Litz VH-1100A
Image: litzhitech.com, Litz
Key Specifications
Max Spindle
Tool Capacity
Table Size
Spindle Power
x axis travel
y axis travel
How much does the Litz VH-1100A cost?
Price estimate
We do not have a price for the Litz VH-1100A that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Litz VH-1100A marks the step to the larger VH casting. Travels are 1,100 mm (43.3 in) in X, 610 mm (24.0 in) in Y and 600 mm (23.6 in) in Z, and the table rating rises to 1,000 kg (2,205 lb) from the 500 kg of the VH-1000A.
Nearly every figure moves with it. The spindle motor becomes 15 / 18.5 kW (20.1 / 24.8 hp), the axis motors 4 / 4 / 4 kW, the supply 35 kVA. Rapids come down to 48 / 48 / 24 m/min (1,890 / 1,890 / 945 ipm), still quick for a machine of this capacity. Spindle speed is unchanged at 12,000 rpm, direct-drive, with BBT-40 tooling.
So the VH-1100A is the model for buyers who liked the pace of the smaller VH machines but need to put a real load on the table. A 1,200 x 600 mm (47.2 x 23.6 in) table with 610 mm of Y handles mould plates and fixture tombstones laid flat. Daylight is 85 to 685 mm (3.3 to 27.0 in).
Machine weight is listed at 7,300 kg (16,093 lb), only slightly above the VH-1000A at 7,000 kg. The coolant tank grows to 440 L. On the option list the larger magazine is the 32T arm type; the 30T offered on the VH-800A is not available here. Tool limits remain 300 mm (11.8 in) and 7 kg (15 lb).
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 1,100 mm (43.3 in) |
| Y Axis Travel | 610 mm (24.0 in) |
| Z Axis Travel | 600 mm (23.6 in) |
| Distance Spindle Nose to Table | 85 to 685 mm (3.3 to 27.0 in) |
| Spindle Center to Z Rail Surface | 655 mm (25.8 in) |
| Table Height From Floor | 1,030 mm (40.6 in) |
| Max Spindle Speed | 12,000 rpm |
| Tool Capacity | 24 |
| Max Tool Length | 300 mm (11.8 in) |
| Max Tool Weight | 7 kg (15 lb) |
| Tool Change Method | ARM |
| Tool Shank | BBT-40 |
| Spindle Motor Power | 15 / 18.5 kW (20.1 / 24.8 hp) |
| Axis Motors Xyz | 4 / 4 / 4 kW |
| Table Size | 1,200 x 600 mm (47.2 x 23.6 in) |
| Max Table Load | 1,000 kg (2,205 lb) |
| T-Slot Width | 18 mm (0.7 in) |
| T Slot Count | 5 |
| T Slot Distance From Center | 100 mm (3.9 in) |
| CNC Control | FANUC 0i-MF PLUS 3 |
| Machine Weight | 7,300 kg (16,093 lb) |
| Coolant Tank Capacity | 440 L |
| Power Requirement | 35 kVA |
| Compressed Air | 6 kg/cm² |
| Rapid Traverse Xyz | 48 / 48 / 24 m/min (1,890 / 1,890 / 945 ipm) |
Specifications sourced from litzhitech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 1,000 kg (2,205 lb) table load, against 500 kg on the VH-1000A
- 15 / 18.5 kW (20.1 / 24.8 hp) spindle motor at 12,000 rpm
- 48 / 48 / 24 m/min (1,890 / 1,890 / 945 ipm) rapids
- 610 mm (24.0 in) of Y and 600 mm (23.6 in) of Z travel
- 440 L coolant tank for long unattended runs
Limitations
- Rapids are below the 60 / 60 / 30 m/min of the VH-1000A
- Tool weight is still limited to 7 kg (15 lb)
- Requires a 35 kVA supply, up from 25 kVA on the VH-1000A
- 32T is the only larger magazine option
Best For
Frequently Asked Questions
01
The VH-1100A has a 1,000 kg (2,205 lb) table load, a 15 / 18.5 kW motor, 610 mm of Y and 600 mm of Z. The VH-1000A has 500 kg (1,102 lb), 11 / 15 kW, 540 mm and 525 mm, but faster rapids at 60 / 60 / 30 m/min.
02
Travels are 1,100 mm (43.3 in), 610 mm (24.0 in) and 600 mm (23.6 in). The table is 1,200 x 600 mm (47.2 x 23.6 in) with five 18 mm T-slots, and its surface is 1,030 mm (40.6 in) from the floor.
03
A 12,000 rpm direct-drive spindle with BBT-40 tooling and a 15 / 18.5 kW (20.1 / 24.8 hp) motor. A dust-proof air-sealing system is standard. 15,000 rpm direct-drive and 15,000 rpm or 20,000 rpm built-in spindles are options.
04
The machine weighs 7,300 kg (16,093 lb). It needs a 35 kVA electrical supply and compressed air at 6 kg/cm². The coolant tank holds 440 L, and the axis motors are 4 / 4 / 4 kW.
