GF Machining AgieCharmilles CUT E 600

$150,000 - $220,000 Updated 2026-03-19

Key Specifications

X / Y / Z Travel

600 x 400 x 350 mm (23.6 x 15.7 x 13.8 in)

U / V Travel

±50 mm (±2.0 in)

Max Workpiece Dimensions

1030 x 800 x 350 mm (40.6 x 31.5 x 13.8 in)

Max Workpiece Weight

1,000 kg (2,205 lb)

Wire Diameter Range

0.15 - 0.30 mm (0.10 mm optional)

Min Surface Finish Ra

0.14 µm

Overview

The GF Machining Solutions AgieCharmilles CUT E 600 is the larger-travel entry-level wire EDM in GF's CUT E series, extending the accessible-price-point philosophy to a substantially bigger work envelope. With X/Y/Z travels of 600 x 400 x 350 mm and a 1,000 kg workpiece capacity, the CUT E 600 handles medium-size die plates and larger tooling that exceed the reach of the compact CUT E 350.

The expanded 600 x 400 mm X/Y travel and 1030 x 800 mm maximum workpiece dimensions make the CUT E 600 suitable for progressive die plates, medium injection mold inserts, larger fixture assemblies, and industrial components. The 350 mm Z-travel is a significant improvement over the CUT E 350's 250 mm, enabling taller workpieces and thicker die plate sections. The 1,000 kg workpiece capacity handles substantially heavier components.

Surface finish capability matches the CUT E 350 at Ra 0.14 µm. Wire diameter range is 0.15 to 0.30 mm standard with optional 0.10 mm capability. The AC CUT control with technology database provides the same ease of use as smaller CUT E models, and automatic wire threading is standard for unattended operation.

The CUT E 600 fills an important gap in the market: an affordable mid-size wire EDM from a premium manufacturer. It serves shops that need more travel than compact machines provide but do not require the advanced thermal compensation of the CUT F 600 or the IPG generator of the CUT P 550 Pro. Its 2160 x 3400 mm footprint remains manageable for most shop floor layouts.

Full Specifications

Parameter	Value
X / Y / Z Travel	600 x 400 x 350 mm (23.6 x 15.7 x 13.8 in)
U / V Travel	±50 mm (±2.0 in)
Max Workpiece Dimensions	1030 x 800 x 350 mm (40.6 x 31.5 x 13.8 in)
Max Workpiece Weight	1,000 kg (2,205 lb)
Wire Diameter Range	0.15 - 0.30 mm (0.10 mm optional)
Min Surface Finish Ra	0.14 µm
Max Taper Angle	±30° / 50 mm height
Wire Spool Capacity	8 kg (25 kg optional)
Control System	AC CUT with technology database
Auto Wire Threading	Standard (AWT)
Machine Footprint	2160 x 3400 x 2320 mm
Dielectric	Deionized water
Travel X Y Z	600 x 400 x 350 mm23.62 x 15.75 x 13.78 in
Min Surface Roughness Ra	0.14 μm6 μin
Dimensions Of Complete Equipment	2160 x 3400 x 2320 mm85.04 x 133.86 x 91.34 in
Max Taper Angle Height	± 30°/50 mm± 30°/1.97 in
Max Workpiece Dimensions	1030 x 800 x 350 mm40.55 x 31.5 x 13.78 in
Max Workpiece Weight	1000 kg2205 lbs
Travel U V	± 50 mm± 1.97 in
Wire Diameters	0.15-0.30 (0.10 optional) mm0.006-0.012 (0.04 optional) in
Max Wire Spool Weight	8 (25 optional) kg

Specifications sourced from gfms.com — verified 2026-03-28

Strengths & Limitations

Strengths

600 x 400 mm travel handles medium-size die plates at an entry-level price point
1,000 kg workpiece capacity accommodates heavier tooling than compact wire EDMs
350 mm Z-travel cuts taller workpieces than the CUT E 350's 250 mm
AC CUT technology database maintains ease of use on a larger platform
Standard AWT enables unattended operation on multi-feature medium-size parts
Accessible pricing from a premium manufacturer fills a key market gap

Limitations

No Thermal Compensation System — accuracy may drift with shop temperature fluctuations
Surface finish (Ra 0.14 µm) is respectable but not mirror-class for demanding mold work
±30° taper limited to 50 mm height — less capability than CUT P and CUT 2000/3000 series
Standard 8 kg wire spool limits unattended run time on thicker material cuts

Best For

Job shops needing mid-size wire EDM capacity at an accessible price point Progressive die builders with medium-size die plates that exceed compact wire EDM travel Contract manufacturers adding versatile mid-range wire EDM as a service capability Mold shops processing medium inserts and cavity retainer plates without premium-tier investment Shops upgrading from a compact CUT E 350 to handle larger workpieces

Frequently Asked Questions

01 Why choose the CUT E 600 over the CUT E 350?

The CUT E 600 offers significantly more travel (600 x 400 mm vs 350 x 250 mm), taller Z-axis (350 mm vs 250 mm), and higher workpiece capacity (1,000 kg vs 400 kg). Choose the CUT E 600 when your work regularly includes medium-size die plates, thicker workpieces, or tooling exceeding the CUT E 350 envelope.

02 How does the CUT E 600 compare to the CUT F 600?

Both share the same travel dimensions and workpiece capacity. The CUT F 600 adds the Thermal Compensation System (TCS) for maintaining dimensional accuracy across temperature fluctuations, and supports 0.10 mm wire standard rather than as an option. The CUT E 600 is priced lower for shops where thermal compensation is not critical.

03 Can the CUT E 600 handle production volumes?

Yes. The CUT E 600 with its AWT system supports unattended production runs, and the 1,000 kg capacity handles production-scale tooling. For high-throughput production with advanced IPG generator technology and SMART consumables, the CUT P 550 Pro is the natural step up.

04 What is the upgrade path from the CUT E 600?

Within GF's lineup at similar travel: CUT F 600 (adds thermal compensation at modest premium), or CUT P 550 Pro (adds IPG generator, SMART consumables, and production-grade features). For larger travel needs: CUT P 800 Pro. All use the AC CUT control platform for operator skill transfer.
