Vision Wide Vertical Machining Centers (VMC)

Vision Wide NF-10026 / NF-10033

Q: How much does the Vision Wide NF-10026 / NF-10033 cost?

The price estimate for the Vision Wide NF-10026 / NF-10033 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-nf-10026-nf-10033#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

10,000×2,450 mm (393.7×96.5 in)

x axis travel

10,100 mm (397.6 in)

y axis travel

2,600/ 3,300 mm (102.4/ 129.9 in)

z axis travel box way single ballscrew

920 / 1,020 mm (36.2 / 40.2 in)(Opt.)

z axis travel linear way enclosed box ram dual ballscrews

1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)

max table load

26,000 kg (57,319 lb)

How much does the Vision Wide NF-10026 / NF-10033 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide NF-10026 / NF-10033 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Vision Wide NF-10026 / NF-10033 puts a 10,000×2,450 mm (393.7×96.5 in) table under a five-face bridge. X travel is 10,100 mm (397.6 in), Y travel is 2,600 mm (102.4 in) on the NF-10026 or 3,300 mm (129.9 in) on the NF-10033, and the table carries 26,000 kg (57,319 lb).

Who needs a moving table ten metres long? Builders of machine tools, presses, rolling stock and wind or power equipment, where the part is a bed, a side frame or a beam with precise faces spread along its whole length. Machining those faces in one pass of the table is what keeps them in line with each other.

The structure Vision Wide describes is suited to that: a high rigidity box base, wide-span table guideways and a square-section beam. What the page does not give is the weight of the machine, the foundation it needs or the floor length the moving table sweeps, all of which are large on this model.

The table lists the same head and spindle choices as the rest of the NF line. Standard is a 4,000 rpm gear spindle with 18.5/22 kW (24.8/29.5 hp); 30/37 kW (40.2/49.6 hp) is the largest optional motor. Cutting feed is 1-7,000 mm/min and the X/Y rapid 8 m/min.

Full Specifications

Parameter	Value
X Axis Travel	10,100 mm (397.6 in)
Y Axis Travel	2,600/ 3,300 mm (102.4/ 129.9 in)
Z Axis Travel Box Way Single Ballscrew	920 / 1,020 mm (36.2 / 40.2 in)(Opt.)
Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews	1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)
Table Size	10,000×2,450 mm (393.7×96.5 in)
Max Table Load	26,000 kg (57,319 lb)
Spindle Power Cont 30 Min	18.5/22 kW (24.8/29.5 hp)(22/26 kW (29.5/34.9 hp) Opt.)(30/37 kW (40.2/49.6 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram Direct Driven	10,000 rpm(Opt.)
Cutting Feed Rate	1-7,000 mm/min
Rapid Traverse Xy	8 m/min
Rapid Traverse Z Box Way or Linear Way	15 m/min
Rapid Traverse Z Enclosed Box Ram	12 m/min
Tool Capacity Vertical Tool Change	32 / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Horizontal Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

10,000×2,450 mm (393.7×96.5 in) table
26,000 kg (57,319 lb) table load
Up to 3,300 mm (129.9 in) of Y travel on the NF-10033
Optional 30/37 kW (40.2/49.6 hp) spindle motor

Limitations

No machine weight, footprint or foundation data on the maker's page
Cutting feed of 1-7,000 mm/min and X/Y rapid of 8 m/min
Standard motor is 18.5/22 kW (24.8/29.5 hp)

Best For

Machine tool beds and press side frames Rolling stock and power equipment beams Faces spread along up to 10,100 mm (397.6 in) cut in one setup

Frequently Asked Questions

01 What are the dimensions of the Vision Wide NF-10026 table?

10,000×2,450 mm (393.7×96.5 in). X travel is 10,100 mm (397.6 in) and the table load is 26,000 kg (57,319 lb).

02 What is the difference between the NF-10026 and the NF-10033?

Y travel: 2,600 mm (102.4 in) on the NF-10026 and 3,300 mm (129.9 in) on the NF-10033. The other rows of the shared column apply to both.

03 What spindle power can the NF-10026 / NF-10033 have?

18.5/22 kW (24.8/29.5 hp) as standard, with 22/26 kW (29.5/34.9 hp) and 30/37 kW (40.2/49.6 hp) as options. The standard spindle is a box way 4,000rpm 2-step gear type.

04 How much floor space does the NF-10026 need?

Vision Wide's page gives no footprint. The table is 10,000×2,450 mm (393.7×96.5 in) and travels 10,100 mm (397.6 in), so the bed is much longer than the table. Ask for the layout and foundation drawings.
