Jainnher JHU-2710CNC
Key Specifications
Spindle Power
max work swing
max grinding length
max grinding diameter
max workpiece weight
work spindle speed 60hz
How much does the Jainnher JHU-2710CNC cost?
Price estimate
We do not have a price for the Jainnher JHU-2710CNC that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Jainnher JHU-2710CNC is a CNC universal cylindrical grinder with a 270 mm (10.6 in) swing and a 1,000 mm (39.4 in) grinding length. It sits one step up from the JHU-2706CNC, and the step is bigger than the extra bed length suggests.
Job weight is the first change. The JHU-2706CNC is limited to 70 kg (154 lb) between centers. This one carries 130 kg (287 lb), the figure Jainnher gives for every longer bed as well. The second is support: a 2-point center rest joins the standard accessories from the 1 m size upward, so a slender shaft can be steadied without ordering extras.
A metre between centers with a 250 mm (9.8 in) grinding diameter covers most general shaft work, including motor shafts, spindles, rolls and hydraulic rods. The table swivels 9° counter-clockwise and 5° clockwise for tapers, and the work head turns at 11 to 500 rpm on 60 Hz supply or 9 to 420 rpm on 50 Hz.
Jainnher builds the wheel head around a spindle carried in two hydrodynamic bearings with five-point support. If lubrication fails, the spindle stops automatically. The wheel head has 175 mm (6.9 in) of travel, a 0.001 mm setting unit and a maximum feed rate of 6 m/min (236 ipm). The table lists a 1.2 kW (1.6 hp) servo for X and a 1.8 kW (2.4 hp) servo for the other axis. The machine is about 4,700 mm (185.0 in) long and has a gross weight of about 6,000 kg (13,228 lb).
Full Specifications
| Parameter | Value |
|---|---|
| Max Work Swing | 270 mm (10.6 in) |
| Max Grinding Length | 1,000 mm (39.4 in) |
| Max Grinding Diameter | 250 mm (9.8 in) |
| Max Workpiece Weight | 130 kg (287 lb) |
| Work Spindle Speed 60hz | 11 to 500 rpm at 60 Hz (variable speed) |
| Work Spindle Speed 50hz | 9 to 420 rpm at 50 Hz (variable speed) |
| Work Head Swivel Angle | 120° (CCW: 90°; CW: 30°) |
| Center Taper | MT.4 |
| Work Spindle Rotation | Setting, Normal and reverse rotation |
| Table Swivel Angle Ccw Cw | 9° / 5° |
| Table Min Setting Unit | 0.001 mm |
| Wheel Size | 405 x (25 ~ 50) x 152.4; 455 x 50 x 152.4 (opt.) (D x W x B) |
| Max Peripheral Speed | 2,000 m/min |
| Wheel Head Max Feed Rate | 6 m/min (236 ipm) |
| Wheel Head Travel | 175 mm (6.9 in) |
| Wheel Head Min Setting Unit | 0.001 mm |
| Tailstock Center Travel | 30 mm (1.2 in) |
| Tailstock Center | MT4 |
| Spindle Motor Power | 3.75 kW, 5 HP, 4P; 7.5 HP (5.6 kW) (opt.) |
| Worktable Motor | 1.8 kW (2.4 hp) |
| Hydraulic Motor | 0.75 kW (1 HP), 4P |
| Servo Motor X | 1.2 kW (1.6 hp) |
| Servo Motor Y | 1.8 kW (2.4 hp) |
| Hydraulic Tank | 60 L |
| Lubrication Tank | 30 L |
| Coolant Tank | 100 L |
| Gross Weight | 6,000 kg (13,228 lb) (approx.) |
| Machine Dimensions | 4,700 x 2,160 x 2,310 mm (185.0 x 85.0 x 90.9 in) (L x W x H) (approx.) |
Specifications sourced from jainnher.com — verified 2026-10-05
Strengths & Limitations
Strengths
- Carries 130 kg (287 lb) between centers, against 70 kg (154 lb) on the JHU-2706CNC
- 1,000 mm (39.4 in) grinding length on a 270 mm (10.6 in) swing
- 2-point center rest is a standard accessory at this length
- Wheel spindle in hydrodynamic bearings that stops automatically if lubrication is insufficient
- Table swivel of 9° counter-clockwise and 5° clockwise for taper work
Limitations
- Grinding diameter is 250 mm (9.8 in); larger parts need the JHU-3510CNC with 330 mm (13.0 in)
- Standard wheel motor is 3.75 kW, 5 HP, with 7.5 HP (5.6 kW) only as an option
- The maker's table gives no net weight with a unit, only an approximate gross weight
- 3-point center rests, chuck and internal attachment are optional
Best For
Frequently Asked Questions
01
The JHU-2706CNC grinds 600 mm (23.6 in) and carries 70 kg (154 lb). The JHU-2710CNC grinds 1,000 mm (39.4 in) and carries 130 kg (287 lb), and a 2-point center rest is standard from this length. Its table swivel is 9° and 5°, a little less than the 11° and 6° of the JHU-2706CNC.
02
The work head speed is variable. Jainnher gives 11 to 500 rpm on a 60 Hz supply and 9 to 420 rpm on a 50 Hz supply. The spindle can be fixed for dead-center work or run in normal or reverse rotation.
03
The grinding wheel spindle is supported by two hydrodynamic bearings with five-point support. Jainnher states that if lubrication oil is insufficient the spindle stops automatically, to avoid wear on the spindle and bearings. The forced lubrication has its own 30 L tank.
04
Approximately 4,700 x 2,160 x 2,310 mm (185.0 x 85.0 x 90.9 in), length by width by height, in Jainnher's table. The approximate gross weight is 6,000 kg (13,228 lb). A net weight is printed without a unit and is not repeated here.
