Makino V77L
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Spindle Taper
Tool Capacity
Overview
The Makino V77L is a large-platform vertical machining center targeting high-productivity mold, die, and large structural component work where a generous work envelope and robust spindle power are required. The V77L is offered in both 40-taper (CAT-40/BT-40) and 50-taper (CAT-50/BT-50) variants, enabling shops to select the spindle interface appropriate for their tooling standards and material removal demands.
X/Y/Z travel is 1,600 x 760 x 710 mm (63.0 x 29.9 x 28.0 in), one of the largest envelopes in Makino's VMC lineup. The 1,800 x 800 mm (70.9 x 31.5 in) table supports loads up to 3,000 kg (6,614 lb).
The 40-taper variant features a 12,000 RPM spindle with 26 kW (34.8 hp) and 200 Nm, configured for aggressive material removal in steel and cast iron. The 50-taper variant runs a 10,000 RPM spindle with 37 kW (49.6 hp) and 500 Nm for the heaviest cutting in large forgings and die blocks. Rapid traverse reaches 36 m/min (1,417 ipm) on X, and 32 m/min (1,260 ipm) on Y/Z.
The column-moves-in-Y configuration is optimized for large table loads and rigid chip evacuation. The 30-tool ATC (expandable to 60 tools) and through-spindle coolant are standard. Positioning accuracy reaches +/-0.004 mm (0.00016 in). The Pro 6 control is tuned toward high material removal rate, placing the V77L in direct competition with the Mazak Nexus 6800 and Okuma MU-8000V.
Full Specifications
| Parameter | Value |
|---|---|
| X-Axis Travel | 1,600 mm (63.0 in) |
| Y-Axis Travel | 760 mm (29.9 in) |
| Z-Axis Travel | 710 mm (28.0 in) |
| Max Spindle Speed | 12,000 RPM (40-taper) / 10,000 RPM (50-taper) |
| Spindle Taper | CAT-40 or BT-40 / CAT-50 or BT-50 (variant dependent) |
| Spindle Motor Power | 26 kW (34.8 hp) / 37 kW (49.6 hp) |
| Spindle Torque | 200 Nm (40-taper) / 500 Nm (50-taper) |
| Tool Capacity | 30 (expandable to 60) |
| Tool Change Time | 2.5 sec (tool-to-tool) |
| Max Tool Length | 450 mm (17.7 in) |
| Max Tool Weight | 15 kg (33 lb) 40-taper / 25 kg (55 lb) 50-taper |
| Table Size | 1,800 x 800 mm (70.9 x 31.5 in) |
| Table Load Capacity | 3,000 kg (6,614 lb) |
| Rapid Traverse X | 36 m/min (1,417 ipm) |
| Rapid Traverse Yz | 32 m/min (1,260 ipm) |
| Positioning Accuracy | +/- 0.004 mm (0.00016 in) |
| Repeatability | +/- 0.002 mm (0.00008 in) |
| Through Spindle Coolant | Standard |
| Machine Weight | 20,000 kg (44,092 lb) |
| CNC Control | Makino Professional 6 (Pro 6) |
| Eventscontent Librarywebinar Archiveownersmakino Expertisesafety Data Sheetsnewsroomfinancing | Financing OptionsMakino makes it easy to upgrade with flexible financing optionsLearn More |
Specifications sourced from makino.com — verified 2026-03-28
Strengths & Limitations
Strengths
- 1,600 mm X travel and 3,000 kg table capacity handle the largest VMC-class mold bases and structural components
- 50-taper variant with 37 kW and 500 Nm provides heavy-duty roughing power for large die blocks and structural steel forgings
- 36 m/min X rapid traverse reduces non-cutting time significantly on long-travel programs
- 40-taper and 50-taper variants available, allowing shops to standardize on their existing tooling interface
- 60-tool ATC option supports complex programs without manual tool intervention on long unmanned runs
- Column-in-Y design provides excellent rigidity and chip management for heavy roughing
Limitations
- Positioning accuracy of +/-0.004 mm is adequate for most structural and mold work but not competitive with Makino's F-series precision VMCs for fine finishing
- 20,000 kg machine requires careful foundation planning and overhead crane access
- Lower spindle speed ceiling (12,000/10,000 RPM) is not suited to high-speed graphite electrode machining
- V77L is a productivity machine; shops prioritizing precision surface finish should evaluate the F-series instead
- Large footprint limits shop layout flexibility
Best For
Frequently Asked Questions
01
The 40-taper variant (CAT-40 or BT-40) runs at 12,000 RPM with 26 kW and 200 Nm, suited for mold and die work in medium-to-large steel components. The 50-taper variant (CAT-50 or BT-50) runs at 10,000 RPM with 37 kW and 500 Nm for the heaviest roughing in large forgings and structural steel. Shops standardized on 50-taper tooling from existing large HMCs will find the 50-taper V77L integrates seamlessly.
02
The V77L is a large-platform productivity VMC, while the F6 and F8 are precision mold finishing machines. The V77L offers larger travel (1,600 mm X vs 1,300 mm X on F8), higher spindle power (37 kW vs 26 kW), and faster rapids, but positions to +/-0.004 mm vs the F-series +/-0.002 mm. For heavy roughing and large travel, the V77L is the better choice. For sub-3-micron positioning and surface finish as the primary requirement, the F-series is appropriate.
03
Yes. The V77L with the 60-tool ATC option and through-spindle coolant is well-suited for unmanned operation on long roughing and semi-finishing programs. Makino's Pro 6 control includes tool life management, broken tool detection provisions, and DNC connectivity. Many shops run the V77L for extended unattended roughing programs on large mold bases overnight.
04
A new Makino V77L typically ranges from $350,000 to $600,000. The 40-taper base configuration starts around $350,000-$400,000. The 50-taper variant with 37 kW spindle commands a premium, and adding the 60-tool ATC, probing, and enhanced chip management can bring a fully configured machine to $500,000-$600,000.
05
The V77L uses Makino's Professional 6 (Pro 6) control with a multi-touch interface including SGI.5 contouring for large-surface milling programs. The tuning parameters are oriented toward the machine's larger table, higher rapids, and greater spindle power. The same Pro 6 interface found on F-series machines makes cross-training operators between V77L and F-series machines straightforward.
