Takamaz Takamaz XTL-8MYS
Key Specifications
Max Spindle
Rapid Traverse
Max Turn Length
main spindle chuck
sub spindle chuck
main spindle speed
Overview
The Takamaz XTL-8MYS is a full-capability multi-tasking CNC lathe featuring an 8-inch main spindle, 6-inch sub-spindle, Y-axis, and live tooling — the most versatile machine in Takamaz's compact production lathe lineup. The addition of a sub-spindle to the XTL platform enables complete part machining with backworking capability, eliminating the need for second-operation setups on parts that require machining on both ends.
The main spindle runs at 4,000 RPM with a 100 mm bearing bore, while the sub-spindle also delivers 4,000 RPM through a 75 mm bearing bore with 7.5/5.5 kW of power. The main spindle motor output of 5.5/3.7/2.2 kW may seem modest, but Takamaz has optimized the drivetrain for the high-speed, light-cut turning cycles typical of production environments. The 12-station turret with half-indexing provides up to 24 tool positions, with all 12 capable of holding power tools for maximum flexibility.
The Y-axis provides +35/-40 mm of travel for true off-center machining, while the main axes offer 175 mm X-travel, 550 mm Z-travel, and 400 mm A-axis (sub-spindle) travel. Rapid traverse rates of 18 m/min on X, 24 m/min on Z, 10 m/min on Y, and 30 m/min on A keep non-cutting time minimal. The maximum turning length of 404 mm between spindles accommodates shaft-type work and longer components that smaller Takamaz models cannot handle.
Powered by a Fanuc 0i-TF Plus control, the XTL-8MYS handles multi-channel programming for synchronized main and sub-spindle operations. Live tools provide drilling and endmilling capability up to 20 mm diameter with M16 tapping capacity, handling the cross-drilling and milling operations that previously required a separate machining center. With an optional loader handling workpieces up to 75 mm diameter and 5 kg, the XTL-8MYS is a complete automated production cell for complex turned-and-milled parts.
Full Specifications
| Parameter | Value |
|---|---|
| Main Spindle Chuck | 8 inch |
| Sub Spindle Chuck | 6 inch |
| Main Spindle Speed | 4,000 RPM |
| Sub Spindle Speed | 4,000 RPM |
| Main Spindle Power | 5.5 / 3.7 / 2.2 kW (7.4 / 5.0 / 3.0 HP) |
| Sub Spindle Power | 7.5 / 5.5 kW (10 / 7.4 HP) |
| Main Spindle Bearing Id | 100 mm (3.94 in) |
| Sub Spindle Bearing Id | 75 mm (2.95 in) |
| Turret Stations | 12 (24 with half-indexing, up to 12 power tools) |
| Live Tool Capacity | 20 mm drill / M16 tap |
| Max Turning Length | 404 mm (15.9 in) |
| X Axis Travel | 175 mm (6.9 in) |
| Z Axis Travel | 550 mm (21.7 in) |
| Y Axis Travel | +35 / -40 mm (1.38 / 1.57 in) |
| A Axis Travel | 400 mm (15.7 in) |
| Rapid Traverse X | 18 m/min (709 IPM) |
| Rapid Traverse Z | 24 m/min (945 IPM) |
| Rapid Traverse Y | 10 m/min (394 IPM) |
| Rapid Traverse A | 30 m/min (1,181 IPM) |
| CNC Control | Takamaz & Fanuc 0i-TF Plus |
| Loader Capacity | 75 mm diameter / 5 kg (optional) |
| Floor Space Required | 2,764 x 1,965 mm (108.8 x 77.4 in) |
| Item | Ability |
| Main Spindle | Sub-spindle |
| Chuck Size | 8 |
| Spindle | Spindle bearing I.D. |
| Max Spindle Speed | 4,000 |
| Tool Post | Type |
| Maxstroke | X:175 Z:550 Y:+35,-40 A:400 |
| Rapid Traverse Rate | Y:160 Z:160 |
| Power Tools | Tool storage capacity |
| Rotation Speed | 4,000 |
| Capacity | Drill |
| Endmill | φ20 |
| Tap | M16 |
| Motors | AC15/11 |
| W L | Manual machine2,764(1,840※1)×1,965Machine with loader2,764(1,840※1)×1,965 |
| Cnc Control | TAKAMAZ & FANUC Oi-TF Plus |
| Itemloader Specifications | Ability |
| Workpiece Diameter | φ75 |
| Max Load Capacity | 5 |
Specifications sourced from takamaz.co.jp — verified 2026-03-28
Strengths & Limitations
Strengths
- Complete main-spindle plus sub-spindle architecture with Y-axis enables done-in-one part production
- 12 power tool positions with 20 mm drilling and M16 tapping cover demanding milling requirements
- Half-indexing turret effectively provides 24 tool positions for complex parts with many operations
- 550 mm Z-travel and 404 mm turning length handle longer parts than most compact multi-tasking lathes
- 30 m/min A-axis rapid traverse enables fast spindle-to-spindle part transfer
- Fanuc 0i-TF Plus control with multi-channel capability for synchronized spindle operations
Limitations
- Main spindle power of 5.5 kW is modest for aggressive roughing on larger diameter steel parts
- 2,764 x 1,965 mm footprint is significantly larger than single-spindle Takamaz models
- Complex multi-axis programming requires skilled operators and training investment
- Limited Western service infrastructure compared to Mazak, DMG Mori, or Okuma multi-tasking platforms
Best For
Frequently Asked Questions
01
New Takamaz XTL-8MYS machines price between $250,000 and $370,000 depending on loader configuration and tooling options. The machine replaces a lathe, a machining center, and the operator time for part transfer, justifying the investment in medium to high production volumes.
02
The XTL-8MYS adds a 6-inch sub-spindle for backworking and both-end machining. The XTL-8MY is a single-spindle machine with milling and Y-axis but without sub-spindle capability. The XTL-8MYS costs more but produces complete parts in one setup.
03
The main spindle uses a 5.5 kW motor optimized for high-speed production turning, while the sub-spindle has a 7.5 kW motor to handle the additional cutting loads of second-operation machining. This configuration ensures both spindles perform their respective roles efficiently.
04
Yes, the 100 mm main spindle bore accommodates bar feeding, and the machine can be configured with a bar feeder for continuous production. The sub-spindle can then pick up cut-off parts for second-operation machining automatically.
