Vision Wide Vertical Machining Centers (VMC)

Vision Wide SF-5133

Q: How much does the Vision Wide SF-5133 cost?

The price estimate for the Vision Wide SF-5133 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-sf-5133#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

5,300×2,100 mm (208.7×82.7 in)

x axis travel

5,100 mm (200.8 in)

y axis travel

2,600 mm (102.4 in)

z axis travel box way

800 / 1,020 mm (31.5 / 40.2 in) (Opt.)

z axis travel linear way

800 / 1,000 mm (31.5 / 39.4 in) (Opt.)

max table load

18,000 kg (39,683 lb)

How much does the Vision Wide SF-5133 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide SF-5133 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Vision Wide SF-5133 closes the SF series. It is the largest configuration on the page: 5,100 mm (200.8 in) of X travel, 2,600 mm (102.4 in) of Y as printed, a 5,300×2,100 mm (208.7×82.7 in) table and an 18,000 kg (39,683 lb) load rating, with floor-standing tool changers.

At this end of a range it is fair to ask what the series does not provide. Spindle power is the clearest case. The motor is 18.5/22 kW (24.8/29.5 hp), with 22/26 kW (29.5/34.9 hp) as the only step up, and that is the same pair listed for the SF-2116 with its 2,000x1,500 mm (78.7x59.1 in) table. Z travel is another: 800 mm standard and at most 1,020 mm. A buyer who needs more power or more daylight under the spindle for parts of this weight is looking beyond the SF line.

Within those limits the machine is a long, stiff three-axis platform. Vision Wide describes a full casting structure and an ultra-wide column, and rapids are 20 m/min in X and Y.

The floor-standing changer holds 32 tools, with 40 optional, and the vertical-horizontal version can be ordered with up to 60 pcs.

Full Specifications

Parameter	Value
X Axis Travel	5,100 mm (200.8 in)
Y Axis Travel	2,600 mm (102.4 in)
Z Axis Travel Box Way	800 / 1,020 mm (31.5 / 40.2 in) (Opt.)
Z Axis Travel Linear Way	800 / 1,000 mm (31.5 / 39.4 in) (Opt.)
Table Size	5,300×2,100 mm (208.7×82.7 in)
Max Table Load	18,000 kg (39,683 lb)
Spindle Power Cont 30 Min	18.5/22 kW (24.8/29.5 hp) (22/26 kW (29.5/34.9 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	6,000/4,000 rpm(Opt.)
Spindle Speed Linear Way Direct Driven	10,000 rpm(Opt.)/ 12,000 rpm(Opt.)
Spindle Speed Linear Way Built in	10,000 rpm(Opt.)
Cutting Feed Rate	1-10,000 mm/min
Rapid Traverse Xyz	XY：20 m/min / Z：15 m/min
Tool Capacity Floor Standing Vertical Tool Change	32/40 pcs(Opt.)
Tool Capacity Floor Standing Vertical Horizontal Tool Change	32 pcs(Opt.)/40 pcs(Opt.)/60 pcs(Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

Largest SF configuration: 5,100 mm (200.8 in) of X and 2,600 mm (102.4 in) of Y as printed
18,000 kg (39,683 lb) table load
Full casting structure with ultra-wide column, per the maker
Floor-standing changers with up to 60 pcs on the optional vertical-horizontal type

Limitations

Spindle power is the same 18.5/22 kW (24.8/29.5 hp) as on the SF-2116
Z travel is at most 1,020 mm, and that is an option
Printed Y travel should be confirmed against the model number

Best For

The longest and heaviest parts the SF series can take Structural parts up to 18,000 kg (39,683 lb) that are long but not tall Tandem setups along a 5,300×2,100 mm (208.7×82.7 in) table

Frequently Asked Questions

01 Is the Vision Wide SF-5133 the largest SF model?

It shares the longest X travel, 5,100 mm (200.8 in), and the highest table load, 18,000 kg (39,683 lb), with the SF-5126, and adds floor-standing tool changers. Y travel is printed as 2,600 mm (102.4 in).

02 Does the SF-5133 have more spindle power than smaller SF machines?

No. The spindle power row is 18.5/22 kW (24.8/29.5 hp) with 22/26 kW (29.5/34.9 hp) as an option, the same as on every other model in the series.

03 How tall a part fits under the SF-5133 spindle?

Vision Wide's table gives Z travel only: 800 mm standard, 1,020 mm optional on the box way head and 1,000 mm optional on the linear way head. It lists no spindle-nose-to-table distance or column clearance, so request the layout drawing.

04 What tool changers does the SF-5133 list?

A floor-standing type vertical tool change at 32/40 pcs(Opt.) and a floor-standing type vertical-horizontal tool change at 32 pcs(Opt.)/40 pcs(Opt.)/60 pcs(Opt.).
