Hwacheon SIRIUS-1050
Image: hwacheon.com, Hwacheon
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
x axis travel
How much does the Hwacheon SIRIUS-1050 cost?
Price estimate
We do not have a price for the Hwacheon SIRIUS-1050 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Hwacheon SIRIUS-1050 is the deep-Z member of the SIRIUS large-table range. It travels 2,500 mm (98.4 in) in X, 1,050 mm (41.3 in) in Y and 850 mm (33.5 in) in Z, and the spindle nose reaches from 200 ~ 1,050 mm (7.9 ~ 41.3 in) above a 2,800 x 1,050 mm (110.2 x 41.3 in) table. That is more Z than the neighbouring SIRIUS sizes offer: the SIRIUS-850, SIRIUS-1250 and SIRIUS-1350 all stop at 750 mm (29.5 in), and the SIRIUS-1750 at 800 mm (31.5 in).
That height matters on tall castings, angle plates and jobs where a long boring bar or extension has to reach the bottom of a pocket. The table takes 5,000 kg (11,023 lb) and has seven 22 x 150 mm (0.87 x 5.91 in) T-slots.
It is also the quickest of the 50-taper SIRIUS models in the horizontal plane. X and Y rapid at 20 m/min (787 ipm) and Z at 16 m/min (630 ipm), where the SIRIUS-1250 lists 16 m/min on all three axes. On a 2,500 mm X stroke that saves real time between features.
The spindle is the series' built-in BBT-50 unit at 8,000 or 12,000 rpm, rated 30 / 25 kW (40.2 / 33.5 hp), with oil-jet bearings on a Ø100 mm (Ø3.9 in) bore and oil-cooler jacket cooling. The magazine is 24 tools as standard with 30 optional, memory random, for tools up to 350 mm (13.8 in) and 20 kg (44 lb). Diameter is the catch: Ø100 mm (Ø3.9 in) with neighbours loaded, against Ø110 mm on the SIRIUS-850, or Ø200 mm (Ø7.9 in) with adjacent pockets empty.
At 27,690 kg (61,045 lb) the SIRIUS-1050 outweighs the SIRIUS-1250 (23,000 kg) despite the shorter Y. It needs a 6,630 x 4,730 mm (261.0 x 186.2 in) floor area, 3,750 mm (147.6 in) of height, 75 kVA, 0.5 ~ 0.7 MPa x 1,870 NL/min of air, and it carries the largest coolant tank of the group at 1,250 L (330 US gal). Control is a Fanuc 31i-B.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 2,500 mm (98.4 in) |
| Y Axis Travel | 1,050 mm (41.3 in) |
| Z Axis Travel | 850 mm (33.5 in) |
| Distance Spindle Nose to Table | 200 ~ 1,050 mm (7.9 ~ 41.3 in) |
| Table Size | 2,800 x 1,050 mm (110.2 x 41.3 in) |
| Max Table Load | 5,000 kg (11,023 lb) |
| T-Slots | 22 x 150 mm (0.87 x 5.91 in), 7 slots (width x pitch, count) |
| Max Spindle Speed | 8,000 / 12,000 rpm |
| Spindle Motor Power | 30 / 25 kW (40.2 / 33.5 hp) |
| Spindle Taper | ISO#50, 7/24 Taper (BBT-50) |
| Spindle Bearing Bore | Ø100 mm (Ø3.9 in) |
| Spindle Drive | Built-in motor |
| Spindle Bearing Lubrication | Oil-jet |
| Spindle Cooling | Jacket cooling (oil cooler) |
| Rapid Traverse Xyz | 20 / 20 / 16 m/min (787 / 787 / 630 ipm) |
| Tool Shank | BBT-50 (opt.: CAT-50) |
| Pull Stud | 90˚ |
| Tool Capacity | 24 (opt.: 30) |
| Max Tool Diameter (full magazine) | Ø100 / Ø200 mm (Ø3.9 / Ø7.9 in) (with / without adjacent tools) |
| Max Tool Length | 350 mm (13.8 in) |
| Max Tool Weight | 20 kg (44 lb) |
| Tool Selection | Memory Random |
| Power Requirement | 75 kVA |
| Air Supply | 0.5 ~ 0.7 MPa x 1,870 NL/min |
| Coolant Tank Capacity | 1,250 L (330 US gal) |
| Machine Height | 3,750 mm (147.6 in) |
| Floor Space | 6,630 x 4,730 mm (261.0 x 186.2 in) |
| Machine Weight | 27,690 kg (61,045 lb) |
| CNC Control | Fanuc 31i-B |
Specifications sourced from hwacheon.com — verified 2026-10-03
Strengths & Limitations
Strengths
- 850 mm (33.5 in) of Z and 200 ~ 1,050 mm (7.9 ~ 41.3 in) under the spindle, against 750 mm (29.5 in) of Z on the SIRIUS-1250
- X and Y rapids of 20 m/min (787 ipm), faster than the 16 m/min of the SIRIUS-850, SIRIUS-1250 and SIRIUS-1350
- 2,800 x 1,050 mm (110.2 x 41.3 in) table rated for 5,000 kg (11,023 lb) with seven T-slots
- Magazine of 24 tools, with a 30-tool option, for tools up to 350 mm (13.8 in) and 20 kg (44 lb)
- 1,250 L (330 US gal) coolant tank for long cycles with heavy flood coolant
Limitations
- Maximum tool diameter with adjacent tools loaded is Ø100 mm (Ø3.9 in), smaller than the Ø110 mm of the SIRIUS-850
- 27,690 kg (61,045 lb) and a 6,630 x 4,730 mm (261.0 x 186.2 in) footprint need a prepared foundation
- Z still rapids at 16 m/min (630 ipm), so deep-Z retracts are slower than X and Y moves
- Table load is 5,000 kg (11,023 lb), the same as the SIRIUS-1250 and below the 8,000 kg of the SIRIUS-1350
Best For
Frequently Asked Questions
01
For height and speed. The SIRIUS-1050 has 850 mm (33.5 in) of Z and 20 m/min (787 ipm) X and Y rapids. The SIRIUS-1250 has 750 mm (29.5 in) of Z and 16 m/min rapids, but a 2,800 x 1,250 mm (110.2 x 49.2 in) table against 2,800 x 1,050 mm (110.2 x 41.3 in). Both rate the table at 5,000 kg (11,023 lb).
02
24 as standard and 30 as an option, in a memory-random magazine. Tools can be up to 350 mm (13.8 in) long and 20 kg (44 lb), and Ø100 mm (Ø3.9 in) in diameter with the adjacent pockets loaded or Ø200 mm (Ø7.9 in) with them empty. Shanks are BBT-50, with CAT-50 optional.
03
A built-in motor spindle with an ISO#50 BBT-50 taper, offered at 8,000 or 12,000 rpm and rated 30 / 25 kW (40.2 / 33.5 hp). Bearings sit on a Ø100 mm (Ø3.9 in) bore with oil-jet lubrication, and the housing is jacket cooled by an oil cooler.
04
Allow 27,690 kg (61,045 lb), a 6,630 x 4,730 mm (261.0 x 186.2 in) footprint and 3,750 mm (147.6 in) of height. The machine needs 75 kVA and 0.5 ~ 0.7 MPa x 1,870 NL/min of compressed air, and its coolant tank holds 1,250 L (330 US gal).
