26,800 kg (59,000 lb) |
Specifications sourced from johnford.com.tw — verified 2026-10-04
Strengths & Limitations
Strengths
- 3,050 mm of X travel with a No.50 geared spindle
- 15 / 18.5 kW (20.1 / 24.8 hp) Hi Lo Gear drive and a 90 mm (3.5 in) spindle bearing diameter
- 1,300 mm (51.2 in) between columns and of Y travel
- Tools up to 15 kg (33 lb) and 400 mm (15.7 in) long
- Built-in spindle options up to 31 / 40 kW (41.6 / 53.6 hp)
Limitations
- Table load of 6,000 kg (13,200 lb) is low for three metre cast iron or steel parts
- X rapid of 12 m/min (472 ipm)
- Standard speed limited to 6,000 rpm
- The maker's table prints inconsistent inch conversions for this model's X travel and table size, so work from the metric figures
Best For
Frequently Asked Questions
01
X travel 3,050 mm, Y travel 1,300 mm (51.2 in), Z travel 800 mm (31.5 in), a 3,200 x 1,100 mm table rated 6,000 kg (13,200 lb), and a BT-50 / CAT-50 spindle with 15 / 18.5 kW (20.1 / 24.8 hp) and a Hi Lo Gear.
02
The DMC-3100 has a BT-40 / CAT-40 spindle with a 70 mm (2.8 in) bearing diameter, 7.5 / 11 kW (10.1 / 14.8 hp) and 10 kg (22 lb) tools. The DMC-3100H has the No.50 spindle with a 90 mm (3.5 in) bearing diameter and 15 kg (33 lb) tools. Travels, table load and weight are the same.
03
8,515 x 3,300 x 3,835 mm (335 x 130 x 151 in), length by width by height. It weighs 26,800 kg (59,000 lb), the same as the 40-taper DMC-3100.
04
6,000 rpm as standard and 8,000 rpm as an option with the Hi Lo Gear drive, and 10,000 rpm with the built-in spindle of 26 / 31 kW (34.9 / 41.6 hp) or 31 / 40 kW (41.6 / 53.6 hp).
