Litz VH-1300A
Image: litzhitech.com, Litz
Key Specifications
Max Spindle
Tool Capacity
Table Size
Spindle Power
x axis travel
y axis travel
How much does the Litz VH-1300A cost?
Price estimate
We do not have a price for the Litz VH-1300A that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Litz VH-1300A is the longest of the five smaller VH vertical machining centers, offering 1,300 mm (51.2 in) of X travel with 610 mm (24.0 in) of Y and 600 mm (23.6 in) of Z. Its table is 1,420 x 600 mm (55.9 x 23.6 in).
Think of it as a VH-1100A with a longer table. Spindle, motor ratings, rapids, Y and Z are shared between the two. The X axis gains travel, the table gains length, and machine weight goes to 7,600 kg (16,755 lb). Table load does not change: 1,000 kg (2,205 lb) on both.
That makes it a good fit for long parts that are not especially heavy, or for running two different jobs side by side on one table, each with its own work offset. With 48 m/min (1,890 ipm) rapids in X, the spindle crosses between two stations quickly enough for that to pay.
The 12,000 rpm direct-drive spindle has a 15 / 18.5 kW (20.1 / 24.8 hp) motor and BBT-40 tooling. Litz also offers coolant through the ballscrews as an option, which is worth considering on an axis this long because screw growth shows up as position error at the far end of travel. Linear scales are a separate option. The coolant tank holds 460 L and supply is 35 kVA.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 1,300 mm (51.2 in) |
| Y Axis Travel | 610 mm (24.0 in) |
| Z Axis Travel | 600 mm (23.6 in) |
| Distance Spindle Nose to Table | 85 to 685 mm (3.3 to 27.0 in) |
| Spindle Center to Z Rail Surface | 655 mm (25.8 in) |
| Table Height From Floor | 1,030 mm (40.6 in) |
| Max Spindle Speed | 12,000 rpm |
| Tool Capacity | 24 |
| Max Tool Length | 300 mm (11.8 in) |
| Max Tool Weight | 7 kg (15 lb) |
| Tool Change Method | ARM |
| Tool Shank | BBT-40 |
| Spindle Motor Power | 15 / 18.5 kW (20.1 / 24.8 hp) |
| Axis Motors Xyz | 4 / 4 / 4 kW |
| Table Size | 1,420 x 600 mm (55.9 x 23.6 in) |
| Max Table Load | 1,000 kg (2,205 lb) |
| T-Slot Width | 18 mm (0.7 in) |
| T Slot Count | 5 |
| T Slot Distance From Center | 100 mm (3.9 in) |
| CNC Control | FANUC 0i-MF PLUS 3 |
| Machine Weight | 7,600 kg (16,755 lb) |
| Coolant Tank Capacity | 460 L |
| Power Requirement | 35 kVA |
| Compressed Air | 6 kg/cm² |
| Rapid Traverse Xyz | 48 / 48 / 24 m/min (1,890 / 1,890 / 945 ipm) |
Specifications sourced from litzhitech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 1,300 mm (51.2 in) of X travel and a 1,420 x 600 mm (55.9 x 23.6 in) table
- 15 / 18.5 kW (20.1 / 24.8 hp) motor on a 12,000 rpm direct-drive spindle
- 48 / 48 / 24 m/min (1,890 / 1,890 / 945 ipm) rapids
- 1,000 kg (2,205 lb) table load
- Coolant through the ballscrews and linear scales available as options
Limitations
- Table load is no higher than on the shorter VH-1100A
- 24 tools as standard; only the 32T magazine is offered as an upgrade
- Tools limited to 300 mm (11.8 in) and 7 kg (15 lb)
- Y travel stays at 610 mm (24.0 in)
Best For
Frequently Asked Questions
01
The table is 1,420 x 600 mm (55.9 x 23.6 in) and X travel is 1,300 mm (51.2 in). It has five 18 mm T-slots and carries 1,000 kg (2,205 lb). The table surface is 1,030 mm (40.6 in) above the floor.
02
It matches the VH-1100A at 48 / 48 / 24 m/min (1,890 / 1,890 / 945 ipm). The VH-1000A is listed at 60 / 60 / 30 m/min. Axis motors on the VH-1300A are 4 / 4 / 4 kW.
03
The FANUC 0i-MF PLUS 3 is named in the specification table and FANUC is marked standard in the accessory list. The Mitsubishi M80 is offered as an option, as is a 4th axis rotating table.
04
The arm-type changer holds 24 BBT-40 tools, each up to 300 mm (11.8 in) long and 7 kg (15 lb). A 32T arm type magazine is listed as an option.
