Overview
The Pinnacle BX500 is a 5-axis machining center with a ± 120° swivel head and a Ø500 mm (Ø19.7 in) rotary table embedded in the main table and driven directly at 50 rpm. X travel is 1,300 mm (51.2 in) and Y 610 mm (24.0 in).
Pinnacle gives Z in two parts, because the reach changes when the head lies over: Vertical Milling 610 / Horizontal Milling 760 mm. That is a useful honesty. A swivel-head machine cuts with the spindle horizontal as well as vertical, and the clearance to the table differs in each attitude.
In the base BX500 the B axis is still worm driven, at 25 rpm with 1,157 Nm (853.4 lb-ft) of clamp torque, while the C axis is direct drive. Rotary positioning accuracy is 14"/10" for B/C, the weaker figure belonging to the worm. The BX500DD replaces the worm with a direct-drive motor.
The built-in spindle delivers 48 / 120 Nm (35.4 / 88.5 lb-ft) from a 15 / 18 kW (20.1 / 24.1 hp) motor at up to 15,000 rpm. The embedded table carries 500 kg (1,102 lb) and the surrounding 1,450 x 610 mm (57.1 x 24.0 in) table 850 kg (1,874 lb). The machine weighs 7,200 kg (15,873 lb). The series is described with the HEIDENHAIN TNC640 and its tilted-plane, collision monitoring and tool centre point functions.
Full Specifications
| Parameter | Value |
|---|---|
| Table Size | 1,450 x 610 mm (57.1 x 24.0 in) |
| X Axis Travel | 1,300 mm (51.2 in) |
| Y Axis Travel | 610 mm (24.0 in) |
| Z Axis Travel | Vertical Milling 610 / Horizontal Milling 760 mm (Vertical Milling 24.0 / Horizontal Milling 29.9 in) |
| Max Table Load | 850 kg (1,874 lb) |
| Distance Spindle Nose to Table Vertical | 100~710 mm (3.9~28.0 in) |
| Distance Spindle Center to Table Horizontal | 205~965 mm (8.1~38.0 in) |
| T-Slots | 18 x 125 x 5 (W x D x N mm) |
| Spindle Taper | DIN40 (HSKA63) |
| Spindle Bearing Inner Diameter | Ø70 mm (Ø2.8 in) |
| Spindle Center to Column | 675 mm (26.6 in) |
| Max Spindle Speed | 15,000 rpm |
| Draw Bar Force | 800 ± 100 kgf |
| Spindle Motor Power | 15 / 18 kW (20.1 / 24.1 hp) (con/30 min) |
| Spindle Torque | 48 / 120 Nm (35.4 / 88.5 lb-ft) (con/max) |
| B Axis Drive | WORM GEAR |
| B Axis Range | ± 120° |
| B Axis Speed | 25 rpm |
| B Axis Clamp Torque | 1,157 Nm (853.4 lb-ft) |
| Rotary Table Drive Type | EMBEDDED |
| Rotary Table Type | Direct drive |
| Rotary Table Diameter | Ø500 mm (Ø19.7 in) |
| C Axis Speed | 50 rpm |
| Rotary Table Load | 500 kg (1,102 lb) |
| Rapid Traverse Xyz | 36 / 36 / 24 m/min |
| Tool Magazine Type | PLATE |
| Tool Capacity | 30(40/60) |
| Max Tool Diameter (full magazine) | Ø75 mm (Ø3.0 in) |
| Positioning Accuracy | 0.005 mm |
| Positioning Accuracy Rotary Axes | 14"/10" (BC rotary (sec)) |
| Repeatability | 0.003 mm |
| Repeatability Rotary Axes | 8"/6" (BC rotary (sec)) |
| Air Requirement | 6 kg/cm² |
| Power Requirement | 40 kVA |
| Coolant Tank Capacity | 300 L |
| Machine Weight | 7,200 kg (15,873 lb) |
| Machine Height | 3,100 mm (122.0 in) |
| Floor Space | 3,400 x 2,230 mm (133.9 x 87.8 in) (L x W) |
Specifications sourced from pinnacle-mc.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Embedded direct-drive C-axis table, Ø500 mm (Ø19.7 in), at 50 rpm
- Spindle torque of 48 / 120 Nm (35.4 / 88.5 lb-ft) at up to 15,000 rpm
- Long 1,300 mm (51.2 in) X travel beside the rotary table
- Compact for a 5-axis machine at 3,400 x 2,230 mm (133.9 x 87.8 in)
Limitations
- B axis is worm driven at 25 rpm in this version
- Vertical milling Z travel is 610 mm, less than in horizontal milling
- Rotary table load is 500 kg (1,102 lb)
Best For
Frequently Asked Questions
01
Pinnacle lists it as Vertical Milling 610 / Horizontal Milling 760 mm. With the head vertical the spindle nose is 100~710 mm (3.9~28.0 in) from the table; with the head horizontal the spindle centre is 205~965 mm (8.1~38.0 in) above it.
02
Yes. The table is listed as EMBEDDED with a direct drive, Ø500 mm (Ø19.7 in) in diameter, 50 rpm and a 500 kg (1,102 lb) load rating. The B-axis swing head on the BX500 is worm-gear driven.
03
The BX500DD has a direct-drive B axis at 50 rpm with 2,950 Nm (2,175.9 lb-ft) of clamp torque and a 15 / 19.4 kW (20.1 / 26.0 hp) spindle. The BX500 has a worm-gear B axis at 25 rpm and a 15 / 18 kW (20.1 / 24.1 hp) spindle.
04
Pinnacle describes the BX series as a HEIDENHAIN TNC640 5-axis simultaneously controlled machining center and explains its PLANE function for tilted working planes, DCM collision monitoring and TCPM tool centre point management.
