Vision Wide Vertical Machining Centers (VMC)

Vision Wide MHN-10040 / MHN-10047

Q: How much does the Vision Wide MHN-10040 / MHN-10047 cost?

The price estimate for the Vision Wide MHN-10040 / MHN-10047 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-mhn-10040-mhn-10047#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

10,000×3,500 mm (393.7×137.8 in)

x axis travel

10,100 mm (397.6 in)

y axis travel

4,000/ 4,700 mm (157.5/ 185.0 in)

z axis travel box way single ballscrew

920 / 1,020 mm (36.2 / 40.2 in)(Opt.)

z axis travel linear way enclosed box ram dual ballscrews

1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)

max table load

36,000 kg (79,365 lb)

How much does the Vision Wide MHN-10040 / MHN-10047 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide MHN-10040 / MHN-10047 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The largest milling machine on Vision Wide's site is the MHN-10040 / MHN-10047. X travel is 10,100 mm (397.6 in). Y travel is 4,000 mm (157.5 in) on the MHN-10040 and 4,700 mm (185.0 in) on the MHN-10047. The table is 10,000×3,500 mm (393.7×137.8 in), rated for 36,000 kg (79,365 lb).

Its figures are those of the HF-10040 / HF-10047 five-face machining center, with the tool changer rows left out. What the MHN page offers in their place is the fullest description of structure the maker gives for any of its bridge machines: a stepped beam, one-piece cast columns, a thick, extra-wide bed supporting the table over its full stroke, a 65mm ultra-load guideway on Y said to add more than 40% rigidity, supported screws on X and Y, and a spindle set close to its Z-axis ways.

A machine like this is bought to mill the largest parts a works will ever handle, slowly and accurately. X/Y rapid is 8 m/min, cutting feed 1-7,000 mm/min, and the spindle a 4,000 rpm geared unit on 22/26 kW (29.5/34.9 hp), or 30/37 kW (40.2/49.6 hp).

The page lists no tool magazine, no accuracy and no foundation data. Those, with the head attachments, are the subjects for the maker.

Full Specifications

Parameter	Value
X Axis Travel	10,100 mm (397.6 in)
Y Axis Travel	4,000/ 4,700 mm (157.5/ 185.0 in)
Z Axis Travel Box Way Single Ballscrew	920 / 1,020 mm (36.2 / 40.2 in)(Opt.)
Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews	1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)
Table Size	10,000×3,500 mm (393.7×137.8 in)
Max Table Load	36,000 kg (79,365 lb)
Spindle Power Cont 30 Min	22/26 kW (29.5/34.9 hp)(30/37 kW (40.2/49.6 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram Direct Driven	10,000 rpm(Opt.)
Cutting Feed Rate	1-7,000 mm/min
Rapid Traverse Xy	8 m/min
Rapid Traverse Z Box Way or Linear Way	15 m/min
Rapid Traverse Z Enclosed Box Ram	12 m/min

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

Largest table in the series: 10,000×3,500 mm (393.7×137.8 in) for 36,000 kg (79,365 lb)
Y travel of 4,000 mm (157.5 in) or 4,700 mm (185.0 in)
65mm Y guideway, stepped beam and one-piece cast columns
30/37 kW (40.2/49.6 hp) motor option

Limitations

No tool magazine, accuracy or foundation data on the page
X/Y rapid of 8 m/min over the long table
Standard Z travel of 920 mm

Best For

The largest parts a heavy-engineering works handles Beds, frames and platens up to 36,000 kg (79,365 lb) Slow, heavy, accurate milling over ten metres

Frequently Asked Questions

01 What is the largest Vision Wide MHN model?

The MHN-10040 / MHN-10047: 10,100 mm (397.6 in) of X travel, 4,000/ 4,700 mm (157.5/ 185.0 in) of Y, and a 10,000×3,500 mm (393.7×137.8 in) table rated for 36,000 kg (79,365 lb).

02 How does the MHN-10040 differ from the HF-10040?

The two tables agree on travels, table, load, spindle rows and rapids. The HF-10040 table lists tool changers and its page describes automatic head change; the MHN-10040 page lists neither and describes the structure in detail.

03 What structural features does Vision Wide list for the MHN-10040 / MHN-10047?

A stepped beam, a one-piece casting column, a full stroke supported bed, a Y-axis with a 65mm ultra-load guideway, an XY-axis precision supporter mechanism for the ball screws and a minimum distance between spindle center and Z-axis roller way.

04 What are the feeds and power of the MHN-10040?

Cutting feed is 1-7,000 mm/min and X/Y rapid 8 m/min. Spindle power is 22/26 kW (29.5/34.9 hp), with 30/37 kW (40.2/49.6 hp) optional, on a 4,000 rpm gear spindle.
