You Ji VTL3000ATC
Image: image.youji.com, You Ji
Key Specifications
Max Spindle
Spindle Power
table diameter
max swing diameter
max turning diameter
max turning height
How much does the You Ji VTL3000ATC cost?
Price estimate
We do not have a price for the You Ji VTL3000ATC that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
At three metres of table, the You Ji VTL3000ATC is a different class of installation from the smaller VTL vertical turning lathes. The catalogue lists a floor dimension of 11,000 x 7,000 mm (433.1 x 275.6 in) and a height of 7,400 mm (291.3 in).
The table is Ø3,000 mm (118.1 in). Maximum turning diameter is Ø3,300 mm (129.9 in) and swing Ø3,400 mm (133.9 in), so the swing exceeds the turning diameter only slightly and almost the whole envelope can be cut. Turning height is 1,700 mm (66.9 in), the greatest in the VTL table together with the VTL3500ATC. Loading weight is 20,000 kg (44,092 lb).
This is the first VTL where the tool shank row reads BT-50/BT-60. The heavier shank matters when a long boring bar or a large face mill hangs from the ram, because the larger taper carries more bending load. Which of the two is fitted is a choice to settle in the order.
The spindle motor is 60/75 kW (80.5/100.6 hp) at 1-120 rpm. For parts heavier than the table rating, You Ji builds the VTH3000ATC with a hydrostatic table bearing; it has the same table, swing, turning diameter and height figures but carries 45,000 kg (99,206 lb). The VTL3000ATC is the choice when the parts are large and comparatively light: rings, fabricated housings and thin-walled casings. Double ram, C-axis and raised-column builds are listed; the pallet changer is not.
Full Specifications
| Parameter | Value |
|---|---|
| Table Diameter | Ø3,000 mm (118.1 in) |
| Max Swing Diameter | Ø3,400 mm (133.9 in) |
| Max Turning Diameter | Ø3,300 mm (129.9 in) |
| Max Turning Height | 1,700 mm (66.9 in) |
| Max Table Load | 20,000 kg (44,092 lb) |
| Spindle Motor Power | 60/75 kW (80.5/100.6 hp) |
| Tool Shank | BT-50/BT-60 |
| Max Spindle Speed | 1-120 rpm |
| Floor Space | 11,000 x 7,000 mm (433.1 x 275.6 in) |
| Machine Height | 7,400 mm (291.3 in) |
Specifications sourced from image.youji.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Ø3,300 mm (129.9 in) turning diameter inside a Ø3,400 mm (133.9 in) swing
- 1,700 mm (66.9 in) turning height, the greatest in the VTL table
- Tool shank BT-50/BT-60 for heavier ram tooling
- 20,000 kg (44,092 lb) loading weight with a 60/75 kW (80.5/100.6 hp) motor
Limitations
- Floor dimension of 11,000 x 7,000 mm (433.1 x 275.6 in) and 7,400 mm (291.3 in) height
- No pallet changer: the key lists APC only up to the 2500
- Loading weight is less than half the 45,000 kg (99,206 lb) of the VTH3000ATC
- Table speed range of 1-120 rpm
Best For
Frequently Asked Questions
01
The table bearing and the load. The VTH3000ATC is described as having a hydrostatic table bearing and is rated 45,000 kg (99,206 lb) with a 60/84 kW (80.5/112.6 hp) motor at 1-75 rpm. The VTL3000ATC is rated 20,000 kg (44,092 lb) with 60/75 kW (80.5/100.6 hp) at 1-120 rpm.
02
The table lists BT-50/BT-60. Smaller VTL models up to the VTL2500ATC list BT-50 only. The catalogue does not say which shank is standard, so specify it when requesting a quotation.
03
Table diameter Ø3,000 mm (118.1 in), maximum swing Ø3,400 mm (133.9 in), maximum turning diameter Ø3,300 mm (129.9 in) and maximum turning height 1,700 mm (66.9 in).
04
The floor dimension is 11,000 x 7,000 mm (433.1 x 275.6 in), compared with 7,550 x 5,130 mm (297.2 x 202.0 in) for the VTL2500ATC. Machine height is 7,400 mm (291.3 in). A machine of this size is normally set on a prepared foundation; ask the maker for the drawing.
