Vision Wide VBT-110-1250
Image: visionwide-tech.com, Vision Wide
Key Specifications
Max Spindle
Table Size
x axis travel
y axis travel
z axis travel
w axis travel
How much does the Vision Wide VBT-110-1250 cost?
Price estimate
We do not have a price for the Vision Wide VBT-110-1250 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
On the Vision Wide VBT-110-1250 the boring spindle can be fed past the centre of the table. The maker's row for the distance from spindle nose to table center reads -125~425~1,925 mm (-4.9~16.7~75.8 in), and the negative first value is the nose position with the W axis fully out and the table at its nearest.
For boring work that is a useful property. A bore on the centreline of a housing can be reached with the tool held close in the spindle, and a through-bore can be finished from one side to beyond the middle before the part is turned. The W axis gives 550 mm (21.7 in) of that reach.
The VBT is a horizontal boring and milling machine whose structure Vision Wide describes as a high stability, high precision Y-axis box way design. This model has a 1,250 x 1,250 mm (49.2 x 49.2 in) table for 5,000 kg (11,023 lb), with 2,000 mm of X travel, or 2,500 mm as an option, 1,600 mm of Y, or 2,000 mm, and 1,500 mm (59.1 in) of Z.
The spindle runs to 3,500 rpm with 18.5 / 22 kW (24.8 / 29.5 hp) and 972 / 1,155 Nm (717 / 852 lb-ft). Every figure here also appears in the table for the VBH-110-1250, a box in box machine; the maker's text is the only place the two are told apart.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 2,000 / 2,500 mm (78.7 / 98.4 in) (Opt.) |
| Y Axis Travel | 1,600 / 2,000 mm (63.0 / 78.7 in) (Opt.) |
| Z Axis Travel | 1,500 mm (59.1 in) |
| W Axis Travel | 550 mm (21.7 in) |
| Table Size | 1,250 x 1,250 mm (49.2 x 49.2 in) |
| Max Table Load Central Area | 5,000 kg (11,023 lb) |
| Distance Spindle Nose to Table Center | -125~425~1,925 mm (-4.9~16.7~75.8 in) |
| Distance Spindle Center to Table Surface | 0~1,600 / 0~2,000 mm (0~63.0 / 0~78.7 in) (Opt.) |
| Max Spindle Speed | 3,500 rpm |
| Spindle Power Cont 30 Min | 18.5 / 22 kW (24.8 / 29.5 hp) |
| Spindle Torque Cont 30 Min | 972 / 1,155 Nm (717 / 852 lb-ft) |
Specifications sourced from visionwide-tech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Spindle nose can pass the table centre, per the nose-to-centre distance row
- Y-axis box way structure design, as described by the maker
- 3,500 rpm with 972 / 1,155 Nm (717 / 852 lb-ft)
- Z travel of 1,500 mm (59.1 in) and W travel of 550 mm (21.7 in)
Limitations
- Table load of 5,000 kg (11,023 lb) in the central area only
- Specification table identical to the VBH-110-1250, with little guidance on choosing between them
- No feed, rapid, tool magazine or control data is published
Best For
Frequently Asked Questions
01
Spindle nose to table center is listed as -125~425~1,925 mm (-4.9~16.7~75.8 in). The negative value shows the nose can travel beyond the table centre. W-axis travel is 550 mm (21.7 in).
02
None in the specification tables. Vision Wide describes the VBT as a Y-axis box way structure design and the VBH as a box in box structure. Ask the maker which suits the work.
03
X 2,000 / 2,500 mm (78.7 / 98.4 in) (Opt.), Y 1,600 / 2,000 mm (63.0 / 78.7 in) (Opt.), Z 1,500 mm (59.1 in). The table is 1,250 x 1,250 mm (49.2 x 49.2 in) and carries 5,000 kg (11,023 lb).
04
A 3,500 rpm spindle with 18.5 / 22 kW (24.8 / 29.5 hp) and 972 / 1,155 Nm (717 / 852 lb-ft), continuous and short-time ratings in each pair.
