GF Machining AgieCharmilles CUT F 600

$180,000 - $280,000 Updated 2026-03-19

Key Specifications

X / Y / Z Travel

600 x 400 x 350 mm (23.6 x 15.7 x 13.8 in)

U / V Travel

±50 mm (±2.0 in)

Max Workpiece Dimensions

1030 x 800 x 350 mm (40.6 x 31.5 x 13.8 in)

Max Workpiece Weight

1,000 kg (2,205 lb)

Wire Diameter Range

0.10 - 0.30 mm

Surface Finish Ra (Carbide)

0.14 µm

Overview

The GF Machining Solutions AgieCharmilles CUT F 600 is the larger-travel model in GF's CUT F series, extending the thermal-stability-focused design philosophy to a substantially bigger work envelope. With X/Y/Z travels of 600 x 400 x 350 mm, the CUT F 600 handles medium-size die plates, larger mold inserts, and multi-feature tooling that exceeds the 350 x 250 mm reach of the CUT F 350.

The CUT F 600 retains the Thermal Compensation System (TCS) that defines the CUT F series — continuously monitoring machine structure temperature and applying real-time positional corrections to maintain dimensional accuracy through shop temperature fluctuations. On a larger-travel machine, thermal compensation becomes even more important, as thermal expansion effects are proportionally larger across greater axis distances.

Maximum workpiece dimensions of 1030 x 800 x 350 mm with a 1,000 kg weight capacity position the CUT F 600 for production-scale work: progressive die plates, medium injection mold frames, multi-cavity connector tooling, and precision fixture assemblies. The 350 mm Z-travel is a significant improvement over the CUT F 350's 250 mm, enabling taller workpieces including thick die plates and stacked assemblies.

Surface finish capability matches the CUT F 350 at Ra 0.14 µm on carbide and Ra 0.18 µm on steel. Wire diameter range is 0.10 to 0.30 mm, U/V travel is ±50 mm, and taper cutting reaches ±30° at 50 mm height. The machine footprint of 2160 x 3400 mm accommodates the larger frame while remaining manageable for most shop floor layouts.

Full Specifications

Parameter	Value
X / Y / Z Travel	600 x 400 x 350 mm (23.6 x 15.7 x 13.8 in)
U / V Travel	±50 mm (±2.0 in)
Max Workpiece Dimensions	1030 x 800 x 350 mm (40.6 x 31.5 x 13.8 in)
Max Workpiece Weight	1,000 kg (2,205 lb)
Wire Diameter Range	0.10 - 0.30 mm
Surface Finish Ra (Carbide)	0.14 µm
Surface Finish Ra (Steel)	0.18 µm
Max Taper Angle	±30° / 50 mm height
Wire Spool Capacity	8 kg (JIS P5) or 25 kg (DIN 160)
Thermal Management	Thermal Compensation System (TCS)
Control System	AC CUT with technology database
Machine Footprint	2160 x 3400 x 2600 mm
Dielectric	Deionized water
Travel X Y Z	600 x 400 x 350 mm23.62 x 15.75 x 13.78 in
Min Surface Roughness Ra	Carbide: 0.14 μm / Steel: 0.18 μmCarbide: 5.50 μin / Steel: 7.09 μin
Dimensions Of Complete Equipment	2160 x 3400 x 2600 mm85.04 x 133.86 x 102.36 in
Max Taper Angle Height	± 30°/50 mm± 30°/1.97 in
Max Workpiece Dimensions	1030 x 800 x 350 mm40.55 x 31.5 x 13.78 in
Max Workpiece Weight	1000 kg2205 lbs
Travel U V	± 50 mm± 1.97 in
Wire Diameters	0.10-0.30 mm0.004-0.012 in
Max Wire Spool Weight	8 (JIS P5), 25 (DIN 160) kg

Specifications sourced from gfms.com — verified 2026-03-28

Strengths & Limitations

Strengths

600 x 400 mm travel handles medium-size die plates and mold inserts with thermal stability
Thermal Compensation System ensures accuracy across shop temperature fluctuations on a larger platform
1,000 kg workpiece capacity accommodates progressive die plates and heavier tooling
350 mm Z-travel handles taller workpieces than the CUT F 350's 250 mm
0.10 mm minimum wire diameter supports fine-detail cutting on larger parts
Cost-effective positioning between compact CUT F 350 and production CUT P series

Limitations

±30° taper limited to 50 mm height — less taper capability than CUT P and CUT 2000/3000 series
Surface finish (Ra 0.18 µm on steel) is not mirror-class compared to CUT S series
Larger footprint (2160 x 3400 mm) requires more floor space than compact models
Does not include IPG generator — relies on standard Advanced Power Circuit generator

Best For

Progressive die manufacturers needing thermally stable wire EDM for medium-size die plates Mold shops processing larger inserts and cavity retainer plates with consistent accuracy Contract wire EDM shops requiring versatile mid-range capacity with excellent thermal performance Aerospace tooling shops cutting medium-size precision fixtures and structural components Shops upgrading from a compact CUT F 350 to handle larger work without changing to CUT P series

Frequently Asked Questions

01 Why choose the CUT F 600 over the CUT F 350?

The CUT F 600 offers substantially more travel (600 x 400 mm vs 350 x 250 mm), taller Z-axis (350 mm vs 250 mm), and higher workpiece capacity (1,000 kg vs 400 kg). Choose the F 600 when your work regularly includes medium-size die plates, thicker workpieces, or multi-feature tooling exceeding the F 350 envelope.

02 How does thermal compensation benefit a larger-travel machine?

Thermal expansion effects are proportional to distance. On a 600 mm axis, a 5 degree C temperature change causes more absolute positional drift than on a 350 mm axis. The TCS is therefore even more valuable on the CUT F 600, maintaining consistent accuracy across the larger travel range through real-time thermal corrections.

03 Is the CUT F 600 suitable for production environments?

Yes. The CUT F 600 includes automatic wire threading, the AC CUT technology database for reliable parameter selection, and 1,000 kg workpiece capacity for substantial production tooling. For higher-volume production with advanced IPG generator technology, consider the CUT P 550 Pro as a step-up option.

04 What is the maximum part thickness the CUT F 600 can cut?

The 350 mm Z-travel defines the maximum workpiece height. Parts up to 350 mm tall can be wire-cut with full Z-axis positioning. For taller parts, the CUT P 550 Pro offers 400 mm Z-travel, and the CUT P 800 Pro offers 510 mm.
