Litz TX-1000
Image: litzhitech.com, Litz
Key Specifications
Max Spindle
Tool Capacity
Table Size
Spindle Power
x axis travel
y axis travel
How much does the Litz TX-1000 cost?
Price estimate
We do not have a price for the Litz TX-1000 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Litz TX-1000 takes the tapping-center formula to a full metre of X travel: 1,000 mm (39.4 in) in X, 500 mm (19.7 in) in Y and 350 mm (13.8 in) in Z, with a 12,000 rpm BT-30 spindle and a 21-tool disc type magazine.
It is not just a stretched TX-700. Y grows by 100 mm, the table becomes 1,100 x 500 mm (43.3 x 19.7 in), load capacity rises to 350 kg (772 lb), and the cutting feed range extends to 30,000 mm/min where the TX-700 stops at 20,000 mm/min. The coolant tank is larger too, at 300 L. Rapids stay at 48 / 48 / 48 m/min (1,890 / 1,890 / 1,890 ipm).
Who needs a metre-long 30-taper machine? Shops machining laptop and tablet chassis, long extrusions, panel parts and lighting housings, where the features are small holes and shallow pockets spread over a large area. A larger-taper machine of this travel would be slower between features and no better in the cut on that kind of work.
Limits are those of the taper. The motor is 3.5 / 5.5 kW (4.7 / 7.4 hp), tools weigh at most 3 kg (7 lb), and Z travel is only 350 mm with 150 to 500 mm (5.9 to 19.7 in) under the spindle nose. Machine weight is 4,100 kg (9,039 lb) on a 15 kVA supply.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 1,000 mm (39.4 in) |
| Y Axis Travel | 500 mm (19.7 in) |
| Z Axis Travel | 350 mm (13.8 in) |
| Distance Spindle Nose to Table | 150 to 500 mm (5.9 to 19.7 in) |
| Max Spindle Speed | 12,000 rpm |
| Tool Capacity | 21 |
| Max Tool Diameter (full magazine) | 60 / 80 mm (2.4 / 3.1 in) |
| Max Tool Length | 250 mm (9.8 in) |
| Max Tool Weight | 3 kg (7 lb) |
| Tool Change Method | Disc Type |
| Tool Shank | BT-30 |
| Spindle Motor Power | 3.5 / 5.5 kW (4.7 / 7.4 hp) (continuous / 30 min rated) |
| Axis Motors Xyz | 1.5 / 1.5 / 2.2 kW |
| Table Size | 1,100 x 500 mm (43.3 x 19.7 in) |
| Max Table Load | 350 kg (772 lb) |
| T-Slots | 3 x 14 mm x 125 mm (number x width x distance from the center) |
| Cutting Feed Rate | 1-30,000 mm/min (up to 1,181 ipm) |
| CNC Control | Mitsubishi M80 |
| Machine Weight | 4,100 kg (9,039 lb) |
| Power Requirement | 15 kVA |
| Coolant Tank Capacity | 300 L |
| Compressed Air | 6 kg/cm² |
| Rapid Traverse Xyz | 48 / 48 / 48 m/min (1,890 / 1,890 / 1,890 ipm) |
Specifications sourced from litzhitech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 1,000 x 500 mm of X and Y travel on a BT-30 machine
- Cutting feed up to 30,000 mm/min, above the 20,000 mm/min of the TX-700
- 48 / 48 / 48 m/min (1,890 / 1,890 / 1,890 ipm) rapids
- 350 kg (772 lb) table load and a 300 L coolant tank
Limitations
- Z travel of 350 mm (13.8 in)
- 3.5 / 5.5 kW (4.7 / 7.4 hp) motor and 3 kg (7 lb) tool limit
- 21 tools; the only other magazine listed is a smaller 16T
- BT-30 tooling limits cutter diameter and stick-out
Best For
Frequently Asked Questions
01
1,000 mm (39.4 in) in X, 500 mm (19.7 in) in Y and 350 mm (13.8 in) in Z. The table is 1,100 x 500 mm (43.3 x 19.7 in) and carries 350 kg (772 lb).
02
Rapid traverse is 48 m/min (1,890 ipm) on X, Y and Z, and cutting feed is programmable from 1 to 30,000 mm/min. The spindle runs at 12,000 rpm, with 24,000 rpm available as an option.
03
BT-30 tools up to 250 mm (9.8 in) long and 3 kg (7 lb), 21 of them in a disc type magazine. Maximum tool diameter is listed as 60 / 80 mm (2.4 / 3.1 in).
04
Yes. The option list includes a 4th axis rotating table and a DDR embedded motor 4th axis. Raised columns of 100 mm and 200 mm are also offered to gain clearance for such equipment.
