Vision Wide VBT-110-1618
Image: visionwide-tech.com, Vision Wide
Key Specifications
Max Spindle
Table Size
x axis travel
y axis travel
z axis travel
w axis travel
How much does the Vision Wide VBT-110-1618 cost?
Price estimate
We do not have a price for the Vision Wide VBT-110-1618 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Two VBT models share the 1,600 x 1,800 mm (63.0 x 70.9 in) table, and the Vision Wide VBT-110-1618 is the lighter-spindled, faster one. It lists 3,500 rpm, 18.5 / 22 kW (24.8 / 29.5 hp) and 972 / 1,155 Nm (717 / 852 lb-ft), with a W axis of 550 mm (21.7 in).
The other is the VBT-130-1618: 3,000 rpm, 22 / 30 kW (29.5 / 40.2 hp), 1,444 / 1,970 Nm (1,065 / 1,453 lb-ft) and a 700 mm (27.6 in) W axis, with optional Y and Z strokes that this model does not have.
Both carry 15,000 kg, or 20,000 kg (44,092 lb) as an option. So the choice is about the cut, not the part. If the work is mostly boring to size, drilling and light milling in cast iron or aluminum, the 110 spindle does it with a higher top speed. If it includes heavy face milling in steel, the 130 is the one to quote.
On this model Y travel is 2,000 mm (78.7 in) and Z travel 1,500 mm (59.1 in), both without options; X is 2,000 mm, or 2,500 mm. The structure is the VBT's Y-axis box way design. The VBH-110-1618 has the same table of figures on a box in box frame.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 2,000 / 2,500 mm (78.7 / 98.4 in) (Opt.) |
| Y Axis Travel | 2,000 mm (78.7 in) |
| Z Axis Travel | 1,500 mm (59.1 in) |
| W Axis Travel | 550 mm (21.7 in) |
| Table Size | 1,600 x 1,800 mm (63.0 x 70.9 in) |
| Max Table Load Central Area | 15,000 / 20,000 kg (33,069 / 44,092 lb) (Opt.) |
| Distance Spindle Nose to Table Center | -25~525~2,025 mm (-1.0~20.7~79.7 in) |
| Distance Spindle Center to Table Surface | 0~2,000 mm (0~78.7 in) |
| Max Spindle Speed | 3,500 rpm |
| Spindle Power Cont 30 Min | 18.5 / 22 kW (24.8 / 29.5 hp) |
| Spindle Torque Cont 30 Min | 972 / 1,155 Nm (717 / 852 lb-ft) |
Specifications sourced from visionwide-tech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 3,500 rpm top speed on a table rated for up to 20,000 kg (44,092 lb)
- 1,600 x 1,800 mm (63.0 x 70.9 in) table
- Standard Y travel of 2,000 mm (78.7 in)
- Y-axis box way structure design
Limitations
- 972 / 1,155 Nm (717 / 852 lb-ft), well below the 1,444 / 1,970 Nm (1,065 / 1,453 lb-ft) of the VBT-130-1618
- No Y or Z travel options on this model
- W axis of 550 mm (21.7 in)
Best For
Frequently Asked Questions
01
The table and load are the same. The VBT-110-1618 has 3,500 rpm and 972 / 1,155 Nm (717 / 852 lb-ft); the VBT-130-1618 has 3,000 rpm, 1,444 / 1,970 Nm (1,065 / 1,453 lb-ft) and a 700 mm (27.6 in) W axis.
02
15,000 / 20,000 kg (33,069 / 44,092 lb) (Opt.) in the central area, on a 1,600 x 1,800 mm (63.0 x 70.9 in) table.
03
X 2,000 / 2,500 mm (78.7 / 98.4 in) (Opt.), Y 2,000 mm (78.7 in), Z 1,500 mm (59.1 in) and W 550 mm (21.7 in). Only X has an optional longer stroke.
04
They have the same specification table. Vision Wide's feature text gives the VBT a Y-axis box way structure design and the VBH a box in box structure.
