Litz VH-2000A

Q: How much does the Litz VH-2000A cost?

The price estimate for the Litz VH-2000A is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/litz-vh-2000a#price; the request is passed to Litz or an authorised dealer.

Specs verified 2026-10-04 · litzhitech.com Updated 2026-10-04

Litz VH series vertical machining center (VH-2000A)

Image: litzhitech.com, Litz

Key Specifications

Max Spindle

12,000 rpm

Tool Capacity

Table Size

1,700 x 850 mm (66.9 x 33.5 in)

Spindle Power

15 / 18.5 kW (20.1 / 24.8 hp) (continuous / 30 min rated)

x axis travel

2,000 mm (78.7 in)

y axis travel

900 mm (35.4 in)

How much does the Litz VH-2000A cost?

Price estimate

Uncertain

We do not have a price for the Litz VH-2000A that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Litz VH-2000A offers the longest X travel in the VH vertical machining center series at 2,000 mm (78.7 in), together with 900 mm (35.4 in) of Y and 800 mm (31.5 in) of Z. It uses a 12,000 rpm direct-drive spindle with BBT-40 tooling.

There is a point to check before ordering. The specification table gives the same 1,700 x 850 mm (66.9 x 33.5 in) table for the VH-2000A as for the VH-1600A, although X travel is longer here. Ask Litz to confirm the table length for this model, since fixture planning depends on it. Table load is listed as 1,500 kg (3,307 lb).

Two metres of X at 12,000 rpm points to long aluminium parts: beams, rails, extrusions and plate that would otherwise need repositioning. The spindle motor is 15 / 18.5 kW (20.1 / 24.8 hp), and tools are limited to 7 kg (15 lb), so this is not the model for heavy roughing with large holders. The VH-2000B covers that.

The standard magazine holds 30 tools and a 40T arm type magazine is an option. Rapids are 36 / 36 / 24 m/min (1,417 / 1,417 / 945 ipm) with 4 / 4 / 4 kW axis motors. On a 2,000 mm axis, the optional coolant through the ballscrews and linear scales deserve a serious look if positional accuracy over the whole stroke matters. Machine weight is 19,000 kg (41,887 lb).

Full Specifications

Parameter	Value
X Axis Travel	2,000 mm (78.7 in)
Y Axis Travel	900 mm (35.4 in)
Z Axis Travel	800 mm (31.5 in)
Distance Spindle Nose to Table	100 to 900 mm (3.9 to 35.4 in)
Max Spindle Speed	12,000 rpm
Tool Capacity	30
Max Tool Diameter (full magazine)	80 / 150 mm (3.1 / 5.9 in)
Max Tool Length	300 mm (11.8 in)
Max Tool Weight	7 kg (15 lb)
Tool Change Method	ARM
Tool Shank	BBT-40
Spindle Motor Power	15 / 18.5 kW (20.1 / 24.8 hp) (continuous / 30 min rated)
Axis Motors Xyz	4 / 4 / 4 kW
Table Size	1,700 x 850 mm (66.9 x 33.5 in)
Max Table Load	1,500 kg (3,307 lb)
T-Slots	7 x 18 mm x 100 mm (number x width x distance from the center)
CNC Control	FANUC 0i-MF PLUS 3
Machine Weight	19,000 kg (41,887 lb)
Coolant Tank Capacity	500 L
Power Requirement	42 kVA
Compressed Air	6 kg/cm²
Rapid Traverse Xyz	36 / 36 / 24 m/min (1,417 / 1,417 / 945 ipm)

Specifications sourced from litzhitech.com — verified 2026-10-04

Strengths & Limitations

Strengths

2,000 mm (78.7 in) of X travel with 900 mm (35.4 in) of Y
12,000 rpm direct-drive BBT-40 spindle, 15 / 18.5 kW (20.1 / 24.8 hp)
30 tools standard, 40T magazine optional
36 / 36 / 24 m/min (1,417 / 1,417 / 945 ipm) rapids

Limitations

Listed table size of 1,700 x 850 mm is shorter than the X travel and should be confirmed
Tools limited to 7 kg (15 lb) and 300 mm (11.8 in)
Table load of 1,500 kg (3,307 lb)
Linear scales and coolant through the ballscrews are options

Best For

Long aluminium beams, rails and plates up to 2,000 mm Aerospace-style structural parts with small to medium cutters Multi-station setups along a long X axis

Frequently Asked Questions

01 How long is the X travel on the Litz VH-2000A?

2,000 mm (78.7 in). Y travel is 900 mm (35.4 in) and Z travel is 800 mm (31.5 in), with 100 to 900 mm (3.9 to 35.4 in) between the spindle nose and the table.

02 What table does the VH-2000A have?

The specification table lists 1,700 x 850 mm (66.9 x 33.5 in) with seven 18 mm T-slots and a 1,500 kg (3,307 lb) load. That is the figure also printed for the VH-1600A, so confirm the table length with Litz for the 2,000 mm model.

03 What is the difference between the VH-2000A and VH-2000B?

The VH-2000A is BBT-40 at 12,000 rpm with 30 tools and a 7 kg (15 lb) tool limit. The VH-2000B is BBT-50 at 8,000 rpm with 24 tools and a 15 kg (33 lb) limit, and weighs 21,000 kg (46,296 lb) against 19,000 kg for the VH-2000A.

04 Which spindle options are offered on the VH-2000A?

Standard is the 12,000 rpm direct-drive spindle. A 15,000 rpm direct-drive spindle and built-in spindles at 15,000 rpm and 20,000 rpm are listed as options; the built-in spindles need the spindle water chiller.
