Vision Wide Vertical Machining Centers (VMC)

Vision Wide NF-3026 / NF-3033

Q: How much does the Vision Wide NF-3026 / NF-3033 cost?

The price estimate for the Vision Wide NF-3026 / NF-3033 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-nf-3026-nf-3033#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

3,000×2,450 mm (118.1×96.5 in)

x axis travel

3,100 mm (122.0 in)

y axis travel

2,600/ 3,300 mm (102.4/ 129.9 in)

z axis travel box way single ballscrew

920 / 1,020 mm (36.2 / 40.2 in)(Opt.)

z axis travel linear way enclosed box ram dual ballscrews

1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)

max table load

13,000 kg (28,660 lb)

How much does the Vision Wide NF-3026 / NF-3033 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide NF-3026 / NF-3033 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

A wider table is what the Vision Wide NF-3026 / NF-3033 adds to the three-metre NF. It measures 3,000×2,450 mm (118.1×96.5 in), against the 3,000×2,050 mm (118.1×80.7 in) of the NF-3023, and Y travel is 2,600 mm (102.4 in) on the NF-3026 or 3,300 mm (129.9 in) on the NF-3033.

The load rating does not move. Both widths carry 13,000 kg (28,660 lb). The extra table width is therefore room, not strength: space for a wider die, for clamps outside the part outline, or for two narrow parts side by side.

Vision Wide credits the NF with a high rigidity box base and what it calls the best span of work table guideways. A wide guideway span matters more as the table widens, because a heavy part placed off-centre tries to tilt the table, and the further apart the ways are, the less it can.

X travel is 3,100 mm (122.0 in) and the X/Y rapid is 24 m/min. The standard build is the box way head with a 4,000 rpm geared spindle and 18.5/22 kW (24.8/29.5 hp), a vertical type tool magazine with 32 tools and a FANUC 0iMF PLUS controller.

Full Specifications

Parameter	Value
X Axis Travel	3,100 mm (122.0 in)
Y Axis Travel	2,600/ 3,300 mm (102.4/ 129.9 in)
Z Axis Travel Box Way Single Ballscrew	920 / 1,020 mm (36.2 / 40.2 in)(Opt.)
Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews	1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)
Table Size	3,000×2,450 mm (118.1×96.5 in)
Max Table Load	13,000 kg (28,660 lb)
Spindle Power Cont 30 Min	18.5/22 kW (24.8/29.5 hp)(22/26 kW (29.5/34.9 hp) Opt.)(30/37 kW (40.2/49.6 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram Direct Driven	10,000 rpm(Opt.)
Cutting Feed Rate	1-10,000 mm/min
Rapid Traverse Xy	24 m/min
Rapid Traverse Z Box Way or Linear Way	15 m/min
Rapid Traverse Z Enclosed Box Ram	12 m/min
Tool Capacity Vertical Tool Change	32 / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Horizontal Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

3,000×2,450 mm (118.1×96.5 in) table, wider than the NF-3023
Y travel of 2,600 mm (102.4 in) or 3,300 mm (129.9 in)
X/Y rapid of 24 m/min, the fastest NF figure
High rigidity box base, per the maker's description

Limitations

Table load stays at 13,000 kg (28,660 lb) despite the wider table
X travel of 3,100 mm (122.0 in) is the shortest NF length
The 6,000 rpm gear spindle is optional

Best For

Wide dies and plates up to 2,450 mm (96.5 in) across Two narrow parts set side by side Five-face work on parts up to 13,000 kg (28,660 lb)

Frequently Asked Questions

01 How wide is the Vision Wide NF-3026 table?

The table is 3,000×2,450 mm (118.1×96.5 in). The NF-3023, with the same X travel, has a 3,000×2,050 mm (118.1×80.7 in) table. Both are rated for 13,000 kg (28,660 lb).

02 What are the Y travels of the NF-3026 and NF-3033?

The shared column gives 2,600/ 3,300 mm (102.4/ 129.9 in): 2,600 mm for the NF-3026 and 3,300 mm for the NF-3033.

03 What tool magazine comes with the NF-3026 / NF-3033?

A vertical type tool magazine with 32 tools is standard, and 40 or 60 tools are options. Floor-standing vertical and floor-standing vertical-horizontal changers are listed as options with 32, 40 or 60 pcs.

04 Is the NF-3026 faster than longer NF models?

Yes. Its X/Y rapid is 24 m/min. The NF-4026, one metre longer, lists 18 m/min. Cutting feed is 1-10,000 mm/min on both.
