Hartford HSA-323EAY
Image: hartfordcnc.com, Hartford
Key Specifications
Spindle Taper
Tool Capacity
Table Size
Spindle Power
max table load
t slots
How much does the Hartford HSA-323EAY cost?
Price estimate
We do not have a price for the Hartford HSA-323EAY that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
A 3,000 x 2,200 mm (118.1 x 86.6 in) table, 3,100 mm (122.0 in) of Y travel and 3,000 mm (118.1 in) of X travel: on the Hartford HSA-323EAY the gantry is wider than the machine is long. The table load is 10,000 kg (22,046 lb).
The reason is five-face machining. With Y travel exceeding the table width by this much, an angular head can descend beside a part that covers the whole table and cut along its length on either side. The HSA-323EA, with the same table and 2,300 mm (90.6 in) of Y, cannot offer that on full-width parts.
One detail in the tables separates the two beyond travel. The T-slot row reads 22 x 250 on the HSA-323EAY and 28 x 250 on the HSA-323EA, eleven slots in both cases, so fixture hardware is not automatically interchangeable between them.
Hartford credits the structure with a slant beam that reduces vibration during cutting and with columns joined to the base over 1,250 mm. A wide gantry makes both points more relevant than on the narrow models. The #50 spindle is a 6,000 rpm gear head, 8,000 rpm as an option, or a 10,000 rpm hybrid; Z travel is 1,000 mm or 1,200 mm.
Full Specifications
| Parameter | Value |
|---|---|
| Table Size | 3,000 x 2,200 mm (118.1 x 86.6 in) |
| Max Table Load | 10,000 kg (22,046 lb) |
| T-Slots | 22 x 250 (11) mm |
| X Axis Travel | 3,000 mm (118.1 in) |
| Y Axis Travel | 3,100 mm (122.0 in) |
| Z Axis Travel | 1,000 (1,200) mm |
| Spindle Taper | #50 |
| Spindle Speed Gear | 6,000 (8,000) rpm |
| Spindle Speed Hybrid | 10,000 rpm |
| Tool Capacity | A: 32 (40 / 60) pcs |
| Tool Shank | BT-50 (CAT-50 / DIN-50 / BBT-50) |
| Spindle Motor Power | 18.5 / 22 opt. 30 / 35 kW (Cont. / 30 min) |
Specifications sourced from hartfordcnc.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 3,100 mm (122.0 in) of Y travel over a 2,200 mm wide table
- 3,000 x 2,200 mm (118.1 x 86.6 in) table rated at 10,000 kg (22,046 lb)
- Slant beam and 1,250 mm column joints for a stiff wide gantry
- 10,000 rpm hybrid spindle available
Limitations
- T-slots are the 22 size, where the HSA-323EA has 28
- 10,000 kg is the same rating as the much narrower HSA-320EAY
- Y-axis ballscrew support is listed as an option for x23 models
Best For
Frequently Asked Questions
01
3,100 mm (122.0 in), over a table 2,200 mm (86.6 in) wide. X travel is 3,000 mm (118.1 in) and Z travel is 1,000 mm, with 1,200 mm available as an option.
02
The HSA-323EA has 2,300 mm (90.6 in) of Y travel and 28-size T-slots. The HSA-323EAY has 3,100 mm (122.0 in) of Y and 22-size T-slots. Both have the 3,000 x 2,200 mm table and carry 10,000 kg.
03
Yes. The HSA-327EAY keeps the 3,000 x 2,200 mm table and the 10,000 kg rating and has 3,500 mm (137.8 in) of Y travel, the widest gantry among the three-metre models.
04
That the new slant beam design effectively reduces vibration and enhances accuracy and surface roughness during cutting. The columns are described as extra-large, with the joint between column and base widened to 1,250 mm.
