AWEA LG-10050
Image: awea.com, AWEA
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
x axis travel
How much does the AWEA LG-10050 cost?
Price estimate
We do not have a price for the AWEA LG-10050 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The AWEA LG-10050 is the middle of three LG gantry machines with 10,000 mm (393.7 in) of X travel. Its crossbeam gives 5,000 mm (196.9 in) of Y, the fixed table measures 10,000 x 4,800 mm (393.7 x 189.0 in), and Z travel is 1,000 mm (39.4 in).
Length is not what separates the three, so width decides. The LG-10040 has a 10,000 x 3,800 mm (393.7 x 149.6 in) table and 4,000 mm (157.5 in) of Y. The LG-10070 has a 10,000 x 6,800 mm (393.7 x 267.7 in) table and 7,000 mm (275.6 in) of Y. Along X all three list the same VDI figures, P = 0.050 mm and Ps = 0.038 mm, with the same 20 m/min (787 ipm) rapid.
Across the beam they differ. Y rapid is 15 m/min (591 ipm) on the LG-10040, 12 m/min (472 ipm) on this machine and 10 m/min (394 ipm) on the LG-10070. The LG-10040 holds P = 0.030 mm on Y/Z over full travel where the LG-10050 lists P = 0.040 mm. Coolant capacity steps from 1,600 liter on the LG-10040 to 1,900 liter here and 2,100 liter on the LG-10070. Buying more width than the work needs costs traverse time on every cross move.
With a table this long, several workpieces can be set up in a row and one can be loaded while another is cut, since the table itself never moves. Chips leave by two rotating augers, one down each side of the table, into a separate coolant tank. The magazine stands on the floor behind the machine with 32 pockets, or 60 as an option.
Spindle choices match the other LG sizes: a 4,000 rpm gear spindle as standard with a CAT50 (7 / 24) taper and 22 / 26 kW (30 / 35 HP), plus optional gear and built-in units up to 8,000 rpm.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 10,000 mm (393.7 in) |
| Y Axis Travel | 5,000 mm (196.9 in) |
| Z Axis Travel | 1,000 mm (39.4 in) |
| Table Size | 10,000 x 4,800 mm (393.7 x 189.0 in) |
| Max Table Load | 2,500 kg/m² |
| Distance Spindle Nose to Table | 200 ~ 1,200 mm (7.9 ~ 47.2 in) |
| Distance Between Columns with Water Eliminator | 5,800 (5,500) |
| Spindle Motor Power | 22 / 26 kW (30 / 35 HP) |
| Max Spindle Speed | Gear 4,000 rpm (Std.) ; Gear 5,000 / 6,000 rpm (Opt.) ; Built-in 6,000 / 8,000 rpm (Opt.) |
| Spindle Taper | CAT50 (7 / 24) |
| Rapid Traverse X | 20 m/min (787 ipm) |
| Rapid Traverse Y | 12 m/min (472 ipm) |
| Rapid Traverse Z | 10 m/min (394 ipm) |
| Cutting Feed Rate | 1 ~ 10 m/min (39 ~ 394 ipm) |
| Tool Capacity | 32 (60 Opt.) |
| Max Tool Diameter (full magazine) | Ø127 / 215 mm (Ø5.0 / 8.5 in) |
| Max Tool Length | 350 mm (13.8 in) |
| Max Tool Weight | 20 kg (44 lb) |
| Positioning Accuracy Jis B 6338 | ± 0.025 / Full Travel |
| Positioning Accuracy VDI 3441 | P = 0.050 mm |
| Positioning Accuracy Yz VDI 3441 | P = 0.040 mm / Full Travel |
| Repeatability Jis B 6338 | ± 0.003 mm |
| Repeatability VDI 3441 | Ps = 0.038 mm |
| Repeatability Yz VDI 3441 | Ps = 0.030 mm |
| Power Requirement | 80 kVA 220 ±10 % Vac 3 phase 50 / 60 Hz |
| Air Pressure Requirement | 5 ~ 8 (5) kg/cm² |
| Hydraulic Tank Capacity | 120 liter |
| Lubrication Tank Capacity | 6 liter |
| Coolant Tank Capacity | 1,900 liter |
Specifications sourced from awea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 10,000 x 4,800 mm (393.7 x 189.0 in) fixed table at 2,500 kg/m², long enough for several setups in a row
- Faster across the beam than the LG-10070: 12 m/min (472 ipm) Y rapid against 10 m/min (394 ipm)
- 20 m/min (787 ipm) X rapid, the same as the LG-6050 and LG-8050
- Two chip augers along the table and a 1,900 liter separate coolant tank
- Gantry layout that AWEA says uses 40% less space than bridge type models
Limitations
- X positioning under the VDI standard is P = 0.050 mm with Ps = 0.038 mm, wider than the P = 0.040 mm of the LG-8050
- Y/Z positioning of P = 0.040 mm over full travel; the LG-10040 lists P = 0.030 mm
- Table width of 4,800 mm; parts wider than that need the LG-10070
- Z travel stays at 1,000 mm (39.4 in) however long the machine is
Best For
Frequently Asked Questions
01
X travel is 10,000 mm (393.7 in) on all of them. The LG-10040 has 4,000 mm (157.5 in) of Y travel and a Y rapid of 15 m/min (591 ipm). The LG-10050 has 5,000 mm (196.9 in) and 12 m/min (472 ipm). The LG-10070 has 7,000 mm (275.6 in) and 10 m/min (394 ipm), so the cross axis slows as it widens. The X-axis accuracy figures are identical at P = 0.050 mm and Ps = 0.038 mm.
02
03
AWEA describes a separate type coolant tank and two rotating chip augers on both sides of the working table. The coolant tank capacity of the LG-10050 is 1,900 liter. The hydraulic tank holds 120 liter and the lubrication tank 6 liter.
04
The row is printed as 5,800 (5,500), where the figure in brackets applies with the water eliminator. The table between them is 4,800 mm wide and Y travel is 5,000 mm (196.9 in). On the LG-10070 the same row reads 7,800 mm (7,500 mm).
