Biglia BMX 80-Y2
Key Specifications
Max Spindle
Spindle Power
Max Turn Length
bar capacity
max turning diameter
swing over diameter
How much does the Biglia BMX 80-Y2 cost?
Price estimate
We do not have a price for the Biglia BMX 80-Y2 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Biglia's brochure for the BMX twin-turret line has a third column beside the 51 and 70 mm machines: the BMX 80-Y2, with 80 mm (3.1 in) bar capacity and an ASA 8" main spindle. It is the torque version of the family. Maximum torque is 441 / 477 Nm (325 / 352 lb-ft), motor power 23 / 25 kW and top speed 3,500 rpm.
What changes from the smaller sizes is confined to the main spindle. The bore grows to 91 mm and the bearings to 130 mm inside diameter. The frame does not grow with them. Maximum machining diameter stays at 270 mm and machining length at 640 mm, the turrets keep 15 stations each, and the X strokes remain 180 mm. So this is not a bigger machine in the usual sense. It is the same machine set up for thicker bar and slower, heavier cuts.
That has consequences worth thinking through. An 80 mm bar is far smaller than the 270 mm machining diameter, so the envelope is no constraint for bar work. The second spindle is the tighter spot: it is the ASA 5" unit of the whole range, with a 59.5 mm bore, a 50 mm drawtube, 17 / 25 kW and 108 / 159 Nm. Back-end operations on a part turned from 80 mm stock must suit a spindle designed around 51 mm bar.
The weight is 11,300 kg with swarf conveyor, on a footprint of 5,300 x 2,235 mm. Control is the FANUC 31i-mod. B Plus iHMI named in the brochure.
Full Specifications
| Parameter | Value |
|---|---|
| Bar Capacity | 80 mm (3.1 in) |
| Max Turning Diameter | 270 mm (10.6 in) |
| Max Turning Length | 640 mm (25.2 in) |
| Swing Over Diameter | 270 mm (10.6 in) |
| Max Spindle Speed | 3,500 rpm |
| Spindle Nose | ASA 8" |
| Spindle Bore | 91 mm (3.6 in) |
| Spindle Bearing Inside Diameter | 130 mm (5.1 in) |
| Chuck Size | 210 / 250 mm (8.3 / 9.8 in) |
| Spindle Motor Power | 23 / 25 kW (30.8 / 33.5 hp) |
| Spindle Torque | 441 / 477 Nm (325 / 352 lb-ft) |
| C Axis Min Programmable Value | 0.001° |
| Sub Spindle Speed | 5,000 rpm |
| Sub Spindle Nose | ASA 5" |
| Sub Spindle Bore | 59.5 mm (2.3 in) |
| Sub Spindle Drawtube Inside Diameter | 50 mm (2.0 in) |
| Sub Spindle Bearing Inside Diameter | 90 mm (3.5 in) |
| Sub Spindle Chuck Size | 165 / 210 mm (6.5 / 8.3 in) |
| Sub Spindle Power | 17 / 25 kW (22.8 / 33.5 hp) |
| Sub Spindle Torque | 108 / 159 Nm (80 / 117 lb-ft) |
| Turret Stations | 15 per turret (upper turret 1, lower turret 2) |
| Turret Indexing Time | 0.15 sec (1 position) |
| Live Tool Stations | 15 |
| Live Tool Speed | 6,000 / 10,000 rpm |
| Live Tool Power | 11 / 12.5 kW (14.8 / 16.8 hp) |
| Live Tool Torque | 30 / 34.5 Nm (22 / 25 lb-ft) |
| X1 X2 Axis Travel | 180 mm (7.1 in) |
| Rapid Traverse X1 X2 | 18 m/min (709 ipm) |
| Z1 Z2 Axis Travel | 640-540 mm (25.2-21.3 in) |
| Rapid Traverse Z1 Z2 | 30 m/min (1,181 ipm) |
| Y1 Y2 Axis Travel | 90 mm (3.5 in) |
| Rapid Traverse Y1 Y2 | 9 m/min (354 ipm) |
| Coolant Tank Capacity | 500 L (132.1 gal) |
| Coolant Pumps Power | 3.7 kW (5.0 hp) (power rating of 3 electropumps) |
| Machine Dimensions | 5,300 x 2,235 x 2,380 mm (208.7 x 88.0 x 93.7 in), with swarf conveyor (last figure is the height) |
| Spindle Centre Height | 1,280 mm (50.4 in) |
| Machine Weight | 11,300 kg (24,912 lb) with swarf conveyor |
| CNC Control | FANUC 31i-mod. B Plus iHMI |
Specifications sourced from bigliaspa.it — verified 2026-10-05
Strengths & Limitations
Strengths
- Largest bar capacity of the BMX line at 80 mm, through a 91 mm bore
- 441 / 477 Nm of main-spindle torque for large bar in tough materials
- Same two 15-station turrets with 90 mm Y axes as the smaller sizes
- Coolant tank of 500 L fed by 3 electropumps with a combined rating of 3.7 kW
- 45° slant cast-iron bed, listed by Biglia as a main benefit of the line
Limitations
- Top speed of 3,500 rpm, against 4,500 rpm on the BMX 70-Y2
- Motor power of 23 / 25 kW is lower than the 30 / 40 kW of the BMX 70-Y2
- Sub-spindle remains ASA 5" with a 50 mm drawtube and 108 / 159 Nm
- Heaviest of the three at 11,300 kg
Best For
Frequently Asked Questions
01
80 mm, the largest in Biglia's BMX table. The main spindle has an ASA 8" nose, a 91 mm bore and bearings of 130 mm inside diameter, and takes 210 / 250 mm chucks. Biglia's brochure labels it the ASA 8 main spindle for 80 mm bar capacity.
02
Not according to the table. Both list 5,300 x 2,235 x 2,380 mm with swarf conveyor, a 1,280 mm spindle centre height, a 270 mm machining diameter and a 640 mm machining length. The BMX 80-Y2 weighs 11,300 kg and the BMX 70-Y2 11,000 kg.
03
They are far apart. The main spindle delivers 441 / 477 Nm at up to 3,500 rpm with 23 / 25 kW. The sub-spindle is rated 108 / 159 Nm and 17 / 25 kW, but turns faster at 5,000 rpm. Use the main side for heavy turning and drilling, and the second side for finishing, small drilling and light milling.
04
Yes. Among the main advantages Biglia lists 4-axis turning using both turrets on the main spindle for simultaneous operation, and simultaneous machining with three tools through the Superimposition function. The sub-spindle moves on Z3 and X3 so that the turrets do not interfere with each other.
