Litz VC-2000A(B)
Image: litzhitech.com, Litz
Key Specifications
Max Spindle
Tool Capacity
Table Size
Spindle Power
x axis travel
y axis travel
How much does the Litz VC-2000A(B) cost?
Price estimate
We do not have a price for the Litz VC-2000A(B) that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Litz VC-2000A(B) is the largest VC vertical machining center, with 2,000 mm (78.7 in) of X travel and a 2,100 x 850 mm (82.7 x 33.5 in) table that carries 3,000 kg (6,614 lb). Y travel is 900 mm (35.4 in) and Z is 800 mm (31.5 in).
Three tonnes on the table is the number that matters. No other vertical in the VC or VH ranges is rated that high; the VH-2000B, with the same X travel, lists 1,500 kg. For large die shoes, press plates, machine beds and welded frames, the VC-2000A(B) is the Litz C-frame to consider.
The table is also longer than the stroke, 2,100 mm against 2,000 mm of X, so a full-length workpiece can be clamped beyond the cutting zone at both ends.
Spindle figures follow the pattern of the bracketed VC models. The first values are 10,000 rpm and BT-40 with 30 tools; the bracketed ones are 6,000 rpm and BT-50 with 24 tools. Motor rating is 15 / 18.5 kW (20.1 / 24.8 hp), tool weight 15 kg (33 lb) and tool length 350 mm (13.8 in). Machine weight is given as 21,000 kg (46,296 lb), with 26,000 kg (57,319 lb) in brackets, a large gap that Litz should be asked to explain. X and Y rapids are 20 m/min (787 ipm). The coolant tank holds 550 L and supply is 42 kVA.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 2,000 mm (78.7 in) |
| Y Axis Travel | 900 mm (35.4 in) |
| Z Axis Travel | 800 mm (31.5 in) |
| Distance Spindle Nose to Table | 100 to 900 mm (3.9 to 35.4 in) |
| Max Spindle Speed | 10,000 rpm; in brackets: 6,000 rpm |
| Tool Capacity | 30; in brackets: 24 |
| Max Tool Diameter (full magazine) | 125 / 225 mm (4.9 / 8.9 in) |
| Max Tool Length | 350 mm (13.8 in) |
| Max Tool Weight | 15 kg (33 lb) |
| Tool Change Method | ARM |
| Tool Shank | BT-40(BT-50) |
| Spindle Motor Power | 15 / 18.5 kW (20.1 / 24.8 hp) |
| Axis Motors Xyz | 4 / 4 / 4 kW |
| Table Size | 2,100 x 850 mm (82.7 x 33.5 in) |
| Max Table Load | 3,000 kg (6,614 lb) |
| T-Slots | 7 x 18 x 100 mm |
| Rapid Traverse X | 20 m/min (787 ipm) |
| Rapid Traverse Y | 20 m/min (787 ipm) |
| Cutting Feed Rate | 1-20,000 mm/min (up to 787 ipm) |
| Machine Weight | 21,000 kg (46,296 lb); in brackets: 26,000 kg (57,319 lb) |
| Power Requirement | 42 kVA |
| Coolant Tank Capacity | 550 L |
| Compressed Air | 6 kg/cm² |
Specifications sourced from litzhitech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 3,000 kg (6,614 lb) table load, the highest among the VC and VH models
- 2,100 x 850 mm (82.7 x 33.5 in) table with 2,000 mm (78.7 in) of X travel
- 900 mm (35.4 in) of Y and 800 mm (31.5 in) of Z
- Tools up to 15 kg (33 lb) and 350 mm (13.8 in)
- 550 L coolant tank and a 42 kVA supply
Limitations
- X and Y rapids are 20 m/min (787 ipm)
- Machine weight is printed as 21,000 kg with 26,000 kg in brackets and needs clarifying
- Two spindle configurations share one column of the table
- 42 kVA supply; chip conveyor is optional
Best For
Frequently Asked Questions
01
3,000 kg (6,614 lb). The table is 2,100 x 850 mm (82.7 x 33.5 in) with T-slots listed as 7 x 18 x 100 mm, and spindle nose to table distance is 100 to 900 mm (3.9 to 35.4 in).
02
The table prints 10,000 rpm with BT-40 and, in brackets, 6,000 rpm with BT-50. The motor is 15 / 18.5 kW (20.1 / 24.8 hp). The accessory list marks a 10,000 rpm belt spindle, BT-40 and a 30T magazine as standard, with a 40T magazine optional.
03
The table gives 21,000 kg (46,296 lb) and, in brackets, 26,000 kg (57,319 lb). Foundation planning should use the figure Litz confirms for the configuration ordered. The supply requirement is 42 kVA.
04
Both have 2,000 x 900 x 800 mm travels. The VC-2000A(B) carries 3,000 kg (6,614 lb) and moves at 20 m/min in X and Y. The VH-2000B carries 1,500 kg (3,307 lb) and moves at 36 m/min, with an 8,000 rpm direct-drive BBT-50 spindle.
