Vision Wide Vertical Machining Centers (VMC)

Vision Wide NF-5026 / NF-5033

Q: How much does the Vision Wide NF-5026 / NF-5033 cost?

The price estimate for the Vision Wide NF-5026 / NF-5033 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-nf-5026-nf-5033#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

5,000×2,450 mm (196.9×96.5 in)

x axis travel

5,100 mm (200.8 in)

y axis travel

2,600/ 3,300 mm (102.4/ 129.9 in)

z axis travel box way single ballscrew

920 / 1,020 mm (36.2 / 40.2 in)(Opt.)

z axis travel linear way enclosed box ram dual ballscrews

1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)

max table load

20,000 kg (44,092 lb)

How much does the Vision Wide NF-5026 / NF-5033 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide NF-5026 / NF-5033 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Vision Wide NF-5026 / NF-5033 is a five-metre, 20,000 kg (44,092 lb) bridge machine with a 5,000×2,450 mm (196.9×96.5 in) table. X travel is 5,100 mm (200.8 in). Y travel is 2,600 mm (102.4 in) for the NF-5026 and 3,300 mm (129.9 in) for the NF-5033.

Coolant needs a second look on a five-face machine. The NF option list has a spindle ring cutting coolant device, but notes it is for machines with no head attachment. Once a 90º or universal head is on the spindle, the ring is behind it. The options that still reach the cut are the coolant through spindle system 20/70 bar, the interface for it, and a coolant through tool holder interface; an oil mist cooling device is listed too.

Is through-spindle coolant passed on through the attachment heads? The page does not say, and it is the question to put to Vision Wide before choosing the coolant package for side-face drilling.

A cutting fluid cooling system and a spindle cooling system are standard, as are table-side screw conveyors and a caterpillar type chip conveyor. X/Y rapid is 12.5 m/min. The spindle is the 4,000 rpm geared type as standard, on 18.5/22 kW (24.8/29.5 hp).

Full Specifications

Parameter	Value
X Axis Travel	5,100 mm (200.8 in)
Y Axis Travel	2,600/ 3,300 mm (102.4/ 129.9 in)
Z Axis Travel Box Way Single Ballscrew	920 / 1,020 mm (36.2 / 40.2 in)(Opt.)
Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews	1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)
Table Size	5,000×2,450 mm (196.9×96.5 in)
Max Table Load	20,000 kg (44,092 lb)
Spindle Power Cont 30 Min	18.5/22 kW (24.8/29.5 hp)(22/26 kW (29.5/34.9 hp) Opt.)(30/37 kW (40.2/49.6 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram Direct Driven	10,000 rpm(Opt.)
Cutting Feed Rate	1-10,000 mm/min
Rapid Traverse Xy	12.5 m/min
Rapid Traverse Z Box Way or Linear Way	15 m/min
Rapid Traverse Z Enclosed Box Ram	12 m/min
Tool Capacity Vertical Tool Change	32 / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Horizontal Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

5,000×2,450 mm (196.9×96.5 in) table for 20,000 kg (44,092 lb)
Coolant through spindle system 20/70 bar available
Cutting fluid cooling and spindle cooling systems are standard
Y travel of up to 3,300 mm (129.9 in) on the NF-5033

Limitations

Spindle ring cutting coolant device is only for machines with no head attachment
The page does not say whether coolant passes through the attachment heads
X/Y rapid is 12.5 m/min on the five-metre bed

Best For

Large housings and frames machined on five faces Deep drilling with through-spindle coolant on the vertical spindle Workpieces up to 20,000 kg (44,092 lb)

Frequently Asked Questions

01 What coolant options does the Vision Wide NF-5026 have?

Optional: a spindle ring cutting coolant device (for no head attachment), a coolant through spindle system 20/70 bar, the interface of coolant through spindle, a coolant through tool holder interface and an oil mist cooling device. A cutting fluid cooling system is standard.

02 What is the table load of the NF-5026 / NF-5033?

20,000 kg (44,092 lb) on a 5,000×2,450 mm (196.9×96.5 in) table. The four-metre NF-4026 is rated for 16,000 kg (35,273 lb).

03 What Y travel does the NF-5033 have?

3,300 mm (129.9 in). The NF-5026 in the same column has 2,600 mm (102.4 in). The table is 2,450 mm (96.5 in) wide under both.

04 What are the rapid traverse rates of the NF-5026?

12.5 m/min in X/Y. In Z, 15 m/min with the box way or linear way head and 12 m/min with the enclosed box ram. The cutting feed range is 1-10,000 mm/min.
