Takamaz Takamaz AT-1

$100,000 - $160,000 Updated 2026-03-19

Key Specifications

Max Spindle

Max. 4,500

Rapid Traverse

X:18Z:24

Spindle Power

AC7.5 / 5.5

chuck size

－ (Collet,6, 8)※Optional attachments

spindle speed

4,500 RPM

spindle bearing id

85 mm (3.35 in)

Overview

The Takamaz AT-1 is a single-spindle, single-turret CNC precision lathe designed for mid-range production turning of parts up to approximately 200 mm in diameter. Available with both 6-inch and 8-inch chuck options plus collet capability, the AT-1 sits in a versatile sweet spot in the Takamaz lineup — offering more work envelope than their compact XT series while maintaining the automation-ready DNA that defines every Takamaz machine.

Powered by a 7.5/5.5 kW spindle motor turning at up to 4,500 RPM, the AT-1 delivers solid cutting performance on steel, aluminum, cast iron, and brass at production feeds. The 8-station turret handles typical OD/ID turning, facing, grooving, and threading operations efficiently, while the 175 mm X-axis and 330 mm Z-axis travel provide a generous work envelope for a machine in this class. Rapid traverse rates of 18 m/min on X and 24 m/min on Z keep non-cutting time short.

One of the AT-1's distinguishing features is its optional tailstock configuration, which expands the machine's capability to include shaft-type work requiring between-centers support. Without the tailstock, the full 175 mm X-travel is available for chucking work. The Takamaz and Mitsubishi control system includes a 15-inch LCD touch panel monitor that provides clear visualization of programs and machine status, along with idle stop functionality and power consumption monitoring for energy-conscious production environments.

The AT-1 is built for integration into automated production cells. Compatible with Takamaz's range of gantry loaders, the machine transitions smoothly from attended operation during setup and prove-out to unattended production running. The compact footprint of approximately 1,810 x 1,690 mm means multiple AT-1 machines can be arranged in tight cell configurations without consuming excessive floor space.

Full Specifications

Parameter	Value
Chuck Size	－ (Collet,6, 8)※Optional attachments
Spindle Speed	4,500 RPM
Spindle Motor Power	AC7.5 / 5.5
Spindle Bearing Id	85 mm (3.35 in)
Turret Stations	8
X Axis Travel	175 mm (6.9 in) without tailstock / 160 mm (6.3 in) with tailstock
Z Axis Travel	330 mm (13.0 in)
Rapid Traverse X	18 m/min (709 IPM)
Rapid Traverse Z	24 m/min (945 IPM)
Spindle Center Height	960 mm (37.8 in)
CNC Control	Takamaz & Mitsubishi
Gantry Loader	Optional
Tailstock	Optional
Floor Space Required	1,810 x 1,690 x 1,500 mm (71.3 x 66.5 x 59.1 in) without tailstock
Item	Ability
Without Tailstock	With tailstock
Spindle	Spindle bearing I.D.
Max Spindle Speed	Max. 4,500
Tool Post	Type
Maxstroke	X:175Z:330
Rapid Traverse Rate	X:18Z:24
L W H	1,810 (With tailstock: 1,945) × 1,690 × 1,500
Cnc Control	TAKAMAZ &MITSUBISHI

Specifications sourced from takamaz.co.jp — verified 2026-03-28

Strengths & Limitations

Strengths

Versatile chuck sizing with 6-inch, 8-inch, and collet options covers a broad range of part diameters
Optional tailstock configuration expands capability to shaft-type work requiring between-centers support
330 mm Z-axis travel provides generous turning length for a compact production lathe
15-inch LCD touch panel with idle stop and power monitoring supports energy-efficient operation
Compact 1.8 x 1.7 meter footprint enables high-density cell configurations
Mitsubishi control platform offers robust programming and reliable performance

Limitations

4,500 RPM spindle speed is moderate compared to higher-speed compact lathes from competitors
8-station turret limits tool capacity for complex parts requiring many tool changes
No live tooling capability restricts the machine to pure turning operations
Limited brand recognition outside Japan makes parts sourcing and resale values uncertain in Western markets

Best For

Mid-volume production of turned parts up to 200 mm diameter in automotive and hydraulic industries Shops needing a versatile production lathe that handles both chucking and shaft-type work Facilities seeking compact automated turning cells with gantry loader integration Production of fittings, valve bodies, and connectors in steel, aluminum, and brass Manufacturers transitioning from manual lathes to CNC production with automation readiness

Frequently Asked Questions

01 What does a Takamaz AT-1 cost?

New Takamaz AT-1 machines typically price between $100,000 and $160,000 depending on chuck configuration, tailstock option, and gantry loader. Used machines in good condition trade in the $40,000-$75,000 range.

02 What control system does the AT-1 use?

The AT-1 uses a Takamaz and Mitsubishi control system with a 15-inch LCD touch panel monitor. It includes idle stop functionality and power consumption monitoring as standard features.

03 Can the AT-1 handle bar feeding?

The AT-1's spindle bore accommodates bar stock, and Takamaz offers compatible bar feeder integration. The collet chuck option is particularly well-suited for bar-fed production of smaller diameter parts.

04 How does the AT-1 compare to the Takamaz XT-8?

The AT-1 offers a larger work envelope with 330 mm Z-travel versus 120 mm on the XT-8, plus tailstock capability. The XT-8 is faster for small parts under 80 mm diameter, while the AT-1 handles a broader range of part sizes and configurations.
