Goodway GTH-1500

Q: How much does the Goodway GTH-1500 cost?

The price estimate for the Goodway GTH-1500 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/goodway-gth-1500#price; the request is passed to Goodway or an authorised dealer.

Specs verified 2026-10-04 · goodwaycnc.com Updated 2026-10-04

Goodway GTH series parallel twin spindle turning centers (GTH-1500)

Image: goodwaycnc.com, Goodway

Key Specifications

Spindle Power

5.5 kW (7.4 hp) (opt. 7.5 kW (10.1 hp) or 11 kW (14.8 hp)) (cont.)

Max Turn Length

80 mm (3.1 in)

max turning diameter

Ø240 mm (9.4 in)

chuck size

6" / 8"

spindle nose

A2-5

spindle power 30 min

7.5 kW (10.1 hp) (11 kW (14.8 hp) or 15 kW (20.1 hp)) (30 min.)

How much does the Goodway GTH-1500 cost?

Price estimate

Uncertain

We do not have a price for the Goodway GTH-1500 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Goodway GTH-1500 is a parallel twin-spindle chucker with a gantry loader as standard equipment. Two spindles sit side by side, each with its own 12-station turret, and the gantry robotic arm loads, flips and unloads the parts. It is made for disc-shaped parts in volume, with a maximum turning diameter of Ø240 mm (9.4 in) and only 80 mm (3.1 in) of turning length.

That 80 mm figure defines the machine. This is not a lathe for shafts or bar; no tailstock or bar capacity appears in the table. It takes forged or cast blanks in 6 in or 8 in chucks, turns one face on the first spindle and the other face on the second.

Spindle nose is A2-5. The standard motor is 5.5 kW (7.4 hp) continuous and 7.5 kW (10.1 hp) for 30 min., running 45 ~ 6,000 rpm. Goodway lists two stronger options, 7.5 kW or 11 kW (14.8 hp) continuous, and an alternative speed range of 60 ~ 4,800 rpm. Which combination is right depends on chuck size and material, so it should be specified with the part drawing in hand.

Goodway states that each set of jaws on the gantry can hold up to 8 kg, and that disc-type or shaft-type feeding stations are offered. A non-contact inspection system is optional. Single-spindle and twin-spindle machines, a flipping device and the gantry can be linked into a line. The M variation adds a 12-station live tooling turret at 6,000 rpm and a C-axis.

Full Specifications

Parameter	Value
Max Turning Diameter	Ø240 mm (9.4 in)
Max Turning Length	80 mm (3.1 in)
Chuck Size	6" / 8"
Spindle Nose	A2-5
Spindle Motor Power	5.5 kW (7.4 hp) (opt. 7.5 kW (10.1 hp) or 11 kW (14.8 hp)) (cont.)
Spindle Power 30 Min	7.5 kW (10.1 hp) (11 kW (14.8 hp) or 15 kW (20.1 hp)) (30 min.)
Spindle Speed Range	45 ~ 6,000 rpm (opt. 60 ~ 4,800 rpm)
Turret Stations	12
Live Tooling Stations	12 (opt.)
Live Tooling Speed	6,000 rpm (opt.)
Gantry Robotic Arm	Standard

Specifications sourced from goodwaycnc.com — verified 2026-10-04

Strengths & Limitations

Strengths

Gantry robotic arm is standard equipment
Two parallel spindles, each with a 12-station servo turret
Spindle speed up to 6,000 rpm on an A2-5 nose
Motor options up to 11 kW (14.8 hp) continuous
Optional non-contact inspection system and line integration with other GTH machines

Limitations

Turning length is only 80 mm (3.1 in)
Standard motor is 5.5 kW (7.4 hp) continuous
The gantry jaws hold up to 8 kg each, which caps part weight
No bar capacity, tailstock or Y-axis is listed

Best For

Disc and flange parts up to Ø240 mm (9.4 in) machined on two faces Unattended automotive production fed by the gantry Production lines built from several linked machines

Frequently Asked Questions

01 Is the gantry loader included with the GTH-1500?

Yes. Goodway lists the gantry robotic arm as standard and describes the gantry loading/unloading system as standard equipment for the series. Each set of jaws can hold up to 8 kg of workpiece, subject to actual requirements.

02 What size parts does the GTH-1500 handle?

Maximum turning diameter is Ø240 mm (9.4 in) and maximum turning length 80 mm (3.1 in). Chucks are 6 in or 8 in. The larger GTH-2000 turns Ø300 mm (11.8 in) and 205 mm (8.1 in) long with a 10 in chuck.

03 What spindle motors are available on the GTH-1500?

The standard motor is 5.5 kW (7.4 hp) continuous and 7.5 kW (10.1 hp) on the 30 min. rating. Options are 7.5 kW or 11 kW (14.8 hp) continuous, with 30 min. ratings of 11 kW and 15 kW (20.1 hp). The speed range is 45 ~ 6,000 rpm, or 60 ~ 4,800 rpm as an option.

04 Can the GTH-1500 do milling and drilling?

With the M variation, which has a C-axis and a 12-station live tooling turret running at 6,000 rpm. Goodway states that only the tool at the working position rotates. The C-axis is a Cf type driven by a servo motor.
