GF Machining AgieCharmilles CUT P 550 Pro

$280,000 - $400,000 Updated 2026-03-19

Key Specifications

X / Y / Z Travel

550 x 350 x 400 mm (21.7 x 13.8 x 15.7 in)

U / V Travel

550 x 350 mm (21.7 x 13.8 in)

Max Workpiece Dimensions

1200 x 700 x 400 mm (47.2 x 27.6 x 15.7 in)

Max Workpiece Weight

1,500 kg (3,307 lb)

Wire Diameter Range

0.15 - 0.33 mm (0.07-0.10 mm optional)

Min Surface Finish Ra

0.08 µm

Overview

The GF Machining Solutions AgieCharmilles CUT P 550 Pro is the mid-range production wire EDM in GF's latest CUT P Pro series, delivering the sweet spot of travel capacity, workpiece weight, and Z-axis height for the broadest range of mold, die, and precision component applications. With X/Y/Z travels of 550 x 350 x 400 mm and a 1,500 kg workpiece capacity, the CUT P 550 Pro handles medium-to-large die plates, mold frames, and industrial tooling that exceed the reach of compact wire EDMs.

The 400 mm Z-travel is a significant advantage over the CUT P 350 Pro's 220 mm, enabling the CUT P 550 Pro to cut through substantially taller workpieces — a critical capability for thick die plates, tall extrusion die profiles, and stacked fixture assemblies. Maximum workpiece dimensions of 1200 x 700 x 400 mm accommodate the majority of production tooling sizes short of the largest automotive body dies.

Powered by the latest-generation Intelligent Power Generator (IPG), the CUT P 550 Pro achieves Ra 0.08 µm surface finishes with multi-pass skim cutting while delivering up to 30% energy reduction compared to prior-generation machines. The SMART consumables system monitors wire, filters, and resin for predictive maintenance scheduling. Wire diameters from 0.15 to 0.33 mm are supported standard, with optional 0.07-0.10 mm micro-wire capability.

Taper cutting capability reaches ±30° over the full 400 mm Z-height, with optional ±45° for aggressive clearance-angle geometries. The CUT P 550 Pro is the natural choice for production die shops and contract manufacturers that need mid-range travel with production-grade reliability and the latest IPG efficiency.

Full Specifications

Parameter	Value
X / Y / Z Travel	550 x 350 x 400 mm (21.7 x 13.8 x 15.7 in)
U / V Travel	550 x 350 mm (21.7 x 13.8 in)
Max Workpiece Dimensions	1200 x 700 x 400 mm (47.2 x 27.6 x 15.7 in)
Max Workpiece Weight	1,500 kg (3,307 lb)
Wire Diameter Range	0.15 - 0.33 mm (0.07-0.10 mm optional)
Min Surface Finish Ra	0.08 µm
Max Taper Angle	±30° / 400 mm (±45° optional)
Max Wire Spool Weight	8 kg (25 kg optional)
Control System	Advanced HMI with SMART consumables
Generator	Intelligent Power Generator (IPG) — latest generation
Dielectric	Deionized water
Travel X Y Z	1250 x 850 x 100-800 mm49.2 x 33.5 x 3.9-27.56 in
Min Surface Roughness Ra	0.2 μm
Max Taper Angle Height	30°/800 mm30°/31.5 in
Max Workpiece Dimensions	1300 x 950 x 510 mm51.18 x 21.65 x 20.07 in
Max Workpiece Weight	6000 kg13228 lbs
Travel U V	1250 x 850 mm49.2 x 33.5 in
Wire Diameters	0.15-0.33 mm0.006-0.013
Max Wire Spool Weight	25-45 kg55-100 lbs

Specifications sourced from gfms.com — verified 2026-03-28

Strengths & Limitations

Strengths

550 x 350 mm travel with 400 mm Z-height handles the broadest range of production tooling sizes
1,500 kg workpiece capacity accommodates medium-to-large die plates and mold frames
Latest IPG generator delivers Ra 0.08 µm finish with 30% energy savings over prior generation
SMART consumables system enables predictive maintenance for maximum uptime
Optional ±45° taper angle over 400 mm height covers aggressive clearance geometries
Mid-range positioning in the CUT P Pro lineup balances capability against investment

Limitations

Larger footprint than the CUT P 350 Pro requires more floor space
Higher investment than compact models — shops with smaller parts may not need the travel
Standard 8 kg wire spool limits run time for thick-section production cutting
0.15 mm minimum standard wire excludes finest micro-detail without optional package

Best For

Production die shops cutting medium-to-large stamping dies, progressive dies, and blanking tools Mold manufacturers processing mold frames and cavity retainer plates in hardened steel Contract wire EDM shops needing versatile mid-range capacity for diverse customer work Aerospace manufacturers cutting precision profiles in thick hardened material sections Extrusion die makers cutting complex die profiles from H13 and carbide stock

Frequently Asked Questions

01 Why choose the CUT P 550 Pro over the CUT P 350 Pro?

The CUT P 550 Pro offers substantially more capability: 550 x 350 mm travel (vs 350 x 250), 400 mm Z-height (vs 220 mm), and 1,500 kg workpiece capacity (vs 750 kg). Choose the 550 Pro when your work regularly includes medium-to-large die plates, thick workpieces, or components exceeding the 350 Pro envelope.

02 What is the maximum part thickness the CUT P 550 Pro can cut?

The 400 mm Z-travel defines the maximum workpiece height for full Z-axis positioning. Workpieces up to 400 mm tall can be cut with wire EDM, with taper capability of ±30° maintained over this full height. For thicker sections, the CUT P 800 Pro offers 510 mm Z-travel.

03 Can the CUT P 550 Pro handle carbide cutting?

Yes. The IPG generator includes optimized carbide cutting parameters in its technology database. The CUT P 550 Pro handles tungsten carbide, PCD, and other difficult conductive materials. The 1,500 kg capacity accommodates large carbide workpieces common in extrusion die manufacturing.

04 How does the energy savings of the Pro series work?

The latest-generation IPG generator achieves up to 30% daily energy reduction through more efficient spark discharge waveforms that maximize material removal per unit of electrical energy. This reduces operating costs significantly on machines running production shifts, with savings most noticeable on thick-section, long-duration cuts.
