Hartford HSA-736EAY
Image: hartfordcnc.com, Hartford
Key Specifications
Spindle Taper
Tool Capacity
Table Size
Spindle Power
max table load
t slots
How much does the Hartford HSA-736EAY cost?
Price estimate
We do not have a price for the Hartford HSA-736EAY that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Hartford HSA-736EAY is the only seven-metre model in the long-Y five-face HSA line. Its table is 7,000 x 3,000 mm (275.6 x 118.1 in) and rated for 27,000 kg (59,524 lb), with 7,000 mm (275.6 in) of X travel and 4,400 mm (173.2 in) of Y.
Buyers at this length therefore have a simple decision. The HSA-732EA and HSA-736EA cover seven metres with shorter Y travels, 3,200 mm (126.0 in) and 3,600 mm (141.7 in). If the job needs a universal head or long tools alongside a three-metre-wide part, the 736EAY is the one model that provides the clearance.
27,000 kg puts it close to the top of the family; only the eight-metre x36 machines are rated higher. Platens for large presses and injection machines, turbine housings and heavy fabricated beds are within reach.
Twenty-seven T-slots of the 28 size are listed. Hartford states that Y-axis ballscrew support is standard for the HSA-x36 series and X-axis support for models above 5 meters. The #50 spindle is a gear head at 6,000 rpm, optionally 8,000 rpm, or a 10,000 rpm hybrid, and the motor is 18.5 / 22 kW with 30 / 35 kW optional. Z travel is 1,000 mm, or 1,200 mm.
Full Specifications
| Parameter | Value |
|---|---|
| Table Size | 7,000 x 3,000 mm (275.6 x 118.1 in) |
| Max Table Load | 27,000 kg (59,524 lb) |
| T-Slots | 28 x 250 (27) mm |
| X Axis Travel | 7,000 mm (275.6 in) |
| Y Axis Travel | 4,400 mm (173.2 in) |
| Z Axis Travel | 1,000 (1,200) mm |
| Spindle Taper | #50 |
| Spindle Speed Gear | 6,000 (8,000) rpm |
| Spindle Speed Hybrid | 10,000 rpm |
| Tool Capacity | A: 32 (40 / 60) pcs |
| Tool Shank | BT-50 (CAT-50 / DIN-50 / BBT-50) |
| Spindle Motor Power | 18.5 / 22 opt. 30 / 35 kW (Cont. / 30 min) |
Specifications sourced from hartfordcnc.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 7,000 x 3,000 mm (275.6 x 118.1 in) table for 27,000 kg (59,524 lb)
- 4,400 mm (173.2 in) of Y travel, the largest at seven metres
- Supported X and Y ballscrews as standard
- 28-size T-slots, twenty-seven of them
Limitations
- No narrower seven-metre EAY model exists as an alternative
- Z travel remains 1,000 mm, with 1,200 mm optional
- Base motor of 18.5 / 22 kW; 30 / 35 kW has to be specified
Best For
Frequently Asked Questions
01
Table 7,000 x 3,000 mm (275.6 x 118.1 in), X travel 7,000 mm, Y travel 4,400 mm (173.2 in), Z travel 1,000 mm with 1,200 mm optional. The table is rated for 27,000 kg (59,524 lb).
02
Three. The HSA-732EA has 3,200 mm (126.0 in) of Y, the HSA-736EA 3,600 mm (141.7 in) and the HSA-736EAY 4,400 mm (173.2 in). The HSA-736EAY is the only one in the EAY line.
03
No. Both are rated for 27,000 kg (59,524 lb) on a 7,000 x 3,000 mm table. The HSA-736EAY has 4,400 mm (173.2 in) of Y travel where the HSA-736EA has 3,600 mm (141.7 in).
04
The table gives 18.5 / 22 kW as the standard continuous and 30 min rating and 30 / 35 kW as the option. The #50 spindle runs 6,000 rpm or 8,000 rpm as a gear head, or 10,000 rpm as a hybrid.
