Ermak Power-Bend Falcon 3760-260
Image: ermaksan.com.tr, Ermak
Key Specifications
bending length
bending power
distance between columns
y rapid speed
y working speed
y return speed
How much does the Ermak Power-Bend Falcon 3760-260 cost?
Price estimate
We do not have a price for the Ermak Power-Bend Falcon 3760-260 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Ermak rates the Power-Bend Falcon 3760-260 at 260 Ton (287 US tons) across 3,760 mm (148 in). The Ermak Power-Bend Falcon 3760-260 is a plate machine first, and the specification reads that way: a 200 mm table, a 22 kW motor, 16,500 kg of frame.
Mass is the notable figure. The step from the Power-Bend Falcon 3760-220, at 12,750 kg, adds several tonnes of steel for a modest gain in rated force. Heavier side frames and beams deflect less, and on long plate bends that stiffness is what keeps the angle constant from end to end.
Approach speed is 140 mm/s and return 135 mm/s. Pressing speed is 10 mm/s. The oil tank holds 300 L.
In height the machine reaches 3,065 mm. It is 5,710 mm long and 2,265 mm wide, and the table is 900 mm from the floor. Opening figures do not change at this tonnage: 275 mm, 550 mm and 410 mm for stroke, daylight and throat.
Gauging is by the standard X and R axes, 800 mm and 250 mm. Plate blanks of this length are heavy, and a single operator cannot swing them; the 2 sheet supports hold the blank, but lifting gear or the optional extraction system has to do the rest. There are 3,250 mm between the columns.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 3,760 mm (148 in) |
| Bending Power | 260 Ton (287 US tons) |
| Distance Between Columns | 3,250 mm (128 in) |
| Y Rapid Speed | 140 mm/s (5.51 in/s) |
| Y Working Speed | 10 mm/s (0.39 in/s) |
| Y Return Speed | 135 mm/s (5.31 in/s) |
| Crowning | Motorized |
| X Axis Travel | 800 mm (31.5 in) |
| X Axis Speed | 500 mm/s (19.69 in/s) |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Speed | 350 mm/s (13.78 in/s) |
| Backgauge Finger Blocks | 2 |
| Sheet Supports | 2 |
| Oil Capacity | 300 L (79.3 US gal) |
| Motor Power | 22 kW (29.5 hp) |
| Stroke | 275 mm (10.8 in) |
| Daylight | 550 mm (21.7 in) |
| Throat Depth | 410 mm (16.1 in) |
| Table Height | 900 mm (35.4 in) |
| Table Width | 200 mm (7.9 in) |
| Length | 5,710 mm (224.8 in) |
| Height | 3,065 mm (120.7 in) |
| Width | 2,265 mm (89.2 in) |
| Machine Weight | 16,500 kg (36,376 lb) |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 16,500 kg frame for stiffness on long plate bends
- 260 Ton over a 3,760 mm bending length
- 200 mm wide table and 22 kW motor
- 3,250 mm passage between the columns
Limitations
- Approach speed of 140 mm/s
- 3,065 mm tall: check the headroom
- No increase in stroke or daylight over lighter sizes
- Handling equipment for heavy blanks is not included
Best For
Frequently Asked Questions
01
16,500 kg. It measures 5,710 mm in length, 2,265 mm in width and 3,065 mm in height. The foundation should be checked for that load before delivery.
02
The ram approaches at 140 mm/s, bends at 10 mm/s and returns at 135 mm/s. X-axis speed is 500 mm/s and R-axis speed 350 mm/s on the backgauge.
03
No. Stroke is 275 mm and daylight 550 mm, as on the lighter sizes. A 375 mm stroke with 650 mm of daylight is found on the Power-Bend Falcon 3760-320.
04
Two sheet supports are standard. Ermak offers pneumatic rear supports and a sheet extraction system that moves bent parts off the table, both as options.
