Johnford ST-60CX
Key Specifications
Max Spindle
Rapid Traverse
Spindle Power
swing over bed
swing over cross slide
chuck size
How much does the Johnford ST-60CX cost?
Price estimate
We do not have a price for the Johnford ST-60CX that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Johnford ST-60CX is a 1,200 mm (47.2 in) lathe with an A2-15 spindle, a 510 mm (20.1 in) chuck and 1,020 mm (40.2 in) of swing over the bed. It is also the base of one of Johnford's turn-mill machines.
In its listed form it is a two-axis turning machine with a 12-position turret. The optional accessory list ends with a B-axis milling/turning spindle for simultaneous 4 or 5 axis machining, and the ST-60CX+B+C+Y is that idea carried through: the same 1,200 mm between centers and 510 mm chuck, with an HSK-A100 spindle and tool magazine in place of the turret. The tables list 13,350 kg (29,370 lb) here and 15,000 kg (33,069 lb) for the ST-60CX+B+C+Y.
Between those two points there are intermediate steps. A 0.001° C axis, a 12-position live tool turret in VDI or BMT and a Y axis of ±75 mm (±3 in) can each be added to the lathe.
As a lathe, it offers 30 / 37 kW (40.2 / 49.6 hp) or 37 / 45 kW (49.6 / 60.3 hp), four automatic speeds to 1,500 rpm, a 152 mm (6 in) bore, 139 mm (5.5 in) of bar capacity, 420 mm (16.5 in) of X travel and 800 mm (31.5 in) of swing over the cross slide.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 1,020 mm (40.2 in) |
| Swing Over Cross Slide | 800 mm (31.5 in) |
| Chuck Size | 510 mm (20.1 in) |
| Chuck Size Optional | 610 mm (24 in) |
| Bar Capacity | 139 mm (5.5 in) |
| Spindle Nose | A2-15 |
| Spindle Bore | 152 mm (6 in) |
| Spindle Transmission | Auto 4 speeds |
| Max Spindle Speed | 1,500 rpm (Std.); 1,400 rpm (Opt.) |
| Spindle Speed Geared Headstock | 1,200 rpm |
| Spindle Motor Power | 30 / 37 kW (40.2 / 49.6 hp) (Std.); 37 / 45 kW (49.6 / 60.3 hp) (Opt.) |
| Spindle Bearing Diameter | 200 mm (7.9 in) |
| Turret Stations | 12 |
| X Axis Travel | 420 mm (16.5 in) |
| Y Axis Travel Optional | ±75 mm (±3 in) |
| Z Axis Travel | 1,200 mm (47.2 in) |
| Rapid Traverse Rate | X: 12 m/min (472 ipm); Y: 10 m/min (394 ipm); Z: 16 m/min (630 ipm) |
| Tailstock Travel | 900 mm (35.4 in) |
| Tailstock Quill Travel | 125 mm (4.9 in) |
| Tailstock Quill Diameter | Ø125 mm (Ø4.9 in) |
| Tailstock Taper | MT#5 |
| Servo Motor X | 7 kW |
| Servo Motor Y Optional | 3 kW |
| Servo Motor Z | 7 kW |
| Bed Inclination | 60° |
| Machine Weight | 13,350 kg (29,370 lb) |
| Machine Dimensions | 6,195 x 2,270 x 2,765 mm (243.9 x 89.4 x 108.9 in) |
Specifications sourced from johnford.com.tw — verified 2026-10-04
Strengths & Limitations
Strengths
- 1,020 mm (40.2 in) swing over the bed with a 510 mm (20.1 in) chuck
- 30 / 37 kW (40.2 / 49.6 hp), optionally 37 / 45 kW (49.6 / 60.3 hp)
- C axis, live tool turret, Y axis and a B-axis spindle are listed options
- 420 mm (16.5 in) of X travel
- 139 mm (5.5 in) bar capacity through a 152 mm (6 in) bore
Limitations
- A plain turning turret as standard
- Spindle speed of 1,500 rpm at most
- Ø125 mm (4.9 in) MT#5 tailstock quill
- Listed at 13,350 kg (29,370 lb), well above the ST-60BX
Best For
Frequently Asked Questions
01
The ST-60CX is the turret lathe. The ST-60CX+B+C+Y is the turn-mill version, with a B-axis milling/turning spindle, HSK-A100 taper, C and Y axes and a tool magazine; it is listed at 15,000 kg (33,069 lb).
02
A 0.001° C axis for the main spindle, a 12-position live tool turret in VDI or BMT, Y-axis capability with ±75 mm (±3 in) of travel, or a B-axis milling/turning spindle for simultaneous 4 or 5 axis machining.
03
Swing over the bed 1,020 mm (40.2 in), over the cross slide 800 mm (31.5 in), Z travel 1,200 mm (47.2 in), X travel 420 mm (16.5 in) and tailstock travel 900 mm (35.4 in).
04
13,350 kg (29,370 lb) according to the table, compared with 12,300 kg (27,060 lb) for the ST-60BX. Outside dimensions are 6,195 x 2,270 x 2,765 mm (243.9 x 89.4 x 108.9 in).
