Vision Wide Vertical Machining Centers (VMC)

Vision Wide NF-6032 / NF-6039

Q: How much does the Vision Wide NF-6032 / NF-6039 cost?

The price estimate for the Vision Wide NF-6032 / NF-6039 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-nf-6032-nf-6039#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

6,000×2,450 mm (236.2×96.5 in)

x axis travel

6,100 mm (240.2 in)

y axis travel

3,200/ 3,900 mm (126.0/ 153.5 in)

z axis travel box way single ballscrew

920 / 1,020 mm (36.2 / 40.2 in)(Opt.)

z axis travel linear way enclosed box ram dual ballscrews

1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)

max table load

22,000 kg (48,501 lb)

How much does the Vision Wide NF-6032 / NF-6039 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide NF-6032 / NF-6039 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

Finishing on a machine as large as the Vision Wide NF-6032 / NF-6039 depends on two options: a faster spindle and direct position feedback. X travel is 6,100 mm (240.2 in), Y travel is 3,200 mm (126.0 in) or 3,900 mm (153.5 in), and both are long enough for thermal growth of the ballscrews to matter.

The specification table lists a direct-driven spindle at 10,000 rpm, optional, under the linear way and enclosed box ram heads; the accessory list words it as a 10,000/12,000 rpm direct driven type spindle. Either way, it is not available on the standard box way head, whose gear spindle runs 4,000 rpm or optionally 6,000 rpm.

For feedback, XYZ-axis linear scale feedback is optional. Vision Wide states that positioning accuracy could reach ±0.005/300 mm (JIS B6333). That is a short-span figure. Holding position over six metres of X and nearly four of Y is what the scales are for.

The table is 6,000×2,450 mm (236.2×96.5 in) and rated for 22,000 kg (48,501 lb). X/Y rapid is 10 m/min. A large die or mold of that size, roughed with the gear spindle on another machine or another shift, can be finished here if the machine is built for it.

Full Specifications

Parameter	Value
X Axis Travel	6,100 mm (240.2 in)
Y Axis Travel	3,200/ 3,900 mm (126.0/ 153.5 in)
Z Axis Travel Box Way Single Ballscrew	920 / 1,020 mm (36.2 / 40.2 in)(Opt.)
Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews	1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)
Table Size	6,000×2,450 mm (236.2×96.5 in)
Max Table Load	22,000 kg (48,501 lb)
Spindle Power Cont 30 Min	18.5/22 kW (24.8/29.5 hp)(22/26 kW (29.5/34.9 hp) Opt.)(30/37 kW (40.2/49.6 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram Direct Driven	10,000 rpm(Opt.)
Cutting Feed Rate	1-10,000 mm/min
Rapid Traverse Xy	10 m/min
Rapid Traverse Z Box Way or Linear Way	15 m/min
Rapid Traverse Z Enclosed Box Ram	12 m/min
Tool Capacity Vertical Tool Change	32 / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Horizontal Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

Optional direct-driven spindle at 10,000 rpm on the linear way or enclosed box ram head
Optional XYZ-axis linear scale feedback
6,000×2,450 mm (236.2×96.5 in) table for 22,000 kg (48,501 lb)
Y travel of up to 3,900 mm (153.5 in) on the NF-6039

Limitations

The direct-driven spindle is not offered on the standard box way head
Linear scales are optional on axes of 6,100 mm (240.2 in) and more than 3 m
X/Y rapid of 10 m/min on a 6,100 mm (240.2 in) axis

Best For

Finishing large dies with the optional high-speed spindle Accuracy-critical parts when ordered with linear scales Loads up to 22,000 kg (48,501 lb)

Frequently Asked Questions

01 Can the Vision Wide NF-6032 be used for finishing?

With options. A direct-driven spindle at 10,000 rpm is listed for the linear way and enclosed box ram heads, and XYZ-axis linear scale feedback is optional. The standard machine has a 4,000 rpm gear spindle on a box way head.

02 What accuracy does Vision Wide state for the NF-6032 / NF-6039?

The NF series text says positioning accuracy could reach ±0.005/300 mm (JIS B6333). No figure for the full travel is given on the page.

03 What are the NF-6032 and NF-6039 Y travels?

3,200 mm (126.0 in) on the NF-6032 and 3,900 mm (153.5 in) on the NF-6039. X travel is 6,100 mm (240.2 in) on both.

04 What table load does the NF-6032 have?

22,000 kg (48,501 lb) on a 6,000×2,450 mm (236.2×96.5 in) table, the same rating as the NF-6026 and NF-6023 of the same length.
