GF Machining AgieCharmilles CUT 3000 S
Key Specifications
X / Y / Z Travel
U / V Travel
Max Workpiece Dimensions
Max Workpiece Weight
Wire Diameter Range
Min Surface Finish Ra
Overview
The GF Machining Solutions AgieCharmilles CUT 3000 S is the larger-travel surface-finish-optimized wire EDM in GF's CUT 2000/3000 series, offering a substantially expanded work envelope while retaining the same mirror-class surface finish capability as its CUT 2000 S sibling. With X/Y/Z travels of 500 x 350 x 256 mm and a 400 kg workpiece capacity, the CUT 3000 S bridges the gap between compact precision wire EDMs and full-size production machines.
The expanded 500 x 350 mm X/Y travel and 1050 x 650 mm maximum workpiece dimensions open the CUT 3000 S to medium-size die plates, larger mold inserts, and multi-cavity tooling that exceeds the 350 x 250 mm envelope of the CUT 2000 series. The 400 kg workpiece weight capacity (with bath) accommodates substantially heavier workpieces, making the CUT 3000 S suitable for progressive die work and medium-size stamping tool components.
Surface finish capability remains at the same Ra 0.07 µm level as the CUT 2000 S, powered by the same IPG (Intelligent Power Generator) technology. Wire diameter support ranges from 0.10 to 0.30 mm standard with optional micro-wire down to 0.05-0.07 mm. The ±30° taper cutting capability over 100 mm height is retained, and the U/V travel of ±70 mm enables complex taper geometries.
The CUT 3000 S is the natural choice for shops that need the surface finish quality of the CUT 2000 S but regularly work with larger components. Its position in the GF lineup makes it the mid-range sweet spot between the compact CUT 2000 models and the large-frame CUT P production series.
Full Specifications
| Parameter | Value |
|---|---|
| X / Y / Z Travel | 500 x 350 x 256 mm (19.7 x 13.8 x 10.1 in) |
| U / V Travel | ±70 mm (±2.8 in) |
| Max Workpiece Dimensions | 1050 x 650 x 250 mm (41.3 x 25.6 x 9.8 in) |
| Max Workpiece Weight | 400 kg (880 lb) with bath |
| Wire Diameter Range | 0.10 - 0.30 mm (0.05-0.07 mm optional) |
| Min Surface Finish Ra | 0.07 µm |
| Max Taper Angle | ±30° / 100 mm height |
| Max Wire Spool Weight | 25 kg |
| Control System | AC CUT HMI with IPG technology |
| Generator | Intelligent Power Generator (IPG) |
| Dielectric | Deionized water |
| Travel X Y Z | 350 x 250 x 256 mm13.77 x 9.84 x 10 in |
| Min Surface Roughness Ra | 0.05 μm2 μin |
| Max Taper Angle Height | ± 30°/100 mm± 30°/3.93 in |
| Max Workpiece Dimensions | 750 x 550 x 250 mm29.5 x 21.6 x 9.8 in |
| Max Workpiece Weight | 200 kg |
| Travel U V | ± 70 mm± 2.7 in |
| Wire Diameters | 0.10 - 0.30 (0.05-0.07 optional) mm0.004 - 0.012 (0.002-0.003 optional) in |
| Max Wire Spool Weight | 25 kg55.11 lbs |
Specifications sourced from gfms.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Expanded 500 x 350 mm travel accommodates medium-size die plates and larger mold inserts
- Mirror-class Ra 0.07 µm surface finish matches the compact CUT 2000 S quality
- 400 kg workpiece capacity handles progressive die components and heavier tooling
- IPG generator delivers efficient cutting with optimized wire consumption
- Optional micro-wire (0.05-0.07 mm) for ultra-fine detail work on larger platforms
- Full ±30° taper cutting capability with ±70 mm U/V travel
Limitations
- Larger footprint and higher price than the CUT 2000 S for shops that rarely need the extra travel
- 256 mm Z-travel may limit cutting height for taller workpieces
- Premium GF pricing reflects the high-end positioning of the CUT S series
- Micro-wire and other advanced options increase total investment significantly
Best For
Frequently Asked Questions
01
The CUT 3000 S offers larger X/Y travel (500 x 350 mm vs 350 x 250 mm), larger maximum workpiece dimensions (1050 x 650 mm vs 750 x 550 mm), and double the workpiece weight capacity (400 kg vs 200 kg). Surface finish capability, generator technology, and control system are identical. The CUT 3000 S is for shops that need the same finish quality on larger parts.
02
Yes. Both machines use the same IPG generator technology and achieve the same Ra 0.07 µm minimum surface finish. The larger travel of the CUT 3000 S does not compromise finish quality — it simply extends that capability to a larger work envelope.
03
The CUT 3000 X adds laser-calibrated positioning accuracy (±1.5 µm total) to the same physical platform. The CUT 3000 S focuses on surface finish optimization. Choose the X variant when absolute positional accuracy is more critical than surface quality.
04
Yes. The IPG generator includes dedicated carbide cutting parameters in the AC CUT technology database. The CUT 3000 S handles tungsten carbide, PCD, and other conductive hard materials with appropriate wire and parameter selection.
