Vision Wide XML-47

Q: How much does the Vision Wide XML-47 cost?

The price estimate for the Vision Wide XML-47 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-xml-47#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Key Specifications

Tool Capacity

32/40 pcs(Opt.)/60 pcs(Opt.)

Table Size

4×(8~60) m

x axis travel

8,200(+1m)~60,200 mm

y axis travel

4,700 mm (185.0 in)

z axis travel

1,500 / 1,800 mm (59.1 / 70.9 in) (Opt.) / 2,000 mm (78.7 in) (Opt.) / 2,200 mm (86.6 in) (Opt.)

ram size

580x580 mm (22.8x22.8 in)

How much does the Vision Wide XML-47 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide XML-47 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

Tool handling is configurable on the Vision Wide XML-47, to the point that the machine can be ordered with no magazine at all. The option list includes the entry "Without tool magazine" beside the magazines themselves.

The standard is a vertical type tool magazine with 32 tools. Options are the same type with 40 or 60 tools, and a vertical-horizontal type with 32, 40 or 60, which serves an attachment head in the horizontal position as well as the vertical spindle. Why would anyone leave the magazine off? On very long, simple parts, such as rails or beams machined with two or three tools, manual changes are few, and some shops prefer to keep the travelling column light and simple.

For five-sided work the vertical-horizontal type is the relevant one. The option list also notes a spindle ring cutting coolant device for the vertical spindle with no head attachment, which confirms head attachments are part of the XML's intended use.

The XML-47 has 4,700 mm (185.0 in) of Y travel and takes a workpiece 4,600 mm (181.1 in) wide. The table is listed as 4×(8~60) m. Z travel is 1,500 mm, with options to 2,200 mm, in a 580x580 mm (22.8x22.8 in) ram. Rapids are 20/20/12 m/min.

Full Specifications

Parameter	Value
X Axis Travel	8,200(+1m)~60,200 mm
Y Axis Travel	4,700 mm (185.0 in)
Z Axis Travel	1,500 / 1,800 mm (59.1 / 70.9 in) (Opt.) / 2,000 mm (78.7 in) (Opt.) / 2,200 mm (86.6 in) (Opt.)
Ram Size	580x580 mm (22.8x22.8 in)
Distance Spindle Nose to Table Z 1500 Std	850~2,350 mm (33.5~92.5 in)
Distance Spindle Nose to Table Z 1800	850~2,650 mm (33.5~104.3 in)
Max Workpiece Width	4,600 mm (181.1 in)
Table Size	4×(8~60) m
Spindle Power Cont 30 Min	22/26 kW (29.5/34.9 hp)
Spindle Speed 2 Step Gear	4,000/ 6,000 rpm (Opt.)
Spindle Speed Built in Motor	8,000 rpm (Opt.) / 12,000 rpm (Opt.)
Cutting Feed Rate	1-10,000 mm/min
Rapid Traverse Xyz	20/20/12 m/min
Tool Capacity	32/40 pcs(Opt.)/60 pcs(Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

Vertical type magazines of 32, 40 or 60 tools
Vertical-horizontal type magazine available for head attachment work
Can be ordered without a tool magazine
Y travel of 4,700 mm (185.0 in) and workpiece width of 4,600 mm (181.1 in)

Limitations

Vertical-horizontal magazines are optional
The page does not list the head attachments
Cutting feed of 1-10,000 mm/min

Best For

Five-sided machining of large structures Simple long parts run with few tools Workpieces up to 4,600 mm (181.1 in) wide

Frequently Asked Questions

01 What tool magazines are available for the Vision Wide XML-47?

Standard: vertical type tool magazine 32 tools. Optional: vertical type 40 / 60 tools, vertical-horizontal type 32 / 40 / 60 tools, or a machine without tool magazine.

02 What are the XML-47 travels?

X is 8,200(+1m)~60,200 mm, Y is 4,700 mm (185.0 in), and Z is 1,500 mm with 1,800 mm, 2,000 mm and 2,200 mm as options.

03 How wide a part fits the XML-47?

The maximum workpiece width is 4,600 mm (181.1 in). The table is listed as 4×(8~60) m. The XML-42 takes 4,100 mm (161.4 in) and the XML-57 takes 5,600 mm (220.5 in).

04 Can the XML-47 use attachment heads?

The option list includes a vertical-horizontal type tool magazine and a spindle ring coolant device for machines with no head attachment, which implies attachments. The heads themselves are not listed on the page.
